OPERATING and
INSTALLATION MANUAL
STATIONARY ELECTRICAL WATER TANKS
OKCE 160 NTR / 2,2 kW
OKCE 200 NTR / 2,2 kW
OKCE 250 NTR / 2,2 kW
OKCE 300 NTR / 2,2 kW
OKCE 300 NTR / 3-6 kW
OKCE 200 NTRR / 2,2 kW
OKCE 250 NTRR / 2,2 kW
OKCE 300 NTRR / 2,2 kW
OKCE 300 NTRR / 3-6 kW
Družstevní závody Dražice - strojírna s.r.o.
Dražice 69, 294 71 Benátky nad Jizerou
Phone.: +420 /326 370 990
Fax: +420 / 326 370 980
e-mail: prodej@dzd.cz
OKC 160 NTR / BP
OKC 200 NTR / BP
OKC 250 NTR / BP
OKC 300 NTR / BP
OKC 200 NTRR / BP
OKC 250 NTRR / BP
OKC 300 NTRR / BP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OKCE 200 NTR and is the answer not in the manual?

Questions and answers

Related Manuals for Drazice OKCE 200 NTR

Summary of Contents for Drazice OKCE 200 NTR

  • Page 1 INSTALLATION MANUAL STATIONARY ELECTRICAL WATER TANKS OKCE 160 NTR / 2,2 kW OKC 160 NTR / BP OKCE 200 NTR / 2,2 kW OKC 200 NTR / BP OKCE 250 NTR / 2,2 kW OKC 250 NTR / BP OKCE 300 NTR / 2,2 kW...

  • Page 2: Table Of Contents

    CONTENTS PRODUCT TECHNICAL SPECIFICATION ....................... 4 FUNCTION DESCRIPTION ........................4 PRODUCT DESCRIPTION ........................4 DESIGN AND BASIC DIMENSIONS OF TANK ..................5 TECHNICAL PARAMETERS ........................9 OPERATION AND FITTING INSTRUCTIONS ....................13 OPERATING CONDITIONS ........................ 13 ELECTRICAL INSTALLATION ......................13 2.2.1 ELECTRIC HEATING UNIT'S TECHNICAL PARAMETERS .............
  • Page 3 PRIOR TO THE INSTALLATION OF THE TANK, READ CAREFULLY THIS MANUAL! Dear Customer, The Works Cooperative of Dražice – Machine Plant, Ltd., would like to thank you for your decision to use a product of our brand. The present instructions will introduce you to the use, construction, maintenance and other information regarding electrical water tanks.

  • Page 4: Product Technical Specification

    1 PRODUCT TECHNICAL SPECIFICATION 1.1 FUNCTION DESCRIPTION The construction of OKC 160 - 300 series tanks and their variety allow economic preparation of hot sanitary water (HSW) using different energy sources. Their nominal performance provides sufficient amount of hot sanitary water for flat units, premises, restaurants, and similar establishments. HSW can be heated by electric energy, different types of central heating boilers, recoverable energy sources (heat pumps, solar collectors) and combinations of those.

  • Page 5: Design And Basic Dimensions Of Tank

    1.3 DESIGN AND BASIC DIMENSIONS OF TANK OKCE 160 NTR/2,2 kW, OKCE 200 NTR/2,2 kW, OKCE 250 NTR/2,2 kW OKC 160 NTR/BP, OKC 200 NTR/BP, OKC 250 NTR/BP Figure 1 OKCE 160 NTR/2,2 kW OKCE 200 NTR/2,2 kW OKCE 250 NTR/2,2 kW...
  • Page 6 OKCE 200 NTRR/2,2 kW, OKCE 250 NTRR/2,2 kW, OKC 200 NTRR/BP, OKC 250 NTRR/2,2 BP OKCE 200 NTRR/2,2 kW OKCE 250 NTRR/2,2 kW Type OKC 200 NTRR/BP OKC 250 NTRR/BP 1362 1542 1282 1465 1065 1002 Figure 2 1152 1335 - 6 -...
  • Page 7 OKCE 300 NTR/2,2 kW, OKCE 300 NTR/3-6 kW, OKC 300 NTR/BP Figure 3 - 7 -...
  • Page 8 OKCE 300 NTRR/2,2 kW, OKCE 300 NTRR/3-6 kW, OKC 300 NTRR/BP Figure 4 - 8 -...

  • Page 9: Technical Parameters

    1.4 TECHNICAL PARAMETERS MODEL OKCE 160 NTR/2,2kW OKC 160 NTR/BP Capacity [l] Weight without water [kg] TANK OPERATING PRESSURE [MPa] HEAT EXCHANGER OPERATING PRESSURE [MPa] MAX TEMPERATURE OF HEATING WATER [°C] MAX TEMPERATURE OF HOT WATER [°C] Heating surface of bottom heat 1.45 exchanger [m Heating surface of upper heat exchanger...
  • Page 10 OKCE 200 OKC 200 OKCE 200 OKC 200 MODEL NTR/2,2kW NTR/BP NTRR/2,2 kW NTRR/BP Capacity [l] Weight without water [kg] TANK OPERATING PRESSURE [MPa] HEAT EXCHANGER OPERATING PRESSURE [MPa] MAX TEMPERATURE OF HEATING WATER [°C] MAX TEMPERATURE OF HOT WATER [°C] Heating surface of bottom heat 1.45 1.08...
  • Page 11 Table 2 OKCE 250 OKC 250 OKCE 250 OKC 250 MODEL NTR/2,2kW NTR/BP NTRR/2,2 kW NTRR/BP Capacity [l] Weight without water [kg] TANK OPERATING PRESSURE [MPa] HEAT EXCHANGER OPERATING PRESSURE [MPa] MAX TEMPERATURE OF HEATING WATER [°C] MAX TEMPERATURE OF HOT WATER [°C] Heating surface of bottom heat 1.45...
  • Page 12 OKCE 300 OKCE 300 OKCE 300 OKCE 300 OKC 300 OKC 300 MODEL NTR/2,2 NTR/3-6 NTRR/2,2 NTRR/3-6 NTR/BP NTRR/BP Capacity [l] Weight without water [kg] TANK OPERATING PRESSURE [MPa] HEAT EXCHANGER OPERATING PRESSURE [MPa] MAX TEMPERATURE OF HEATING WATER [°C] MAX TEMPERATURE OF HOT WATER [°C] Heating surface of bottom...

  • Page 13: Operation And Fitting Instructions

    10 mm range. 2.2 ELECTRICAL INSTALLATION Wiring for: OKCE 160 NTR/2,2 kW, OKCE 200 NTR/2,2 kW, OKCE 200 NTRR/2,2 kW, OKCE 250 NTR/2,2kW, OKCE 250 NTRR/2,2 kW, OKCE 300 NTR/2,2 kW, OKCE 300 NTRR/2,2 kW,...

  • Page 14: Electric Heating Unit's Technical Parameters

    2.2.1 ELECTRIC HEATING UNIT'S TECHNICAL PARAMETERS Heating unit Universal heating unit 3-6 kW 2.2 kW POWER kW 1 PE-N AC 1 PE-N AC 2 PE-N AC 3 PE-N AC 3 PE-N AC VOLTAGE 230 V 50 Hz 230 V 50 Hz 400 V 50 Hz 400 V 50 Hz 400 V 50 Hz...

  • Page 15: Heating Unit - Flanges

    2.2.2 HEATING UNIT - FLANGES OKCE 300 NTR/2,2 kW, OKCE 300 NTRR/2,2 kW OKCE 160 NTR/2,2 kW, OKCE 200 NTR/2,2 kW, Flange 2,2 kW OKCE 200 NTRR/2,2 kW, OKCE 250 NTR/2,2 kW, OKCE 250 NTRR/2,2 kW Flange 2,2 kW Fastening 8 x M10...

  • Page 16: Plumbing Fixture

    Heating unit 3-6 kW The 3-6 kW heating unit allows 4 universal types of connection based on either the required time of heating, or possibilities of electric network in the place of use. To achieve the chosen performance of the heating unit, connect the inlet conductor to the terminal board L1-L2-L3-N and interconnect the terminals on the terminal board 1 –...
  • Page 17 6). If the water main pressure exceeds that value, reduction valve must be added to the system. No closing armature may be mounted between the tank and the safety valve. During the assembly, follow the guide provided by the safety equipment manufacturer. It is necessary to check the safety valve each time before putting it into operation.

  • Page 18: Pressure Losses

    2.4 PRESSURE LOSSES Heat exchanger with 1.5 m Heat transfer surface 1 m2 Heating water flow m3/hr Pressure loss (mbar) Type tHV = 60 °C Amount of heating water in m3/hr Heat exchanger Heat exchanger 1.5 m Table 7 2.5 EXAMPLES OF CONNECTING TANKS Connecting a tank to heating system - 18 -...
  • Page 19 The tank is placed on the floor next to the heating source or in its proximity. The heating circuit is connected to marked tank exchanger inputs and outputs, and bleeder valve is installed at the highest point. It is necessary to install a filter into the circuit in order to protect pumps, three-way valve, backflow flaps and the exchanger from sedimentation.
  • Page 20 OKC 160-300 NTR heated by gas boiler with two pumps Figure 11 - 20 -...
  • Page 21 OKC 200-300 NTRR heated by gas boiler and solar collectors, controlled by three-way valve Figure 12 - 21 -...

  • Page 22: First Commissioning

    2.6 FIRST COMMISSIONING Once the tank is connected to water supply system and power supply, and safety valve tested (accordingly with the manual attached to the valve), the tank can be put in operation. Procedure: Check the water main and wiring; Check proper placement of thermostat sensors. The sensors in the well must be inserted all the way in;...

  • Page 23: Hsw Temperature Control For 160-250 Litre Tanks

    2.7.2 HSW TEMPERATURE CONTROL FOR 160-250 LITRE TANKS OKCE 160 NTR/2,2 kW, OKCE 200 NTR/2,2 kW, OKCE 250 NTR/2,2 kW, OKC 160 NTR/BP, OKC 200 NTR/BP, OKC 250 NTR/BP OKCE 200 NTRR/2,2 kW, OKCE 250 NTRR/2,2 kW, OKC 200 NTRR/BP, OKC 250 NTRR/BP Each tank has a separate HSW temperature control for each heat exchanger.

  • Page 24: Cleaning Of Tank And Exchange Of Anode Rod

    Wiring diagram: 230 V 24 V Schéma zapojení NTR 24 V – Wiring diagram NTR 24 V 2.8 CLEANING OF TANK AND EXCHANGE OF ANODE ROD Repetitive water heating causes limestone sediment on both the enamelled tank walls and chiefly the flange lid.

  • Page 25: Spare Parts

    6. During the fitting, make sure the grounding cable (300-500l) is connected properly; this is the condition of the anode's proper functioning 7. Fill the tank with water PROCEDURE OF EXCHANGING ANODE ROD IN SIDE FLANGE 1. Turn off control voltage to the tank 2.

  • Page 26: Dispposal Of Pckaging Material And Non-Functioning Product

    Without a proof issued by a professional company about performed electrical and plumbing fixture the warranty shall be void. It is necessary to check the protective magnesium anode periodically and replace it if necessary. No closing armature may be mounted between the tank and the safety valve. If the overpressure in the eater main exceeds 0.48 MPa, a reduction valve must be mounted before the safety valve.
