  • Page 1: Instruction Manual

    Wild Camera DENVER WCT-3004 Instruction Manual WWW.DENVER-ELECTRONICS.COM ENG-1...

  • Page 2: Table Of Contents

    Table of Contents Instructions ....................3 1.1 General Description ................3 1.2 Camera Body Interface ................3 1.3 Camera components and features ............3 1.4 Remote Control ..................4 1.4.1 Navigating ..................4 1.5 Shooting Information Display ..............5 1.6 Supported Format ................... 5 Cautions ......................

  • Page 3: Instructions

    1. Instructions 1.1 General Description This digital trail camera is a surveillance camera working automatically. It can be triggered at once by any movement of human (or animals) in a certain region of interested (ROI) monitored by a high sensitive Passive Infrared (PIR) motion sensor, and then automatically captures high quality pictures (up to 12M pixels) or records FHD video clips (WVGA or QVGA).

  • Page 4: Remote Control

    1.4 Remote Control The remote control is an input device of the camera and is primarily used for customer settings and password input. This is an infrared type wireless remote control. The maximum remote distance is 9 meters. There are fifteen buttons on the remote control.

  • Page 5: Shooting Information Display

    Select Item (UP) Display Menu Selection Exit (MENU) (OK) Select Option Select Option (Left) (RIGHT) Select Item (DOWN) 1.5 Shooting Information Display When the camera is turned on (the power switch is slid to TEST position), the shooting information will be displayed in the monitor. 3.

  • Page 6: Easy Operation

    It is recommended to format the SD-card by the camera when used at the first time. The camera will be in USB mode when connected to a USB port of a computer. In this case, the SD-card functions as a removable disk. Please ensure sufficient power when having firmware upgrade, otherwise the upgrade process could be interrupted incorrectly.

  • Page 7: Insert The Sd-Card

    3.2 Insert the SD-card Insert SD-card into the card slot with marked side upwards. Please note that the SD-card can only be plugged in one direction. Make sure that the write-protect switch of the SD-card is on the “write” position. 3.3 Power on and Enter into the ON Mode Before switching on, please pay attention to the following: 1.

  • Page 8: Advanced Operations

    4. Advanced Operations From the basic operations of the camera in previous chapter, we know that the camera has three basic operation modes: 1. OFF mode: Power switch is at OFF position (Right). 2. ON mode: Power switch is at ON position (Left). 3.

  • Page 9: System Setting

    4.1.1 System Setting 4.1.2 Camera Setting ENG-9...

  • Page 10: Video Setting

    4.1.3 Video Setting 4.1.4 Default Default Settings are listed as below: Setting Default Items Mode Camera Camera, Video, Camera&Video Resolution 8MP,5MP,3MP Interpolated (Camera) Interval 1 Seconds 5-30 Seconds,1-30 Minute Multi Single Single,3,6,9 Pictures auto 100,200,400 Resolution 1080P 1080P,720P,WVGA,QVGA (Video) Video Length 10s,30s,60s,90s YY/MM/DD,MM/DD/YY,DD/MM/YY Date/Time...

  • Page 11: Format Sd-Card

    c) Press RIGHT to select Video. d) Press ok the select switch to save the current setting. Press MENU to cancel setting and return to info display. 4.1.7 Format SD-Card The system will delete all images or videos stored in the SD-card after formatting, make sure that you have made a backup of important data.

  • Page 12: Set Multi

    d) Press OK to Display Date/Time Interface, Press UP and DOWN to change the digit. Press LEFT and RIGHT to slide to next item e) Press OK to save all current setting, then press MENU to return to info display. 4.1.11 Set Multi This Item affects the number of pictures per each triggering in the camera or camera+video mode.

  • Page 13: Set Timer

    e) Press OK switch to save the current setting, then press MENU to return to info display. 4.1.16 Set Timer This parameter defines a certain camera working time in a day. In the rest of the time the device is shut off. The effective value of the hour ranges from 0 to 23 while the minute ranges from 0 to 59.

  • Page 14: File Numbering

    b) Press Menu to select Delete. c) Press right to select delete current or delete all. d) Press OK, Cancel and OK are prompted. e) Press OK to delete the image or video. Press cancel to cancel, then press MENU and press down the select switch to return to info display.

  • Page 15: Appendixⅰ: Technical Specifications

    AppendixⅠ: Technical Specifications Image Sensor 3 Mega Pixels Color CMOS Memory SD Card to 32 GB Lens F=3.1; FOV=120 ° Size 145 mm * 80 mm * 55 mm IR Filter Full Automatic IR Filter TFT Display Screen 2.0 inch Black Invisible 940 nm PIR Distance High/Normal/Low...
  • Page 16 ALL RIGHTS RESERVED, COPYRIGHT DENVER ELECTRONICS A/S Electric and electronic equipment contains materials, components and substances that can be hazardous to your health and the environment, if the waste material (discarded electric and electronic equipment) is not handled correctly. Electric and electronic equipment is marked with the crossed out trash can symbol, seen below.
