7.6.2 After sales service info
This menu provides access to After sales Service information:
- date of last access to installer menus
- the name of the company which provides the after sales
service, if entered during installation.
- the telephone number of the company which provides the after
sales service , if entered during installation.
7.7

Replacing a fuse

4
3
A
D
2
1
Key
1 Fuse
2 Control unit
3 Switch On (I) / Off (O)
4 Fuse holder
∙ Turn off the control unit (2) with the switch (3) in position (O).
∙ Turn off the power supply to the control unit (2) at the isolating
switch.
∙ Replace the fuse following the order (A) to (F).
∙ Turn on the power supply to the control unit (2) at the isolating
switch.
∙ Turn on the control unit (2) with the switch (3) in position (I).
8

Recycling and disposal

8.1

Recycle the packaging

∙ Sort the waste to separate those which can be recycled
(cartons, plastics...) from those that cannot (strapping ...).
∙ Recycle the product packaging according to all relevant
regulations.
8.2 Recycle or dispose the product and its
components
∙ Do not dispose of your product or any of its accessories in the
household waste.
∙ Make sure the old unit and any accessories are disposed of
properly.
∙ Observe all relevant regulations.
0020148679_00 - 11/12 - Glow-worm
B
C
E
F
INSTALLATION AND SERVICING
9

Technical data

Description
Transmission / reception
frequency
Transmission / reception
frequency with outdoor sensor
Transmission / reception
frequency with room thermostat
Average radio signal range in
open air (*)
Average radio signal range
indoors (*)
Control unit dimensions:
Height
Length
Depth
(*) Depends on the installation's conditions and the electromagnetic
environment.
Electricals
Power-supply voltage
Power cable gauge
eBUS connection cable gauge
Current
Delay fuse
Electrical protection
Electrical classifi cation
Surge category
Pollution rating
Contact outputs fed work
Action auto
Unité Control unit
MHz 868
MHz 15
MHz 10
m 100
m 25
mm 264
mm 290
mm 45
VAC/Hz 230/50
mm² 3 x 0.75
mm² 2 x 0.75
A 4.35
A 1
IP20
I
II
2
A 8
V 230
type 1.C
- 15 -
EN
