PARTS LIST OF MAIN UNIT

Ref. No. Part No. Part Name
1 GU-3412 DSP P.W.B. unit Ass'y
2 GU-3413 Power P.W.B. unit Ass'y
−
2-1 Power P.W.B. unit
−
2-2 OP/CL switch P.W.B. unit
−
2-3 LED P.W.B. unit
3 411 2005 009 Chassis
4 461 0706 127 Foot sheet
5 412 4921 003 PWB bracket
6 412 4922 002 Mecha. bracket
7 412 4923 001 Mecha. cover
8 105 1398 003 Back panel
9 445 0084 009 Cord bush
9 445 0056 008 Cord bush
10 144 2798 005 Front panel
11 146 2275 003 P. switch knob guide Ass'y
12 441 1959 005 Front sub panel
13 119 0096 004 Rubber key (C)
14 461 0740 002 Sheet
15 FG- 9000 Drive unit
16 113 1689 001 P. switch knob
17 102 0425 253 Top cover
21 415 0335 032 PWB support
22 445 0033 005 Wire clamp band
23 445 0123 009 Clamp band (PLT2I)
24 445 0122 000 Clamp plate (FCPI2)
31 206 2155 001 AC cord with connector
31 206 2089 106 AC cord with connector
32 203 6577 000 4P LC-VH connector cord
33 203 6577 013 4P LC-VH connector cord
34 204 6719 007 40P flat cable
35 204 6719 010 40P flat cable
41 513 3796 008 Fuse label
42 513 3744 018 Rating sheet
42 513 3744 005 Rating sheet
43 513 2303 007 Version label
44 513 1519 009 Manufac. date label
45 513 0985 003 Inst. label
46 513 3776 002 E3 label
47 513 2521 009 CE label
48 513 3384 009 C-UL mark US (813)
49 513 3253 004 C-tick label
50 513 3159 001 FCC/class B caution
59 475 1178 009 3 washer-B
Note : The symbols in the column "Remarks" indicate the following destinations.
E3: U.S.A. & Canada model
E2: Europe model
Remarks Q'ty Ref. No.
1 SCREWS
1
1
2
2
2
2
1
for E3 1
for E2 1
1
1
1
2
2
2
1
1
1
5
2
4
for E3 1
for E2 1
1
1
1
1
for E2 1
for E3 1
for E2 1
1
for E3 1
for E2 1
for E3 1
for E2 1
for E3 1
for E2 1
for E3 1
8
Part No. Part Name
51 473 7015 005 Screw 3X6 CBTS (S)-B
52 473 7002 005 Screw 3X6 CBTS(S)-Z
53 471 9050 020 Screw 3X6 FHHS-B
54 473 7508 017 Screw 3X10 CBTS(P)-B
55 471 3301 021 Screw 3X4 CBS-B
56 471 1204 036 Screw 2.6X8 CPS-NiB
57 471 1832 013 Screw 3X8 SEMS
58 477 0263 005 3P. swelling screw
DN-D9000
Remarks Q'ty
26
11
8
4
8
2
8
4
54
