About This User Guide

C ,
The following notices are found in this User Guide:
AUTIONS
W
ARNINGS AND
N
OTICES
M I ,
Menu items, icons, and instructions found in the procedures in this User
ENU TEMS
B ,
Guide are set apart by capitalizing them exactly as shown on screen.
UTTONS
I
Examples are the Start menu, Dashboard, Tablet and Pen Settings icon, and
CONS
Apply buttons.
W
Writing on the Motion Tablet PC digitizer display in this User Guide refers
RITING ON
D to any hand-written input using the specially-designed Motion digitizer pen,
THE ISPLAY
provided. The display responds only to this pen and not to any other type of
pen or to a stylus or other device such as those used with personal digital
assistants (PDAs). The display surface may be damaged by ink pens or other
pointed objects.
I
The term ink refers to digital ink, i.e., text entered in handwritten format and
NK
converted to an object that can be displayed exactly as you write it.
R
Notations for using the Motion Digitizer Pen, which are found throughout
EFERENCES
U
this User Guide, are described below:
TO SING THE
P
EN AND
•
P F
EN UNCTION
B
UTTON
•
•
•
•
•
T B / The Microsoft Windows task bar is on the lower-left of the display; the
ASK AR
S T
system tray (or notification area) is on the lower right, near the clock.
YSTEM RAY
WARNING: Text set off in this way indicates that failure to follow
directions in the warning could result in bodily harm or loss of life.
CAUTION: Text set off in this way indicates that failure to follow
directions in the CAUTION could result in damage to the equipment or
loss of information.
IMPORTANT: Text set off in this way presents information or instructions that
should be followed or information of particular interest.
NOTE: Text set off in this way presents information or instructions.
Tap — Tap the pen on the Tablet PC display, without pressing the func-
tion button on the pen
Double-tap — Double-tap the pen on the display, without pressing the
function button on the pen
Right-click — Press the function button on the pen and tap the pen on the
display (equivalent to a mouse right-click)
Press and hold — Press and hold the tip of the pen to the display, without
pressing the function button on the pen (same as a mouse right-click)
Tap and drag — Tap and drag the pen on the display
Select/Highlight — Tap on the item on the Tablet PC display with the
pen to activate the function; to select a line of text, tap and drag the pen
across the text to highlight it
Motion Computing M1400 Tablet PC User Guide iii
