SENSOR 500
Dedicated Network services telephone

User guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SENSOR 500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AUDIOLINE SENSOR 500

Summary of Contents for AUDIOLINE SENSOR 500

  • Page 1: User Guide

    SENSOR 500 Dedicated Network services telephone User guide...
  • Page 2 DORO AUDIOLINE...
  • Page 3 The SENSOR 500 is a dedicated network services telephone which is compatible with Caller display and Call Minder services. In addition it is also pre-programmed for access to other optional services. Up to 10 speed dial memories and a 20 name and number phonebook add to its versatility.

  • Page 4: Table Of Contents

    SENSOR 500 CONTENTS SENSOR 500 Installation ....3 Caller display ....9 Location of controls ..3 New numbers .

  • Page 5: Installation

    INSTALLATION SENSOR 500 LOCATION OF CONTROLS 1 Handset 14 Erase key 2 Curly cord socket 15 Scroll call list/phonebook, save 3 Wall mounting hook 16 Speed-dial/pre-programmed keys 4 Hook switch 17 Volume control for handset 5 Dial-Up key 18 Volume control for speaker...

  • Page 6: Batteries

    BATTERIES Four AAA 1.5V batteries (not supplied) are required for the phonebook memory and caller display list. When the batteries are low, the low battery indicator will be present on the display. P Disconnect the telephone from the telephone network. P Remove the screw from the battery compartment lid (on the base of the telephone) and insert the batteries, observing correct polarity.

  • Page 7: Wall Mounting

    WALL MOUNTING The phone can be wall mounted, using the bracket supplied. Use the bracket supplied to mark the position of screw holes on a wall. Drill the holes (check for hidden pipes, etc). Use the raw plug and screws provided, ensuring approximately 3 mm remain between the wall and the head of the screw.

  • Page 8: Display

    DISPLAY When the unit is in standby mode the display will show: the current date and time, if new calls have been received (if these have not been reviewed or answered) and the total number of calls on the call list. The display will also indicate if the batteries are low and require changing.

  • Page 9: Using The Telephone

    SENSOR 500 USING THE TELEPHONE MAKING A CALL A call can be made in several different ways, using the handset, on-hook dialling or headset USING the HANDSET 1. Lift the handset and wait for a dial tone. 2. Dial the phone number required.

  • Page 10: Last Number Redial

    LAST NUMBER REDIAL If the last number dialled was engaged or the call was not answered, it is possible to redial the number using the button. P Press and release . The telephone number will be dialled automatically. P When the called party answers, lift the handset (or headset) to converse. If the call is not answered, press and release It is also possible to lift the handset and then press the redial key.

  • Page 11: Caller Display

    CALLER DISPLAY SENSOR 500 Caller display allows you to see who is calling before you answer a call and to see who has called in your absence. When the service is implemented on your telephone line, seconds before your telephone rings the number of the incoming caller will appear on the display.

  • Page 12: Reviewing The Call List

    REVIEWING THE CALL LIST Scroll the memory with the keys The key scrolls from the oldest number. The key scrolls from the latest number. The time and date each call is received is shown on the display. If the number is stored in the phonebook the corresponding name is also shown.

  • Page 13: Erase Phone Number(S)

    ERASE PHONE NUMBER(S) You may erase a single number or all numbers on the call list. ERASE A SINGLE NUMBER P Scroll the call list until the number to be erased is shown on the display. P Press twice quickly, then release. ERASE ALL NUMBERS P Scroll the call list until a number is shown on the display.

  • Page 14: Speed Dial Memories

    SENSOR 500 SPEED DIAL MEMORIES Ten `One-touch’ speed dial memories are available. Memories 6-10 have been pre- programmed for easy access to and set up of Select services*. If required these memories can be re-programmed with numbers of your own choice following the procedure below.
  • Page 15 PHONEBOOK SENSOR 500 The telephone has a phone book where you can store 20 names and telephone numbers for easy access and fast dialling. When one of these phone numbers calls, both the name and number will be displayed. In stand-by mode the LED indicator will double flash and the display will alternate between NEW CALLS and VIP on the upper line.

  • Page 16: Store

    STORE NUMBER/NAME 1. Press and release . The display shows how many numbers/names are stored in the phonebook. 2. Press 3. Dial the number to be stored (16 digits maximum). 4. Press and release 5. Enter a name (15 letters maximum) by pressing the relevant keypad digit buttons once or several times (see page 13).

  • Page 17: Least Cost Routing

    For example: The SENSOR 500 can be programmed so all phone numbers that starts with e.g. 0 is changed to 95020; phone number 00 46 46 2805000 is then changed automatically to 9502 00 46 46 2805000.

  • Page 18: Programming

    PROGRAMMING 1. Press and hold until the display shows "LANGUAGE", then release. 2. Press and release . The display shows "LCR". 3. Press 4. The indication for OFF or ON is now flashing on the display. Press to turn the function ON.

  • Page 19: Examples

    SOME EXAMPLES OF LCR DIALLING EXAMPLE 1 Idea: All calls except local calls must be dialled using XYZ network.. Programming: Advantages: All mobile, international and long distance calls are made using XYZ by adding the prefix 9502 before each number that starts with 0. E.g. 046-280 5000 is changed to 9502 046-280 5000.

  • Page 20: Call Answering

    SENSOR 500 CALL ANSWERING From new, the Sensor 500 is pre-programmed for compatibility with the BT Call Minder answering service. To check your messages, simply press Play and your messages will be played to you. Whilst listening to your messages you can use the keys featured below to operate various options.

  • Page 21: Re-Program

    RE-PROGRAM FOR ALTERNATIVE CALL ANSWERING SERVICE If the pre-programmed keys are not compatible with your network operators answering service, it is possible to re-programme the keys. P Press P Press and hold down until the display shows text, then release. P Enter digit (s) to store.

  • Page 22: Miscellaneous

    Please note that this is a Premium Line number and all calls are charged at 50 pence per minute. Price correct at the time of going to press. Alternatively, you can write to: Technical Support Group, Doro-Audioline Ltd., 22 Walkers Road, North Moons Moat, Redditch, Worcestershire, B98 9HE.

  • Page 23: Guarantee

    GUARANTEE The SENSOR 500 is guaranteed for a period of 12 months from the date of purchase. In the unlikely event of a fault occurring during this period, please return it with a copy of the purchase receipt to your place of purchase.
