Summary of Contents for Ophit DQSP
- Page 1 DQSP Thank you for purchasing DQSP Optical DVI dual link extender DQSP extends DVI dual link signal up to 300M using two strand s of multi -mode optic fiber. It support single-link and dual-link DVI resolutions up to 3840x2160. www.ophit.com...
- Page 2 2. Connect the Receiver module to the display. (3) User’s Guide 3. Connect two strands of multi-mode SC terminated If any of these items are missing in your package, contact OPHIT or fiber optic cable(50/125㎛) from the Transmitter to the Receiver your supplier for support.
- Page 3 User’s Guide Installation LED indicator status 4. Connect the included +5V DC power supply into both Display Transmitter and Receiver module. Only external power 5. Blue LED indicator on the modules will be light up connected(or Tx powered No Display via source power) after all connections are completed.
- Page 4 Warranty We, OPHIT hereby warrant the final purchase of our product as follows. In the case of troubles on our products, please contact the shop purchased. One year limited warranty Our customers have right to be served with free of charge when there is trouble in this product during 1(one) year from the day purchased.
- Page 5 RMA Request Form No.: Customer Name: Return Date: Company Name: Phone: Model Name: E-Mail: Serial No: Place of Purchase: Address: (For RMA Return) RMA details: (Please describe RMA status, application used and failure symptom) www.ophit.com...
- Page 6 Tel: +1 714 300 0540 Fax: +49(0) 6104 64398 11 Fax: +44(0) 208 546 3931 Fax: +1 714 300 0546 E-mail: leon.bang@fsnmed.eu E-mail: christian.elfert@fsnmed.eu E-mail: sshin@fsnmed.com www.ophit.com REV. 1.0 © 2014 OPHIT CO., LTD. All rights reserved. Printed and designed in Korea...
