HSP Installation Guide ● Connection • Connect product transmitter to the HDMI port on your source device. • Connect product receiver to the HDMI port on your digital display device. • Connect Multi-mode SC type 1 Channel standard fiber-optic cable between transmitter and receiver. • Connect power adapter to the receiver which has been provided. *Connecting power adapter to the transmitter is option. (In the case of power shortage) • The Green LED will appear on the transmitter and receiver, after all the product connections are completed. - LED On : Power supply and Signal transfer - LED Blinking : Only Power supply, Signal not transfer(Connections are not completed) Adapter HDMI Port HDMI Port TRANSMITTER RECEIVER ● Contact us (OPHIT USA) Foreseeson Custom Displays, Inc. 2210E. Winston Road Anaheim, CA 92806 Tel : 714-300-0540, Fax : 714-300-0546, e-mail : sshin@foreseesonusa.com HSP.indd 2 2011-09-20 2:29:05...
Page 3
● Caution Use the DC adapter (5V, 2A) included in the product package for the receiver, which is connected to the display device and requires the external power supply. The transmitter connected to the source device normally used the power from source. Therefore, no external DC adapter is required except some device with the special specification. In this case, use the external DC adapter used for the transmitter. (Connect transmitter to adapter only in case of either insufficient power or no power from source device.) ● Troubleshooting - Check if the source device power is on. Screen is not displayed. - Check if connections to the source and display device are correct. - Turn the source device power off and on again. - C heck the HDMI connection. Noise is shown on the screen. - C heck the display resolution. - If the malfunction is not fixed by the above measures, please contact with the A/S center. HSP.indd 3 2011-09-20 2:29:05...
HSP Installation Guide ● Precautions for safety Make sure to comply with precautions to prevent danger and damage on the property through proper usage product. If precautions are ignored, if may incur If precautions are ignored, if may incur decease or serious injury. decease or serious injury. Warning Caution ● Warnings 1. Do not plug in several power cords. It can cause overheating and a fire. 2. Do not bend the power cord by force, or do not put heavy object on the power cord to prevent breakdown. It can cause a fire. 3. Do not touch the power plug with wet hands. You may be struck by electricity. 4. Insert the power plug firmly to avoid shaking. If not inserted firmly, It can cause a fire. 5. Do not disassemble, repair of modify. It can cause a fire and an injury by electrical shock due to abnormal operation. 6. Do not insert a metallic material (hair pin or ironware) or combustible foreign object (match, paper and so on) into the terminal hole, or drop the terminal. It may cause a fire and an injury by electrical shock, 7. Do not put vase, flowerpot, cup, cosmetics, medicines and container filled with water near the product. It may cause a fire and an injury by electrical shock, or injury by dropping. 8. Stay away from the direct sunlight and the heat source like the heater. It may cause a fire. 9. Do not spray water on the product. It may cause a fire and an injury by electrical shock. Scrub the product surface softly with a dry towel.
● We, OPHIT hereby warrant the final purchase of our product as follows. ● In the case of troubles on our products, please contact the shop purchased. Name of products Name of Model Date Purchased Day Month Year Serial No. Shop purchased One year limited warranty Our customers have right to be served with free of charge when there is trouble in this product during 1(one) year from the day purchased. Out of warranty services When you request services (in the case of non manufacturing defects but the troubles by misusage), may served with charge as follows. ● defects of products caused by accident, disaster ● damages of products caused by the customer’s carelesseness or mistaken application ● damages of products caused by the application of the parts or products not supplied or sold by our company ● damages of products and related defects caused by not our staff or the men or group not nominated by us for services. The interchanged parts and products for maintenance services shall be replaced as new parts and products operating normally, and the inter-changed parts and products shall be subjected to our company. HSP.indd 5 2011-09-20 2:29:06...
Page 10
Benutzerhandbuch HSP ● Anschluss • Schließen Sie den Sender an den HDMI-Port Ihrer Signalquelle an. • Schließen Sie den Empfänger an den HDMI-Port Ihres digitalen Monitors/TV an. • Schließen Sie das standard einkanal multi mode SC Glasfaserkabel an Sender und Empfänger an. • Schließen Sie das mitgelieferte Netzteil an den Empfänger an. *Der Anschluss eines Netzteils an den Sender ist optional (bei ungenügender Stromversorgung durch die Signalquelle.) • Die grüne LED leuchtet an Sender und Empfänger auf, nachdem der Geräteanschluss abgeschlossen ist: - LED Ein: Netzversorgung und Signalübertragung - LED Blinkt: Netzversorgung und Signal wird nicht übertragen oder Adapter HDMI Port HDMI Port TRANSMITTER RECEIVER ● Contact us (OPHIT EUROPE) Foreseeson GmbH Benzstr. 9, 61352 Bad Homburg, Germany Tel : 49-6172-185310-10, Fax : 49-6172-185310-11, e-mail : jasonkwon@foreseeson.de HSP.indd 10 2011-09-20 2:29:09...
Page 11
● Vorsicht Nutzen Sie das mitgelieferte Netzteil (5V, 2A) zur Stromversorgung des Empfängers, der an den digitalen Monitor/TV angeschlossen wird. Dieser benötigt eine externe Stromversorgung. Der an die Signalquelle angeschlossene Sender nutzt normalerweise die Stromversorgung der Signalquelle. Deshalb ist kein externes Netzteil erforderlich, ausgenommen bei einigen Signalquellen mit besonderer Spezifikation. Schließen Sie in diesem Fall ein weiteres Netzteil (5V, 2A) an den Sender an. (Achtung: Schließen Sie das Netzteil nur an den Sender an, wenn die Stromversorgung durch die Signalquelle entweder unzureichend oder gar nicht vorhanden ist! Ansonsten kann der Sender durch Überspannung beschädigt werden!) ● Troubleshooting - Überprüfen Sie, ob die Signalquelle eingeschaltet ist. Kein Bild - Überpüfen Sie, ob alle Verbindungen korrekt hergestellt wurden. - Schalten Sie die Signalquelle aus und wieder ein. - HDMI Anschluss prüfen. Bild gestört - Anzeigeauflösung prüfen. - W enn die Funkionsstörung nicht durch die angeführten Maßnahmen behoben warden kann, wenden Sie sich an das Support-Center. HSP.indd 11 2011-09-20 2:29:09...
Page 12
Benutzerhandbuch HSP ● Sicherheitsvorkehrungen Stellen Sie sicher, dass Sie das Gerät immer gemäß der Anleitung und unter Beachtung aller Sicherheisthinweise betreiben. So schützen Sie sich vor Gefahren und vor materiellen schäden. Die Missachtung der Sicherheitshinwise kann zu Die Missachtung der Sicherheitshinwise kann zu schweren Verletzungen oder zum Tod führen. schweren Verletzungen oder zum Tod führen. Warnung Vorsicht ● Sicherheitshinweise 1. Verwenden Sie keine Verkettungen von Mehrfachsteckdosen. Dies kann zu Überhitzung und Bränden führen. 2. Biegen Siedas Netzkabel nicht übermäßig, und stellen Sie keine schweren Gegenstände darauf. Dadurch könnte das Netzkabel beschädigt warden. Dies kann zu Bränden führen. 3. Berühren Sie den Netzstecker nicht mit nassen Händen. Dies kann zu elektischen Schlände führen. 4. Stcken Sie den Netzstecker fest in eine Steckdose. Wenn Netzstecker nicht richtig sitzen, kann dies zu Bränden führen. 5. Nehmen Sie das Gerät nicht auseinander. Führen Sie keine Prparaturen oder Veränderungen am Gerät durch. Dies kann zu unnormalen Betrienszustanden und zu Bränden oder elektrischen Schlägen führen. 6. Führen Sie keine metallischen Gegenstände (Haarnadeln oder Eisenwaren) oder brnnbaren Fremdkörper (Streichhölzer, Papier usw.) in die Anschlussöffnung ein. Lasse Sie das Gerät nicht fallen. Dies kann zu Bränden und elektrischen Schlägen führen. 7. Halten Sie Vasen, Blunentöpfe, Tassen, Kosmetika, Arzneimittel und Behälter mit Wasser vom Gerät fern. Dies kann zu Bränden und elektrischen Schlägen sowie zu Verletzungen durch fallende Gegenstände führen. 8. Setzen Sie das Gerät keinem direkten Sonnenlicht oder einer Wärmequelle aus. Dies kann zu Bränden führen. 9. Spritzen Sie kein Wasser auf das Gerät. Dies kann zu Bränden und elektrischen Schlägen führen. Reinigen Sie die Oberfläche des Geräts nur mit elnem weichen, trockenen Tuch. 10. Verwenden Sie das mitgelieferte Gleichstrom-Netzteil nicht Spannungen außerhalb des angegebenen Bereichs. Dies kann zu Bränden führen.
Page 13
● We, OPHIT herby warrant the final purchase of our product as follows. ● In the case of troubles on our products, please contact the shop purchased. Name of products Name of Model Date Purchased Day Month Year Serial No. Shop purchased One year limited warranty Our customers have right to be served with free of charge when there is trouble in this product during 1(one) year from the day purchased. Out of warranty services When you request services (in the case of non manufacturing defects but the troubles by misusage), may served with charge as follows. ● defects of products caused by accident, disaster ● damages of products caused by the customer’s carelesseness or mistaken application ● damages of products caused by the application of the parts or products not supplied or sold by our company ● damages of products and related defects caused by not our staff or the men or group not nominated by us for services. The interchanged parts and products for maintenance services shall be replaced as new parts and products operating normally, and the inter-changed parts and products shall be subjected to our company. HSP.indd 13 2011-09-20 2:29:09...
Page 14
HSP 사용설명서 ● 연결 방법 • 제품의 송신부를 출력기기의 HDMI 포트에 연결합니다. • 제품의 수신부를 디지털 디스플레이의 HDMI 포트에 연결합니다. • 송신부와 수신부 사이에 멀티모드 SC타입 1채널 표준 광케이블을 연결합니다. • 지급되는 어댑터를 수신부에 연결합니다. *송신부 어댑터 연결은 선택사항입니다. (전원이 불충분할 경우) •...
Page 15
- 출력기기를 OFF 한 후 다시 ON을 하세요. - DC 어댑터가 연결되어 있는지 확인하세요. - HDMI 커넥터의 연결을 확인하세요. 화면에 노이즈가 보일 때 - 해상도를 다시 확인해 주세요. - 위와 같이 했음에도 조치가 되지 않을 경우 A/S 센터에 문의하세요. HSP.indd 15 2011-09-20 2:29:10...
HSP 사용설명서 ● 안전을 위한 주의사항 제품을 올바르게 사용하여 위험이나 재산상의 피해를 미리 막기 위한 내용이므로 반드시 지켜주시기 바랍니다. 지시사항을 위반할 시 사람이 사망하거나 지시사항을 위반할 시 사람이 부상을 입거나 경 주 고 의 중상을 입을 가능성이 예상되는 내용입니다. 물적 손해 배상이 예상되는 내용입니다.
Page 17
3) 그 밖의 경우 ● 천재지변(화재, 염해, 수해 등)에 의한 고장 발생시 ● 헤드세척 및 이물투입 서비스 요청시 ● 소모성 부품의 수명이 다한 경우(배터리, 형광등, 헤드, 진동자, 램프류, ● 네트워크 및 타사 프로그램 사용설명 필터류, 토너 드럼, 리본 등) HSP.indd 17 2011-09-20 2:29:10...
