DAC IV Menu Tree
Top level menus are for
operational controls. Setup
menus follow on the next
pages.
Press the menu button on
either the front panel or
remote.
Navigate up and down the
options with the front panel
knob or the volume up down
buttons on the remote.
Use the arrow buttons to
navigate right and left in the
menus on either the front
panel or remote.
Use the * button on the front
panel or the > button on the
remote to select.
The default settings are
shown on the chart in bold
type.
Upsampling
Phase Invert
Filter Select
Upsampler
Select
About
Setup
12
Off
On
Off
On
F1-32x Filter
F2-16x Filter
F3-Lanczos 3
F4-Minimum
Phase
Temporary
U1 - Upsampler 1
U2 - Upsampler 2
U3 - Upsampler 3
Displays the DACs information. Including
serial number, distributor, year of
manufacture, and installed features.
GO TO NEXT PAGE
See page to for setup options
