WF-2000 Series
Wi-Fi I/O Module
AIO User's Manual
www.icpdas.com
WF-2000 Series AIO
User's Manual (Ver. 1.2, May./2014) ------------- 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WF-2017 and is the answer not in the manual?

Questions and answers

Related Manuals for ICP DAS USA WF-2017

Summary of Contents for ICP DAS USA WF-2017

  • Page 1 WF-2000 Series Wi-Fi I/O Module AIO User’s Manual www.icpdas.com WF-2000 Series AIO User’s Manual (Ver. 1.2, May./2014) ------------- 1...
  • Page 2 Warranty All products manufactured by ICP DAS are under warranty regarding defective materials for a period of one year from the date of delivery to the original purchaser. Warning ICP DAS assumes no liability for damages resulting from the use of this product.

  • Page 3: Table Of Contents

    Table of Contents 1. Introduction ..................5 Wireless connection mode ..............5 Features..................... 5 1.2.1 Features Description ................ 6 Specifications ..................7 2. Hardware ..................11 Front Panel ..................11 2.1.1 LED Indicator ................. 12 2.1.2 I/O Connector................. 12 Top Panel ..................14 Dimensions ..................
  • Page 4 5.2.4 Response ..................46 5.2.5 Data Encoding................47 Address Mapping ................48 5.3.1 WF-2017 I/O Address Mapping ............48 5.3.2 WF-2019 I/O Address Mapping ............48 5.3.3 WF-2026 I/O Address Mapping ............49 6. Troubleshooting................50 Appendix A....................52 A.1 Analog Input Type and Data Format Table ............ 52 A.2 Analog Output Type and Data Format Table..........

  • Page 5: Introduction

    1. Introduction The WF-2000 series I/O modules have WLAN connection complies with the IEEE802.11b/g standards. With the popularity of 802.11 network infrastructure, the WF-2000 series I/O modules make an easy way to incorporate wireless connectivity into monitoring and control systems. They also support Modbus/TCP and UDP protocol and the network encryption configuration, which makes perfect integration to SCADA software and offer easy and safe access for users from anytime and...

  • Page 6: Features Description

    1.2.1 Features Description The WF-2000 module offers the most comprehensive configuration to meet specific application requirements. The following list shows the features designed to simplify installation, configuration and application. Compatible with IEEE 802.11b/g standards WF-2000 module complied with IEEE 802.11b/g standard from 2.4~2.5GHz, and it can be used to provide up to 11Mbps for IEEE 802.11b and 54Mbps for 2.4GHz IEEE 802.11g to connect your wireless LAN.

  • Page 7: Specifications

    Module Watchdog is a built-in hardware circuit that monitors the operating status of the module and will reset the module if a failure occurs in the hardware or the software. Specifications Table 1-1 System Specifications Modules WF-2017 WF-2019 WF-2026 Wi-Fi Interface Antenna 5 dBi (Omni-Directional)
  • Page 8 Table 1-2 WF-2017 I/O Specification Modules WF-2017 Analog Input Channels 8-ch Differential / 16-ch Single-ended(Note), Jumper Selectable Voltage : ±150 mV, ±500 mV, ±1 V, ±5 V, ±10 V Input Type Current : 0 ~ +20 mA, +4 ~ +20 mA, ±20 mA (Jumper Selectable)
  • Page 9 Table 1-3 WF-2019 I/O Specification Modules WF-2019 Analog Input Channels Voltage : ±15 mV, ±50 mV, ±100 mV, ±500 mV, ±1 V, ±2.5 V, ±5 V, ±10 V Input Type Current : ±20 mA (External resistor is required) Thermocouple : J, K, T, E, R, S, B, N, C Resolution 16 bit Accuracy...
  • Page 10 Table 1-4 WF-2026 I/O Specification Analog Input Channels Wiring Differential Voltage ±150 mVDC, ±500 mVDC, ±1 VDC, ±5 VDC, ±10 VDC Input Range Current 0 ~ +20 mA, +4 ~ +20 mA, ±20 mA (Jumper Selectable) Resolution 16 bit Accuracy ±0.1% FSR Sampling Rate 10 Hz (Total)

  • Page 11: Hardware

    2. Hardware 2.1 Front Panel The WF-2000(AIO) front panel contains the antenna, I/O connectors and LEDs. RP SMA Connector Signal strength System Status I/O Connector Figure 2-1 Front Panel of the WF-2000(AIO) WF-2000 Series AIO User’s Manual (Ver. 1.2, May./2014) ------------- 11...

  • Page 12: Led Indicator

    Table 2-2 Signal Strength LED Indicator Signal Strength LED Indicator LED Status Signal strength High Medium Bad or No Signal 2.1.2 I/O Connector 2.1.2.1 WF-2017 Figure 2-2 I/O Connector of WF-2017 WF-2000 Series AIO User’s Manual (Ver. 1.2, May./2014) ------------- 12...
  • Page 13 2.1.2.2 WF-2019 Figure 2-3 I/O Connector of WF-2019 Figure 2-4 Pin Assignment of DB-1820 WF-2000 Series AIO User’s Manual (Ver. 1.2, May./2014) ------------- 13...

  • Page 14: Top Panel

    2.1.2.3 WF-2026 Figure 2-5 I/O Connector of WF-2026 2.2 Top Panel The WF-2000 top panel contains the Power/Signal connector and operating mode Selector switch. Power/RS-232 Operating Mode Connector Selector Switch Figure 2-6 Top Panel of the WF-2000 WF-2000 Series AIO User’s Manual (Ver.

  • Page 15: Dimensions

    The diagrams below provide the dimensions of the WF-2000 to use in defining your enclosure specifications. All dimensions are in millimeters. Figure 2-7 Front / Left Side dimension of the WF-2017/WF-2026 WF-2000 Series AIO User’s Manual (Ver. 1.2, May./2014) ------------- 15...
  • Page 16 Figure 2-8 Front / Left Side dimension of the WF-2019 Figure 2-9 Top / Bottom dimension of the WF-2017/WF-2026 WF-2000 Series AIO User’s Manual (Ver. 1.2, May./2014) ------------- 16...

  • Page 17: Hardware Connection

    Figure 2-10 Top / Bottom dimension of the WF-2019 Hardware Connection 2.4.1 Power and Serial port connection The following figures describe the Power and the COM port to a serial device via serial network. Figure 2-11 Power and Serial port wire connection WF-2000 Series AIO User’s Manual (Ver.

  • Page 18: I/O Connection

    2.4.2 I/O connection 2.4.2.1 WF-2017 Figure 2-12 AI wire connection of WF-2017 2.4.2.2 WF-2019 Figure 2-13 AI wire connection of WF-2019 WF-2000 Series AIO User’s Manual (Ver. 1.2, May./2014) ------------- 18...
  • Page 19 2.4.2.3 WF-2026 Figure 2-14 AIO wire connection of WF-2026 Figure 2-15 DIO wire connection of WF-2026 WF-2000 Series AIO User’s Manual (Ver. 1.2, May./2014) ------------- 19...

  • Page 20: Jumper Settings

    Table 2-4 WDT Jumper Position Mode Jumper Number WF-2017 WF-2019 WF-2026 Enable (default) Disable Figure 2-16 Watchdog timer Jumper Position 2.5.2 AI Settings Table 2-5 WF-2017 AI Input Type/Mode Jumper configuration Input Mode Jumper Position Input Type Jumper Position Modules Differential Voltage Single-ended WF-2017...

  • Page 21: Fw / Op Dip-Switch

    Table 2-6 WF-2026 Analog Input/Output Type Jumper configuration Output Type Jumper Position Input Type Jumper Position Modules Voltage Voltage WF-2026 Current Current FW / OP Dip-switch On the top of the WF-2000 series module, there is a dip-switch used for firmware operation or firmware update of the module. The following steps show how to use this dip-switch.
  • Page 22 Figure 2-18 CA-0910 Cable Figure 2-19 Downloads cable connection Users just need to execute “Firmware_Update_Tool.exe” and follow the below steps to complete the firmware updating process. [1] Choose “COM” interface and “COM Port”. [2] Click “Browser” button to choose firmware file. (e.g. WF20xx.fw) [3] Click “Firmware Update”...

  • Page 23: Firmware Operation Mode

    Figure 2-20 WF-2000 firmware update process The WF-2000 firmware can be downloaded from ftp://ftp.icpdas.com/pub/cd/usbcd/napdos/wifi/io/wf-20xx/firmware The Firmware_Update_Tool program can be downloaded from ftp://ftp.icpdas.com/pub/cd/usbcd/napdos/wifi/io/wf- 20xx/software/tool/ 2.6.2 Firmware Operation Mode In the operation mode, users need to set the dip-switch to the “OP” position as Figure 2-22 and reset the power, and the WF-2000 can run in operation mode.
  • Page 24 Figure 2-21 OP Position of Dip-Switch WF-2000 Series AIO User’s Manual (Ver. 1.2, May./2014) ------------- 24...

  • Page 25: Software

    3. Software The WF-2000 Utility provides a simple way to test and acquire data easily and instantly for all ICP DAS WF-2000 series I/O modules without programming. WF-2000 Utility can be used to configure the wireless network interface, establish a TCP connection, I/O control and I/O monitoring of WF-2000 series I/O modules.

  • Page 26: Configuration Screen

    Menu Function: [1] File Exit Press this button to exit WF-2000 I/O Utility. [2] Device Search This function can search all of WF-2000 devices that support UDP communication. Configuration This function can enter the basic wireless configuration interface, as shown in Figure 3-2. [3] Search List Search list provides each item that scans from UDP and display the related information about the device, includes host name, alias...
  • Page 27 [1] Network Net ID The Unit Identifier in Modbus TCP/IP application data unit. (Range:1~247, Default:1) DHCP Enable If a DHCP server is present on the network, the WF-2000 will automatically obtain the network settings from the DHCP server when the DHCP function is enabled. (Ad Hoc mode don't support DHCP configuration) IP Address WF-2000 IP setting (Default:192.168.255.1)
  • Page 28 Figure 3-3 Auto search SSID list Wi-Fi Modes Table 3-1 AP Mode Configuration AP：Use the wireless access point way for connection and transmission. Wi-Fi Mode (Must have Wi-Fi AP) Service Set Identifier: Connected devices must be with the same SSID, SSID SSID length must not exceed 20 characters.
  • Page 29 [3] General F/W Version Display the firmware version of the WF-2000 Date created Display the date created of the WF-2000 Auto Disconnect Once the connection is established, if there is no data exchange within 60 sec the socket will be closed automatically when the this function is enabled Communication Net ID Modbus Net ID of WF-2000...

  • Page 30: Analog Input Screen

    The detail of all items in this form will be introduced in this section. Data Monitor Region Configuration Region Message Region Figure 3-4 WF-2017 diagnostic screen Configuration Region Data Monitor Region Message Region Figure 3-5 WF-2019 diagnostic screen WF-2000 Series AIO User’s Manual (Ver.
  • Page 31 Data Monitor and Control Region Configuration Region Configuration Region Message Region Figure 3-6 WF-2026 diagnostic screen Configuration Region All I/O related configurations can be set in this region. This region is divided into two parts, channel and module related setting. The channel related setting is in the "Selected Channel".
  • Page 32 Channel CJC Offset Setting the CJC offset for the specific channel. The behavior of the setting is the same as the CJC Offset, but it only affects specific channel. Note: The CJC offset can be any in the range of -30.00 to +100.00 °C.
  • Page 33 Note: The valid value is 100 ~ 5000ms. Show Hex Convert the I/O value from decimal to hexadecimal. RSSI This area will display the signal strength information by RSSI value and LED indicator when press the "Get" button. Table 3-3 Signal Strength Information Display Table Signal Strength LED Indicator LED Status RSSI value...
  • Page 34 Digital Output Monitor and Control Region The digital output value can be read and write in this region. Power On Value of DO The power on value of DO can be Set and Get in this region. It is loaded into the DO under 3 conditions: power on, reset by Module Watchdog, reset by reset command.
  • Page 35 Power On Value of AO The power on value of AO can be Set and Get in this region. It is loaded into the AO under 3 conditions: power on, reset by Module Watchdog, reset by reset command. Enable: Select which channel to enable or disable this function.

  • Page 36: Application Notes

    4. Application Notes Users can use a computer to communicate with the WF-2000 devices in the application. It can complete the purpose of I/O control to wireless network by this way. Figure 4-1 WF-2000 application architecture 4.1 Hardware Installation Before use, associated hardware configuration, the steps described as follows：...

  • Page 37: Wf-2000 Series Configuration

    If you do not need parameter setting, this step can be omitted. Step 3: Power connection Connect the power supply to WF-2000 series' power terminator, as shown in Figure 2-5. 4.2 WF-2000 series Configuration 4.2.1 WF-2000 Series Wireless Network Configuration Figure 4-2 Configuration Interface 01、Net ID : The Unit Identifier in Modbus TCP/IP application data unit.

  • Page 38: Pc Connection Configuration

    4.2.2 PC Connection Configuration 01、TCP/IP Setting : a. Open Network connections and entry the properties setting of wireless network connections. Figure 4-3 Properties setting of wireless network connections b. Select the Internet Protocol (TCP/IP) and press the "Properties" button. Figure 4-4 Properties setting of Internet Protocol (TCP/IP) c.
  • Page 39 address as "192.168.255.10", Subnet mask as "255.255.255. 0". Finally, press "OK" button. Figure 4-5 IP address setting interface 02、Wireless network connection : a. View available wireless networks and you can see the "WF- 20xx" wireless network in the list. b. Select the "WF-20xx" and press the "Connect" button. Figure 4-6 Wireless network connection c.

  • Page 40: Access I/O Data

    Figure 4-7 Connection confirm interface d. After waiting for a while, there will appear connection success screen. Figure 4-8 Connection successful interface 4.2.3 Access I/O data 01、Connection with WF-2000 I/O utility (v2.3 or later) a. Open WF-2000 I/O utility and click the "Search" button, choose the network interface that connect with the WF-2000 device, search list will provide each item that scan from UDP Port.
  • Page 41 b. To access the WF-2000 I/O module user can double click the module listed in "Device List". Figure 4-10 WF-2000 search list c. Then you will see the I/O page come out. In the I/O page, it is used to access I/O data and configure parameters. Figure 4-11 I/O page interface(WF-2026) 02、Connection with Modbus TCP utility a.
  • Page 42 c. The following Modbus command function codes are available for WF-2000 series control. Table 4-1 Modbus request command list FC1 Read FC2 Read FC3 Read FC4 Read FC16 Write FC15 Force multiple coils multiple input multiple multiple input multiple Request multiple coils status (0xxxx) for discrete (1xxxx)
  • Page 43 Figure 4-17 Read multiple registers (4xxxx) for AO Figure 4-18 Write multiple registers (4xxxx) for AO WF-2000 Series AIO User’s Manual (Ver. 1.2, May./2014) ------------- 43...

  • Page 44: Modbus Applications

    5. Modbus Applications The WF-2000 is a Modbus device that allows you to access terminals data via Wi-Fi and communicates using a master-slave technique in which only one device (the master) can initiate transactions (called queries). The other devices (slaves) respond by supplying the requested data to the master, or by taking the action requested in the query.

  • Page 45: Mbap

    Modbus/TCP Application Data Unit Transaction ID Protocol ID Length Unit ID FCode Data (2 bytes) (2 bytes) (2 bytes) (1 bytes) (1 bytes) (0 to 252 bytes) MBAP Header Protocol Data Unit Figure 5-1 Modbus/TCP Application Data Unit 5.2.1 MBAP The Modbus/TCP extension includes 7 additional bytes to the original Modbus protocol, which allows for transport over the TCP/IP layers.

  • Page 46: Data

    Table 5-2 Supports Function Codes of WF-2000 series Function Code Descriptions 01 (0x01) Read Coil Status 02 (0x02) Read Input Status 03 (0x03) Read Holding Registers 04 (0x04) Read Input Registers 05 (0x05) Force Single Coil 15 (0x0F) Force Multiple Coils 16 (0x10) Preset Multiple Registers Any other function code request will be returned with an error...

  • Page 47: Data Encoding

    For example a client can read the ON/OFF states of a group of digital input or output or it can read/write the data contents of a group of registers. When the server responds to the client, it uses the function code field to indicate either a normal response or that some kind of error occurred (called an exception response).

  • Page 48: Address Mapping

    Table 5-4 A 16-bits word item Value 0x1234 0x12 0x34 5.3 Address Mapping 5.3.1 WF-2017 I/O Address Mapping Table 5-5 (3xxxx) AI address Begin Address Points Descriptions Range Access Type -32768 ~ +32767 (Bipolar) 30001 1~16 Analog Input 0 ~ +65535 (Unipolar)

  • Page 49: Wf-2026 I/O Address Mapping

    Table 5-8 (4xxxx) AO address Begin Address Points Descriptions Range Access Type 1= Reset System 40248 Reset System 247= Restore to Factory Default Settings 5.3.3 WF-2026 I/O Address Mapping Table 5-9 (3xxxx) AI address Begin Address Points Descriptions Range Access Type -32768 ~ +32767 (Bipolar) 30001 Analog Input...

  • Page 50: Troubleshooting

    6. Troubleshooting Item Problem Description Solution Power Failure 1. Please return to the ICP DAS for inspection and (PWR LED Off) repair 1. Make sure that the service set identifier device (SSID) settings are the same. 2. Make sure Wi-Fi transmission Channel settings are the same.

  • Page 51: Technical Support

    Item Problem Description Solution Cannot execute WF-2000 Because the ICP DAS WF-2000 Utility(v2.0 or later) Utility(v2.0 or later) with the requires .NET Framework v4.0,this program will message like the following automatically detect the .NET Framework v4.0 Figure 6-1 installed as well or not. Users can install .NET Framework v4.0 in the following website.

  • Page 52: Analog Input Type And Data Format Table

    Appendix A. A.1 Analog Input Type and Data Format Table Type Code Input Range Data Format +F.S -F.S Engineering Unit +15.000 -15.000 -15 to +15 mA 2’s comp HEX 7FFFh 8000h Engineering Unit +50.000 -50.000 -50 to +50 mA 2’s comp HEX 7FFFh 8000h Engineering Unit...
  • Page 53 Type Code Data Format +F.S -F.S Input Range Engineering Unit +1.0000 -1.0000 -1 to +1 V 2’s comp HEX 7FFFh 8000h Engineering Unit +500.00 -500.00 -500 to +500 mV 2’s comp HEX 7FFFh 8000h Engineering Unit +150.00 -150.00 -150 to +150 mV 2’s comp HEX 7FFFh 8000h...

  • Page 54: Analog Output Type And Data Format Table

    Type Code Data Format +F.S -F.S Input Range Type N Engineering Unit +1300.0 -0270.0 Thermocouple 2’s comp HEX 7FFFh E56Bh -270 to 1300°C Type C Engineering Unit +2320.0 +0000.0 Thermocouple 2’s comp HEX 7FFFh 0000h 0 to 2320°C Engineering Unit +20.000 +00.000 0 to +20 mA...

  • Page 55: Cjc (Cold Junction Compensation) Definition

    A.3 CJC (cold junction compensation) Definition Type Input Range Data Format +F.S -F.S Engineering Unit +100.00 -030.00 -30 to +100 ℃ 2’s comp HEX 03E8h FED4h WF-2000 Series AIO User’s Manual (Ver. 1.2, May./2014) ------------- 55...
