- Page 1 User’s Guide DisplayPort Optical Extender DSFP Thank you for purchasing DSFP Optical DisplayPort pigtail module extender with DPCD support extends DisplayPort signal up to 1000M using single strand multi-mode optic fiber. It supports display resolution up to 2560x1600(WQXGA). www.ophit.com...
- Page 2 2. Connect the Receiver module to the display. (3) User’s Guide 3. Connect a single strand multi-mode SC terminated If any of these items are missing in your package, contact OPHIT or optic fiber(50/125㎛) from the Transmitter to the Receiver module. your supplier for support.
- Page 3 User’s Guide Installation Application 4. Connect the included +5V DC power supply into the Transmitter. 5. Connect the included +5V DC power supply into the Receiver. 6. Blue LED indicator on the modules will be light up after all connections are completed. ▶...
- Page 4 Warranty We, OPHIT hereby warrant the final purchase of our product as follows. In the case of troubles on our products, please contact the shop purchased. One year limited warranty Our customers have right to be served with free of charge when there is trouble in this product during 1(one) year from the day purchased.
- Page 5 RMA Request Form No.: Customer Name: Return Date: Company Name: Phone: Model Name: E-Mail: Serial No: Place of Purchase: Address: (For RMA Return) RMA details: (Please describe RMA status, application used and failure symptom) www.ophit.com...
- Page 6 Tel.: +49 (0)6172 185310 20 Tel: +1-714-300-0540 Fax : +44(0) 208 546 3931 Fax: +49 (0)6172 185310 11 Fax : +1-714-300-0546 E-mail: jasonkwon@foreseeson.de E-mail: christianelfert@foreseeson.de E-mail: sshin@foreseesonusa.com www.ophit.com REV. 1.0 © 2012 OPHIT CO., LTD. All rights reserved. Printed and designed in Korea...
