Control panel the fitting is installed used and serviced correctly and safely. Menu setting CLAY PAKY S.p.A. disclaims all liability for damage to the fitting or to other property or persons deriving from installation use and Maintenance maintenance that have not been carried out in conformity with this instruction manual which must always accompany the fitting.
SAFETY INFORMATION • Installation Make sure all parts for fixing the projector are in a good state of repair. Make sure the point of anchorage is stable before positioning the projector. The safety chain must be properly hooked onto the fitting and secured to the framework, so that, if the primary support system fails, the fitting falls as little as possible.
INSTALLATION AND START-UP Installing the projector - Fig. 4 The projector can be installed on the floor resting on special rubber feet, on a truss or on the ceiling or wall. WARNING: with the exception of when the projector is positioned on the floor, the safety cable must be fitted. Cod. 105041/003 available on request). This must be securely fixed to the support structure of the projector and then connected to the fixing point at the centre of the base.
CONTROL PANEL Mains Connecting to the mains supply - Fig. 6 Connecting to the control signal line (DMX) - Fig. 7 Use a cable conforming to specifications EIA RS-485: 2-pole twisted, shielded, 120Ohm characteristic impedance, 22-24 AWG, low capacity. Do not use microphone cable or other cable with characteristics differing from those specified.
Page 6
Reversal of the display - Fig. 9 To activate this function, press UP and DOWN keys simultaneously while the display is in the rest mode. This status will be memorised and maintained even for the next time it will be switched on. To return to the initial state, repeat the operation all over again. Setting the projector starting address On each projector, the starting address must be set for the control signal (addresses from 1 to 512).
MENU SETTING Main Menu Level 1 Level 2 Level 3 Choices / Values DMX Address 001-512 Standard Channel Mode Vector Fixture ID 000-255 Disabled Control Protocol Art-net IP 2.x.x.x. Art-net IP 10.x.x.x. Ethernet Interface Disabled Repeat on DMX Enabled on primary Universe 000-255 Lamp DMX...
Page 8
Main Menu Level 1 Level 2 Level 3 Choices / Values System Errors Read / Reset Total Hours Read Fixture Hours Partial Hours Read / Reset Total Hours Read Lamp Hours Partial Hours Read / Reset Total Strikes Read Lamp Strikes Partial Strikes Read / Reset CPU brd...
Page 9
SET UP MENU DMX ADDRESS PLEASE NOTE: Without the DMX input signal, the displayed address (DMX Address) blinks. It lets you select the address (DMX Address) for the control signal. A DMX address between 001 and 512 can be selected. CHANNEL MODE This lets you select the projector operating mode, selecting one of the two available modes: Standard (29 DMX channels occupied, see Channel Function)
Page 10
OPTIONS MENU LAMP DMX It lets you enable (ON) the lamp remote control channel. Select OFF to turn off or disable this option. SAFETY BLACK OUT This allows the Dimmer's automatic lock option to be activated (ON) after 3 seconds with no incoming DMX signal.
Page 11
COLOR CMY short-cut It lets you optimise (ON) the color change time of the color wheel since the disk rotates in the direction that requires the shortest and thus quickest movement. Select OFF to turn off or disable this option. Linear Movement It lets you enable (ON) the linear color wheel movement.
Page 12
SETTINGS Used to save 3 different settings of the items in the option menu and relevant submenus. Default preset (*) User preset 1 User preset 2 User Preset 3 Load preset 'X’ is used to recall a previously stored configuration. Save to preset ‘X’...
Page 13
INFORMATION MENU SYSTEM ERRORS It displays a list of errors that occurred when the projector was turned on. To reset the SYSTEM ERRORS list, press OK. A confirmation message appears (Are you sure you want to clear error list?). Select YES to confirm reset. From the menu FIXTURE HOURS It lets you view projector working hours (total and partial).
Page 14
DMX MONITOR It lets you view the level of projector DMX channels in bit (Val) and in percent. FANS MONITOR It lets you view the speed of each fan installed in the projector: Lamp (lamp cooling fan) Pwr.Sup (PSU cooling fan) HEAD POSITION It lets you view the projector head position with reference to the X, Y and Z axes.
Page 15
MANUAL CONTROL LAMP It lets you turn the lamp on (ON) or off (OFF) from the projector control panel. RESET It lets you reset the projector from the projector control panel. CHANNEL It lets you set the channel DMX levels from the projector control panel (value between 0 and 255 bit or between 0% and 100%).
MAINTENANCE 1/4 Turn 1/4 Turn Locking and releasing Pan and Tilt movements - Refer to the instructions in the UNPACKING AND PREPARATION section. Opening the head covers - Fig. 10. Closing the head covers - Fig. 11. MYT OS...
Page 17
- The original gobos have a special coating designed specifically to resist to the high temperatures in the Prima Supersharpy; - The rotating gobo wheel only use dichroic glass gobos (it is not possible to use metal gobos); - For more information contact Clay Paky; - Fig. 13 MYT OS...
Page 18
Battery removal - Fig. 14 This product contains a rechargeable lead-acid or lithium iron tetraphosphate battery. To preserve the environment, please dispose the battery at the end of its life according to the regulation in force. LiFePO4 MYT OS...
TECHNICAL INFORMATION Power supplies available IP20 protection rating Zoom IN&OUT 115/230V 50/60Hz • Protected against the entry of solid bodies larger 455 (17.91") than 12mm (0.47”). Input power • No protection against the entry of liquids. 700VA a 230V 50Hz. Zoom IN CE Marking 408 (16.06")
CHANNEL FUNCTION NB: To prevent accidental breakage of the effects, which could collide with each other during transport, MYTHOS before switching the projector OFF check that all the projector Channels have been excluded (DMX level = 0%). CHANNEL MODE CHANNEL STANDARD VECTOR CYAN COLOUR WHEEL...
Page 21
Channel Mode Function Value Standard Vector CYAN COLOUR WHEEL 0 - 255 Linear Cyan movement MAGENTA COLOUR WHEEL 0 - 255 Linear Magenta movement YELLOW COLOUR WHEEL 0 - 255 Linear Yellow movement COLOUR 1 Empty position Empty + Frost Frost Frost + Lavender Lavender...
Page 22
Channel Mode Function Value Standard Vector COLOUR 3 Empty position Empty + Green Green Green + Pink Pink Pink + Aquamarine Aquamarine Aquamarine + Orange1 Orange1 Orange1 + Orange2 Orange2 STOPPER / STROBE 0 - 3 Light OFF Strobe at linearly variable frequency 4 - 103 from low (1 flash/sec) to high (25 flashes/sec) 104 - 107...
Page 24
Channel Mode Function Value Standard Vector ANIMATION DISK INSERTION 0 - 255 Linear Animation Disk Insertion ANIMATION DISK ROTATION Continuous animation disk clockwise rotation at linearly variable speed 0 - 124 from fast (120 rpm) to slow (4.4 rph) 125 - 130 Stop rotation Continuous animation disk counter-clockwise rotation at linearly 131 - 255...
Page 25
Channel Mode Function Value Standard Vector PRISMS ROTATION 0 - 21 Prism indexing: 0° to 90° range 21 - 42 Prism indexing: 90° to 180° range 42 - 63 Prism indexing: 180° to 270° range 63 - 84 Prism indexing: 270° to 360° range 84 - 105 Prism indexing: 360°...
Page 26
Channel Mode Function Value Standard Vector RESET 0 - 25 Unused range Zoom Reset 26 - 76 Zoom Reset sequence is activated passing through the unused levels range and staying in this range for 5 seconds Pan / Tilt Reset 77 - 127 Pan/Tilt Reset sequence passing through the unused levels range and staying in this range for 5 seconds.
Page 27
TIME TABLE Seconds Seconds Seconds Seconds Seconds Seconds Full 10.2 10.4 10.6 Follow cue Data MYT OS...
