  • Page 1: Service Manual

    ® Workcentre 6400 Multifunction Printer ® Service Manual...

  • Page 2: Parts List

    Parts List In this chapter... Serial Number Format ■ Using the Parts List ■ Overview Parts ■ Print Engine Parts ■ Option - 500-Sheet Feeder ■ Option - Finisher ■ Option - Printer Stand ■ Xerox Supplies and Accessories ■ Chapter...

  • Page 3: Serial Number Format

    Parts List Serial Number Format Changes to Xerox products are made to accommodate improved components as they become available. It is important when ordering parts to include the following information: Component's part number ■ Product type or model number ■...
  • Page 4 Parts List Example KAA030001: Xerox Serial Number KAA: Product Code for the WorkCentre 6400 1 = Revision Level 30001 = Serial Number for 6400 The serial number labels can be found at two locations of the printer. Label Placement The Barcode label is applied to the Rear panel on the left side of the printer.
  • Page 5 Parts List The Text-only label is applied to the front of the printer chassis. Text-Only Label Location s6400mfp-852 Label Layout Examples MANUFACTURED: May 2009 S/N: KAA030001 Factory ID: KAA030001 s6400mfp-853 WorkCentre 6400 Service Manual...

  • Page 6: Using The Parts List

    J2 is attached to the other end that is plugged into P2. Note Only parts showing part numbers are available for ordering by support. Parts not showing part numbers are available on the parent assembly. Abbreviations Abbreviation Meaning C-ring E-ring K-clip Screw WorkCentre 6400 Service Manual...
  • Page 7 Horizontal Transport Unit Fusing Unit Duplex Unit Vertical Transport Unit Tray 1 (Manual Feed) Tray 2 Laser Unit Section Waste Toner Transport Section Main Frame Section External Parts LVPS Section Paper Exit Section Scanner (IR Section) DADF Section WorkCentre 6400 Service Manual...
  • Page 8 Accessory Parts (500-Sheet Feeder) Option - Finisher, Cover (1 of 2) PL 35.0 page 9-73 Option - Finisher, Cover (2 of 2) PL 36.0 page 9-74 Frame (Finisher) PL 37.0 page 9-76 Paper Entrance (Finisher) PL 38.0 page 9-78 WorkCentre 6400 Service Manual...
  • Page 9 PL 45.0 page 9-88 Drive (1 of 2) (Finisher) PL 46.0 page 9-90 Drive (2 of 2) (Finisher) PL 47.0 page 9-92 Main Tray (Finisher) PL 48.0 page 9-94 Option - Printer Stand PL 49.0 page 9-96 WorkCentre 6400 Service Manual...

  • Page 10: Print Engine Parts

    Parts List Print Engine Parts Parts List 1.0 Duplex Automatic Document Feeder Assembly s6400mfp-422 WorkCentre 6400 Service Manual...
  • Page 11 DADF Top Cover Assy 848K31450 Includes item 1.3 DADF Assy (*) 059K69750 Complete Assy, 100K Life Separator Pad 019K14220 20K Life Friction Pad 019K14230 50K Life Pressure Spring 809E95220 (*) Includes one Calibration Target and Instruction Sheet 9-10 WorkCentre 6400 Service Manual...
  • Page 12 Parts List Parts List 2.0 Scanner Assembly 12 (with 14-17, 19) s6400mfp-423 WorkCentre 6400 Service Manual 9-11...
  • Page 13 Label Screw (Tapping) P/O Hardware Kit Screw (P/O Hinge Assy) Not shown Screw (Tapping) P/O Hardware Kit Screw Screw (Hinge Plate) Not shown Screw P/O Hardware Kit (*) Includes one Calibration Target and Instruction Sheet 9-12 WorkCentre 6400 Service Manual...
  • Page 14 Parts List Parts List 3.0 Covers s6400mfp-318 WorkCentre 6400 Service Manual 9-13...
  • Page 15 Shoulder Screw 826E49130 Qty 5 when ordered Cover 848E40100 Seal Left Side Cover 848E40110 Label Arrow Washer Label Door Latch Label Screw (Tapping) P/O Hardware Kit Screw P/O Hardware Kit C-Clip 019E81510 Also P/O Hardware Kit 9-14 WorkCentre 6400 Service Manual...
  • Page 16 Parts List Parts List 4.0 Main Frame PS11 s6400mfp-319 WorkCentre 6400 Service Manual 9-15...
  • Page 17 Rail Bracket Seal Shoulder Screw Included in Hardware Kit Ground Strap Scanner Open Sensor Kit 604K55020 Label Screw (Tapping) P/O Hardware Kit E-Ring P/O Hardware Kit P/O Hardware Kit Screw (Tapping) P/O Hardware Kit Screw 9-16 WorkCentre 6400 Service Manual...
  • Page 18 Parts List Parts List 5.0 Tray 1 (Manual Feed) 27 28 s6400mfp-320 WorkCentre 6400 Service Manual 9-17...
  • Page 19 Pressure Spring Separation Roller Separation Roller Assy 059K69680 Complete Assembly Gear 25T Guide Plate Guide Feed Roller 059E10850 120K Life Clutch Gear 14T Friction Sheet C-Clip C-Clip P/O Hardware Kit Screw (Tapping) P/O Hardware Kit 9-18 WorkCentre 6400 Service Manual...
  • Page 20 Parts List Parts List 6.0 Imaging Unit Rail TLSB s6400mfp-321 WorkCentre 6400 Service Manual 9-19...
  • Page 21 Toner Cartridge (K), Metered 106R01323 Imaging Unit (C) 108R00775 Imaging Unit (M) 108R00776 Imaging Unit (Y) 108R00777 Imaging Unit (K) 108R00774 Screw P/O Hardware Kit Screw (Tapping) P/O Hardware Kit Screw (Tapping) P/O Hardware Kit 9-20 WorkCentre 6400 Service Manual...
  • Page 22 Parts List Parts List 7.0 Imaging Unit Contact FM13 s6400mfp-322 WorkCentre 6400 Service Manual 9-21...
  • Page 23 Seal Screw Fan Motor (FM13) 127E16410 Exhaust Fan Motor (Ozone Ventilation Fan) Cover Contact (*) Contact (*) Contact (*) Holder Screw P/O Hardware Kit Screw P/O Hardware Kit (*) Developer Bias Voltage contact from HVPS-1. 9-22 WorkCentre 6400 Service Manual...
  • Page 24 Parts List Parts List 8.0 Waste Toner Transport (1 of 2) s6400mfp-323 WorkCentre 6400 Service Manual 9-23...
  • Page 25 Gear 14T Gear 16T Gear 16/20T Gear 17T Stop Ring Waste Toner Auger Assy 848K25680 Complete Assembly Holder 019E81230 Waste Auger Shaft Bearing Foam Seal Screw E-Ring P/O Hardware Kit Screw P/O Hardware Kit C-Clip 9-24 WorkCentre 6400 Service Manual...
  • Page 26 Parts List Parts List 9.0 Waste Toner Transport (2 of 2) s6400mfp-324 WorkCentre 6400 Service Manual 9-25...
  • Page 27 Includes two Cartridges per part number Holder Assy 019K13970 Front Imaging Unit Holder Holder Assy 019K13980 Rear Imaging Unit Holder Gear 19T Stop Ring Bracket Screw (Tapping) P/O Hardware Kit Screw (Tapping) P/O Hardware Kit Screw P/O Hardware Kit 9-26 WorkCentre 6400 Service Manual...
  • Page 28 Parts List Parts List 10.0 LVPS/ Laser Unit LVPS (DCPU) s6400mfp-325 WorkCentre 6400 Service Manual 9-27...
  • Page 29 105E24170 DCPU Bracket Seal Screw (Tapping) P/O Hardware Kit Screw Screw P/O Hardware Kit Screw (Tapping) P/O Hardware Kit (*) Connections to Fuser, LVPS, I/P Board, MCU Board, Scanner. PL 10.7 includes Fuser Bulkhead connector. 9-28 WorkCentre 6400 Service Manual...
  • Page 30 Parts List Parts List 11.0 Drive (1 of 3) - 2nd Transfer Pressure/ Retraction TEM/HUMS PS13 s6400mfp-326 WorkCentre 6400 Service Manual 9-29...
  • Page 31 Gear 17T Lever Tension Spring Torsion Spring Bracket Cover Photo Interrupter (PS5) 130E13000 OHP Sensor Screw (Tapping) P/O Hardware Kit Screw (Tapping) P/O Hardware Kit C-Clip C-Clip 019E81510 P/O Hardware Kit Screw (Tapping) P/O Hardware Kit 9-30 WorkCentre 6400 Service Manual...
  • Page 32 Parts List Parts List 12.0 Drive (2 of 3) - Main Drive 11 12 s6400mfp-327 WorkCentre 6400 Service Manual 9-31...
  • Page 33 Pressure Retraction Clutch 2. M4 requires factory alignment, do not remove it from the Assembly. Screw P/O Hardware Kit C-Clip Screw P/O Hardware Kit C-Clip Screw Screw P/O Hardware Kit Screw P/O Hardware Kit 9-32 WorkCentre 6400 Service Manual...
  • Page 34 Parts List Parts List 13.0 Drive (3 of 3) - Toner Supply (Hopper) FM12 FM11 s6400mfp-328 WorkCentre 6400 Service Manual 9-33...
  • Page 35 M6 = Toner Supply Motor Y/M M7 = Toner Supply Motor C/K Washer Torsion Spring Screw P/O Hardware Kit Screw (Tapping) P/O Hardware Kit Screw (Tapping) P/O Hardware Kit E-Ring P/O Hardware Kit Screw P/O Hardware Kit 9-34 WorkCentre 6400 Service Manual...
  • Page 36 Parts List Parts List 14.0 Transfer Belt Unit IDCSB/R IDCSB/F PS12 s6400mfp-329 WorkCentre 6400 Service Manual 9-35...
  • Page 37 Pressure/ Retraction Sensor 1 Rail Wire Harness Assy (CN27-PJ13) MCU to PS12 Wire Harness Assy (T2HV2) HV2 to 2nd Image Transfer Guide Plate Torsion Spring Contact Rail Plate Spring Screw P/O Hardware Kit Screw P/O Hardware Kit 9-36 WorkCentre 6400 Service Manual...
  • Page 38 Parts List Parts List 15.0 Vertical Transport Unit (1 of 2) A P.16.0 PS10 s6400mfp-330 WorkCentre 6400 Service Manual 9-37...
  • Page 39 Wire Harness Assy (CN14A/B-PJ11) 962K76760 MCU to Duplex Unit Plate Spring Plate Spring Pressure Spring 809E94750 Label - Fuser Jam 896E86840 Screw (Tapping) P/O Hardware Kit Screw P/O Hardware Kit Screw (Tapping) P/O Hardware Kit 9-38 WorkCentre 6400 Service Manual...
  • Page 40 Parts List Parts List 16.0 Vertical Transport Unit (2 of 2) A PL.15.0 15 10 14 13 s6400mfp-331 WorkCentre 6400 Service Manual 9-39...
  • Page 41 Spacer Clutch (CL2) 121E26560 Registration Clutch Lever Transfer Roller 108R00815 Includes Ozone Filter Washer Registration Roller Assy 059K69700 Complete Assembly Screw (Tapping) P/O Hardware Kit E-Ring P/O Hardware Kit E-Ring C-Clip 019E81510 P/O Hardware Kit 9-40 WorkCentre 6400 Service Manual...
  • Page 42 Parts List Parts List 17.0 Horizontal Transport Unit 41 42 11 50 35 46 s6400mfp-424 WorkCentre 6400 Service Manual 9-41...
  • Page 43 Timing Belt 280L Bracket Duct Cushion Spring Roll Guide Seal Holder Pressure Spring Tension Spring Gear 30T Gear 16T Gear 17T Gear 16T Horizontal Transport - Upper 059E10840 Complete Assembly Gear 22T Shaft Gear 17T 9-42 WorkCentre 6400 Service Manual...
  • Page 44 ID No. Name/Description Part Number Qty. Comments Gear 17T Holder Shaft Pulley 14T Shaft Screw Neutralizing Brush Horizontal Transport - Lower 059E10830 Complete Assembly Seal Bearing E-Ring P/O Hardware Kit Screw P/O Hardware Kit Screw WorkCentre 6400 Service Manual 9-43...
  • Page 45 Fuser Unit - 220V 115R00060 Seal Shoulder Screw Pawl 807E34410 Photo Interrupter (PS1, PS2) 130E11800 PS1 = Fuser Exit Sensor PS2 = Paper Feed Sensor C-Clip 019E81510 P/O Hardware Kit Screw (Tapping) P/O Hardware Kit 9-44 WorkCentre 6400 Service Manual...
  • Page 46 Parts List Parts List 19.0 Paper Exit PS15 PS14 s6400mfp-508 WorkCentre 6400 Service Manual 9-45...
  • Page 47 Sensor Wiring 2 Wiring Harness (*) MCU Board to PS14, PS15 Pressure Spring E-Ring P/O Hardware Kit P/O Hardware Kit Screw (Tapping) P/O Hardware Kit Screw P/O Hardware Kit (*) Connections from CN-Exit, CN-Exit1, CN-Exit2 (PS14/PS15) to MCU Board. 9-46 WorkCentre 6400 Service Manual...
  • Page 48 Parts List Parts List 20.0 Electrical Components FM14 FM15 s6400mfp-333 WorkCentre 6400 Service Manual 9-47...
  • Page 49 Hold Plate Bracket Bracket Card Cage Bracket Wire Harness Assy (CN1PG1) AC Input Wire Harness Assy (CN29L/A-PJ34/35MCU) 962K76770 Engine to Finisher Harness Bracket Ferrite Core I/P Board Back Panel 848E40130 Hinge Hinge Seal Washer Screw 9-48 WorkCentre 6400 Service Manual...
  • Page 50 512 MB each IP Board NVRAM Chip 960K52040 Hard Drive Cable 962K40460 Common harness for both NC and CC HDDs Screw P/O Hardware Kit Screw (Tapping) P/O Hardware Kit Screw Screw (Tapping) P/O Hardware Kit Screw Screw WorkCentre 6400 Service Manual 9-49...
  • Page 51 Parts List Parts List 21.0 500-Sheet Tray s6400mfp-334 9-50 WorkCentre 6400 Service Manual...
  • Page 52 Tray 2 Separation Roller Clutch Feed Roller 059E10850 120K Life Cassette Assy (A4) 050K68310 Complete Tray Assembly Cassette Assy (Letter) 050K68320 Complete Tray Assembly K Clip 019E81520 Label Brake E-Ring P/O Hardware Kit E-Ring Screw P/O Hardware Kit WorkCentre 6400 Service Manual 9-51...
  • Page 53 Parts List Parts List 22.0 Duplex Unit (1 of 2) PS16 A PL.23.0 s6400mfp-426 9-52 WorkCentre 6400 Service Manual...
  • Page 54 Duplex Door Sensor Holder ----- ----- Gear 32T Axle Plate (Drive) Timing Belt 158L Duplex Unit 084K36930 Complete Duplex Unit Assembly Label Label Seal Spring Seal Seal Screw P/O Hardware Kit Screw P/O Hardware Kit Screw Washer WorkCentre 6400 Service Manual 9-53...
  • Page 55 Parts List Parts List 23.0 Duplex Unit (2 of 2) A PL.22.0 ADCB s6400mfp-427 9-54 WorkCentre 6400 Service Manual...
  • Page 56 Wiring Harness Assy (PJ2ADCB-PJ22) ADCB to M8 Wiring Harness Assy 117E36000 Duplex Unit to Engine Harness. (CN14A/CN14B-PJ1ADCB) Includes Bulkhead connector E-Ring Screw Screw P/O Hardware Kit Screw (*) Connections from PJ3/PJ4ADCB to PJ23 (M9) and PJ25 (PS16). WorkCentre 6400 Service Manual 9-55...
  • Page 57 CN1PG1 CN1_INPDCPU PJ12MCU PJ25 PJ24 PJ23 PJ33MCU PJ14MCU PJ29MCU PJ31 PJ8MCU PJ22 PJ32 CN27 CN26 PJ5MCU PJ27MCU PJ33 PJ14 PJ7MCU PJ6MCU PJ16 PJ15 CN13 CN12 CN11 PJ6 PJ20 PJ21 PJ15MCU PJ18 PJ26MCU PJ25MCU PJ19 s6400mfp-335 9-56 WorkCentre 6400 Service Manual...
  • Page 58 Developer Motors Harness PJ7MCU to PJ31(M6), PJ32(M7), ■ CN26(CL4), CN27/PJ13(PS12) PJ8MCU & PJ33MCU to PJ21(M5) & ■ PJ16(M4) PJ14MCU to PJ14(M3) ■ PJ27MCU to PJ15(M1) ■ Wire Harness Assy PJ26MCU to PJ19(PS7) & PJ18(PS6) ■ WorkCentre 6400 Service Manual 9-57...
  • Page 59 Wire Harness Assy 962K76810 TLSB Harness Wire Harness Assy (Power Source) 962K76270 Fuser Bulkhead Connector Connections from PJ10MCU to CN17, CL5, PJ10(PS3), PJ11(PS13) & PJ3 (PS4) ■ Connections from PJ3MCU to MS2 & MS3 & MS4 ■ 9-58 WorkCentre 6400 Service Manual...
  • Page 60 11.2 11.5 31.4 32.4 s6400mfp-835 Parts List 26.0 Wiring Accessories ID No. Name/Description Part Number Qty. Comments Saddle Saddle Saddle Saddle P/O Hardware Kit Clamp Clamp Band P/O Hardware Kit Saddle Holder P/O Hardware Kit WorkCentre 6400 Service Manual 9-59...
  • Page 61 Parts List 27.0 Accessories ID No. Name/Description Part Number Qty. Comments Tray Tray Power Cord, 120V 117E35990 Refer to “Xerox Supplies and Accessories” on page 9-98 for non- North America Power Cord part numbers. Output Tray 050E28910 9-60 WorkCentre 6400 Service Manual...
  • Page 62 Parts List Option - 500-Sheet Feeder Parts List 28.0 Optional 500-Sheet Tray 3/4 (1 of 7) 25 (with 1 ~ 24, 26) PCCB s6400mfp-428 WorkCentre 6400 Service Manual 9-61...
  • Page 63 LTA to Engine Wire Harness Assy (PJ1PCCB-CN25) 962K77190 Tray 3 to Tray 4 Connector Reinforce Plate Optional-500 Sheet Feeder 050K68330 Complete 500-Sheet Feeder Assembly (does not include Tray) Label Screw P/O Hardware Kit Screw P/O Hardware Kit 9-62 WorkCentre 6400 Service Manual...
  • Page 64 Parts List Parts List 29.0 Optional 500-Sheet Tray 3/4 (2 of 7) - Paper Take-up Section PS23 PS24 PS22 s6400mfp-429 WorkCentre 6400 Service Manual 9-63...
  • Page 65 Tray 3/4 Paper Feed Sensor Actuator Actuator Guide Slider Wire Harness Assy (*) Label C-Clip Screw P/O Hardware Kit C-Clip Screw P/O Hardware Kit C-Clip P/O Hardware Kit (*) Connections from PJ5PCCB to PJ28(PS24), PJ29(PS23) & PJ30(PS22) 9-64 WorkCentre 6400 Service Manual...
  • Page 66 Parts List Parts List 30.0 Optional 500-Sheet Tray 3/4 (3 of 7) - Drive Section s6400mfp-430 WorkCentre 6400 Service Manual 9-65...
  • Page 67 Pressure Spring Pawl Gear 32T Torsion Spring Gear Motor (M16) 127E16480 Transport Motor Bracket Gear 18/40T Gear 24T C-Clip Screw P/O Hardware Kit Screw P/O Hardware Kit E-Ring P/O Hardware Kit P/O Hardware Kit Screw 9-66 WorkCentre 6400 Service Manual...
  • Page 68 Parts List Parts List 31.0 Optional 500-Sheet Tray 3/4 (4 of 7) - Paper Feed Tray Section PL.32.0 s6400mfp-431 WorkCentre 6400 Service Manual 9-67...
  • Page 69 Shoulder Screw Guide Pressure Spring Knob Lever Shaft Label Lever Label Paper Supply Bracket Detecting Plate Guide Plate Spring Back Stop Cassette (Tray) Cassette Assy (Tray Assy) 050K68340 Complete Tray Assembly E-Ring P/O Hardware Kit Screw 9-68 WorkCentre 6400 Service Manual...
  • Page 70 Parts List Parts List 32.0 Optional 500-Sheet Tray 3/4 (5 of 7) - Paper Feed Tray Section PL.31.0 s6400mfp-432 WorkCentre 6400 Service Manual 9-69...
  • Page 71 Tension Spring Lever Guide Plate Guide Resistor Plate Spring Plate Spring Shaft Guide Guide K-Clip 019E81520 K-Clip 005E29580 Separation Roller Assy 059K70360 Complete Assembly C-Clip C-Clip P/O Hardware Kit C-Clip Screw P/O Hardware Kit Washer 9-70 WorkCentre 6400 Service Manual...
  • Page 72 Parts List 33.0 Optional 500-Sheet Tray 3/4 (6 of 7) - Wiring Accessories s6400mfp-433 Parts List 33.0 Optional 500-Sheet Tray 3/4 (6 of 7) - Wiring Accessories ID No. Name/Description Part Number Qty. Comments Cord Clamp Saddle WorkCentre 6400 Service Manual 9-71...
  • Page 73 Parts List 34.0 Optional 500-Sheet Tray 3/4 (7 of 7) - Accessory Parts s6400mfp-434 Parts List 34.0 Optional 500-Sheet Tray 3/4 (7 of 7) - Accessory Parts ID No. Name/Description Part Number Qty. Comments Cover 848E40140 Rear LTA Fasteners 029E51120 Front LTA Fasteners 029E51160 Label Tray 3/4 9-72 WorkCentre 6400 Service Manual...
  • Page 74 Parts List 35.0 Cover (1 of 2) ID No. Name/Description Part Number Qty. Comments Rear Cover Assy Cushion Cushion Front Cover Assy Label Staple Supply Front Door Plate Spring Tapping Screw Finisher Assy 059K69720 Complete Assembly Screw WorkCentre 6400 Service Manual 9-73...
  • Page 75 Parts List Parts List 36.0 Cover (2 of 2) PS10 s6400mfp-436 9-74 WorkCentre 6400 Service Manual...
  • Page 76 PS10 = Paper Level Sensor 2 Caution: Connectors to PS9 and PS10 can get swapped. The wiring color is different, but the plugs are the same. Wire Harness Assy (CN8FSCB-PJ6, PJ7) FSCB to PS9, PS10 Cushion Screw WorkCentre 6400 Service Manual 9-75...
  • Page 77 Parts List Parts List 37.0 Frame s6400mfp-437 9-76 WorkCentre 6400 Service Manual...
  • Page 78 Wire Harness Assy (CN24FSCB-MS1) Bracket Push Button Switch Front Door Switch (MS1) 110K21050 Finisher Front Door Switch (Stapler Cover) Holder Screw Lever Tension Spring Lock Assy ----- Stop Ring 005E29460 Hook 019E81240 Qty 1 when ordered Screw Screw WorkCentre 6400 Service Manual 9-77...
  • Page 79 Parts List Parts List 38.0 Paper Entrance PL.39.A s6400mfp-438 9-78 WorkCentre 6400 Service Manual...
  • Page 80 Neutralizing Brush Neutralizing Brush Assy 118K01690 Tray 050E28920 Top Tray Pressure Spring Lever Roller Shaft Holder Paper Exit Assy 848K31460 Includes items 13-15, 19-22 Does not include 38.05 Guide Assy 032K09700 Includes items 6-12, 23 Screw WorkCentre 6400 Service Manual 9-79...
  • Page 81 Parts List Parts List 39.0 Paper Transport (1 of 2) 25 22 18 17 PL.38.24 s6400mfp-439 9-80 WorkCentre 6400 Service Manual...
  • Page 82 Gear 32T Gear Lever Pulley Gear 16T Timing Belt Collar Retaining Ring Label Dial Collar Gear 18T Bushing Gear 16T Sensor Assy Wire Harness Assy (CN7FSCB-PS4) Bracket Assy Roller C-Clip P/O Hardware Kit E-Ring Screw WorkCentre 6400 Service Manual 9-81...
  • Page 83 Parts List 40.0 Paper Transport (2 of 2) s6400mfp-440 Parts List 40.0 Paper Transport (2 of 2) ID No. Name/Description Part Number Qty. Comments Guide Neutralizing Brush Tapping Screw Roller Assy Roller Assy Roller Assy Roller Assy 059K69730 Includes items 1-6 Screw 9-82 WorkCentre 6400 Service Manual...
  • Page 84 ID No. Name/Description Part Number Qty. Comments Sensor Assy 130K76010 Complete Assembly Photo Interrupter (PS5, PS7) 130E13030 PS5 = Paper Ejector Sensor PS7 = Storage Section Sensor Torsion Spring Stop Ring Sensor Assy Tapping Screw WorkCentre 6400 Service Manual 9-83...
  • Page 85 Parts List Parts List 42.0 Alignment (2 of 2) PL.47.0 s6400mfp-442 Parts List 42.0 Alignment (2 of 2) ID No. Name/Description Part Number Qty. Comments Paddle 033E05420 Tension Spring Tension Spring 9-84 WorkCentre 6400 Service Manual...
  • Page 86 Parts List Parts List 43.0 Storage (1 of 2) P.46 s6400mfp-443 Parts List 43.0 Storage (1 of 2) ID No. Name/Description Part Number Qty. Comments Lever Bushing C-Clip WorkCentre 6400 Service Manual 9-85...
  • Page 87 Parts List Parts List 44.0 Storage (2 of 2) PL.46.0 s6400mfp-444 9-86 WorkCentre 6400 Service Manual...
  • Page 88 Parts List 44.0 Storage (2 of 2) ID No. Name/Description Part Number Qty. Comments Gear 14T Bush Shaft Assy Stopper Ring Bushing Bracket Bushing Stop Ring Roller Collar Pulley 22T Flange Roller Assy 059K69740 Tapping Screw Screw C-Clip E-Ring WorkCentre 6400 Service Manual 9-87...
  • Page 89 Parts List Parts List 45.0 Stapler Unit 11 (with 1, 3-10) s6400mfp-445 9-88 WorkCentre 6400 Service Manual...
  • Page 90 Wire Harness Assy (CN23FSCB - CN9) Wire Harness Assy (CN9 - PJ20 & PJ19) Bracket Label Cushion Base Frame Tapping Screw Stapler Unit Label Arrow Stapler Assy 029K04650 Complete Stapler Assembly Screw Screw P/O Hardware Kit WorkCentre 6400 Service Manual 9-89...
  • Page 91 Parts List Parts List 46.0 Drive (1 of 2) PS11 PL.44.0 PL.43.0 FSCB s6400mfp-446 9-90 WorkCentre 6400 Service Manual...
  • Page 92 Motor (M3, M4) 127E16490 M3 = Transport Motor M4 = Exit Motor Bracket Tension Spring Bracket Fan Motor (FM1) 127E16500 FM1 = Fan Motor Screw Screw Screw C-Clip Screw (*) Connections from CN1/CNAFSCB to CN2/CN3 to Engine WorkCentre 6400 Service Manual 9-91...
  • Page 93 Parts List Parts List 47.0 Drive (2 of 2) PL.42.0 s6400mfp-447 9-92 WorkCentre 6400 Service Manual...
  • Page 94 Tension Spring Gear 32/18T Bracket Tapping Screw Motor 127E16510 M5 = Exit Roller Up/ Down Motor Wire Harness Assy Bracket Photo Interrupter (PS8) Exit Roller Sensor Solenoid (SD4) Paddle Solenoid C-Clip Screw Screw P/O Hardware Kit WorkCentre 6400 Service Manual 9-93...
  • Page 95 Parts List Parts List 48.0 Main Tray 18 (with 9-17) 17 (with 1-8, 16) PS12 PS13 s6400mfp-448 9-94 WorkCentre 6400 Service Manual...
  • Page 96 PS12 = Tray Upper Sensor PS13 = Tray Lower Sensor Holder Lever Gear 40T Lever Holder Holder Cover Wire Harness Assy Lever Holder Tray Cushion Screw Tray Motor Assy Tray Assy 050K68350 Complete Main Tray Assembly WorkCentre 6400 Service Manual 9-95...
  • Page 97 Parts List Option - Printer Stand Parts List 49.0 Printer Stand s6400mfp-743 9-96 WorkCentre 6400 Service Manual...
  • Page 98 Part Number Qty. Comments Stand Assembly 078K00820 Complete Assembly Leg Stand Assy 078K00830 Left/ Right Leg Assembly Door Assy 078K00840 Mounting Kit 604K55040 Frame Assy Cover, Rear RePack Kit 650K65000 Stand Repackaging Kit (Not shown) WorkCentre 6400 Service Manual 9-97...
  • Page 99 Fuser Unit 18.1 115R00059 Fuser Unit - 110V ■ 150K, continuous ■ 130K, 2-page jobs ■ 115R00060 Fuser Unit - 220V ■ 150K, continuous ■ 130K, 2-page jobs ■ Transfer Roller (Up to 120K) 16.20 108R00815 9-98 WorkCentre 6400 Service Manual...
  • Page 100 Power Cord, Denmark, 230V 117E29460 Power Cord, India/South Africa, 230V 117E29470 Power Cord, Israel, 230V 117E29480 Power Cord, Australia, 230V 117E29490 Power Cord, China, 220V 117E35030 Power Cord, Argentina, 220V 117E35040 Power Cord, Switzerland, 230V 117E35050 WorkCentre 6400 Service Manual 9-99...
  • Page 101 Service Kits are developed to provide an easy means to obtain spare parts normally associated with larger assemblies. A number of Service Kits have been developed for the WorkCentre 6400. The following tables list the contents for each kit. Kits...
  • Page 102 Steps Screw 4.21 Steps Screw 20.1 Repack Kit Parts List Reference Description Part Number Printer Packaging Kit 695K28270 Tools Parts List Part Number Description Reference USB Memory with Firmware 237E25350 DADF Registration Calibration Target Sheet 109K02300 WorkCentre 6400 Service Manual 9-101...
