SETTINGS...........3 SPEcIFIcaTIONS..............7 APPENDIX DIGITal EFFEcTS TaBlE............1 aPPlIcaTIONS.................2 DIMENSIONS................4 BlOcK DIaGRaMS..............5 Phonic preserves the right to improve or alter any information within this document without prior notice. POWERPOD 1062 PLUS / 1062R / 1062FR / 1082 PLUS / 1082R...
6. Plug the supplied ac cable into a power outlet of a suitable voltage. ● Powerpod 1062 Plus/R: 600W + 600W / 4 ohm amplifier for 7. Turn the power switch on. main l & R or main / monitor ●...
(and possibly an equalizer) and then to a floor monitor speaker allows artists to monitor their own instruments or vocals whilst performing, or an engineer to monitor the mix. POWERPOD 1062 PLUS / 1062R / 1062FR / 1082 PLUS / 1082R...
NB. Using incorrect voltages can cause irreversible damage to the mixer. all care must be taken in selecting the voltage appropriate to your zone. If unsure of local voltage levels, contact a knowledgeable source before using this mixer. POWERPOD 1062 PLUS / 1062R / 1062FR / 1082 PLUS / 1082R...
Monitor signal (when the EQ switch is in the appropriate position it becomes the Main left EQ, where the lower equalizer is for the Main l-R signal. POWERPOD 1062 PLUS / 1062R / 1062FR / 1082 PLUS / 1082R...
Page 9
Monitor outputs. 37. Main Level Control This rotary control allows the user to adjust the final signal level sent to the Main l-R and Speaker outputs. POWERPOD 1062 PLUS / 1062R / 1062FR / 1082 PLUS / 1082R...
Page 10
Random – Enables random playback of files in current folder or root. put channels. 2. Users may experience very short instances of drop outs during playback of recorded WAV files. POWERPOD 1062 PLUS / 1062R / 1062FR / 1082 PLUS / 1082R...
Phonic, at its option, shall repair or replace the defective unit covered by this warranty. Please retain the dated sales receipt as evidence of the date of purchase.
Page 13
TaBla DE EFEcTOS DIGTalES..........1 aPlIcacIONES................2 DIMENSIONES................4 DIaGRaMaS DE BlOQUE............5 Phonic se reserva el derecho de mejorar o alterar cualquier información provista dentro de este documento sin previo aviso. POWERPOD 1062 PLUS / 1062R / 1062FR / 1082 PLUS / 1082R...
Page 14
POWERPOD 1062 PLUS / 1062R / 1062FR / 1082 PLUS / 1082R...
Selector de Voltaje de la parte posterior de la unidad. CARACTERÍSTICAS 6. conecte el cable de ac al toma corriente de voltaje compatible. ● Powerpod 1062 Plus/R: 600W + 600W / 4 ohm amplificador para 7. Encienda la unidad. main l & R o main / monitor ●...
1/4” de dispositivo a la entrada izquierda estéreo (mono) y deja la entrada derecha sin conexión. la señal se duplicará al canal derecho debido al milagro de la normalización de jack. POWERPOD 1062 PLUS / 1062R / 1062FR / 1082 PLUS / 1082R...
Se deberá de tener todos los cuidados para que los voltajes sean adecuados. Si no está seguro de los niveles de voltaje local, contactese con una fuente conocida antes de usar esta mezcladora. POWERPOD 1062 PLUS / 1062R / 1062FR / 1082 PLUS / 1082R...
El botón PaD -25, localizado arriba del jack de audífono de 1/4” de los canales mono, es utilizado para atenuar la señal de entrada en 25dB. Esto solo deberá activarse cuando se utilizan dispositivos de entrada de nivel de línea. POWERPOD 1062 PLUS / 1062R / 1062FR / 1082 PLUS / 1082R...
Page 19
Main/Monitor- tomando las señales monitor y main y las direcciona a las salidas del altavoz apropiadas - Main l / Main R - utilizando la señal Main l/R para alimentar las salidas de altavoz POWERPOD 1062 PLUS / 1062R / 1062FR / 1082 PLUS / 1082R...
Page 20
2. los usuarios pueden experimentar interrupciones muy cortas durante la reproduccion de archivos WaV grabados. POWERPOD 1062 PLUS / 1062R / 1062FR / 1082 PLUS / 1082R...
MICRÓFONO MICROPHONE MICRÓFONO CD PLAYER BASS GUITAR REPRODUCTOR DE CD GUITARRA BASS FLOOR MONITORS MONITORES DE PISO FLOOR MONITORS FOH MAIN SPEAKERS MONITORES DE PISO ALTAVOCES PRINCIPALES FOH POWERPOD 1062 PLUS / 1062R / 1062FR / 1082 PLUS / 1082R...
Page 25
ELECTRIC GUITAR GUITARRA ELÉCTICA SIDE FILL ACTIVE SPEAKER OR ANOTHER PA SYSTEM ALTAVOZ ACTIVO DE RELLENO LATERAL U OTRO SISTEMA PA RIGHT SPEAKERS LEFT SPEAKERS ALTAVOCES DERECHOS ALTAVOCES IZQUIERDOS POWERPOD 1062 PLUS / 1062R / 1062FR / 1082 PLUS / 1082R...
471 mm (18.5") 285 mm (11.2") 285 mm (11.2") 275 mm (10.8") 275 mm (10.8") * All measurements are shown in mm/inches. Todas las medidas están mostradas en mm/pulgadas. POWERPOD 1062 PLUS / 1062R / 1062FR / 1082 PLUS / 1082R...
BLOCK DIAGRAMS DIAGRAMAS DE BLOQUE Powerpod 1062 Plus POWERPOD 1062 PLUS / 1062R / 1062FR / 1082 PLUS / 1082R...
Page 28
Powerpod 1082 Plus CH1_6 L CH1_6 L CH1_6 R CH1_6 R CH1_6 MON CH1_6 MON MAIN L MAIN L MAIN R MAIN R POWERPOD 1062 PLUS / 1062R / 1062FR / 1082 PLUS / 1082R...
Page 29
CH1_6 L CH1_6 L CH1_6 R CH1_6 R CH1_6 MON CH1_6 MON MAIN L MAIN L MAIN R MAIN R REC L REC L REC R REC R POWERPOD 1062 PLUS / 1062R / 1062FR / 1082 PLUS / 1082R...
