Summary of Contents for Hisense HL55T36PZL
- Page 1 User’s manual Please read this manual carefully before operating your TV set and retain it for further reference. Model Number: HL55T36PZL Part Number: ES-G112612 Http://www.hisense.com.au...
- Page 2 4. Product Identification 10. Any unauthorised access to the internal hardware of the product will void a. Hisense reserves the right to reject claims for any services or work where this warranty. the Customer requesting such work or services from Hisense and/or its 11.
-
Page 3: Service Procedure
12 MONTHS IN HOME REPLACEMENT LCD WARRANTY* Hisense Australia will provide its nearest service centre for repairs or replacement under warranty. You will need to ensure that you have already called Hisense Warranty Centre and have received a JOB NUMBER. -
Page 5: Table Of Contents
Table of Contents Table of Contents Hisense Declaration................... Important safety precautions..............Safeguards..................Warning..................Setting Up....................Accessories................... Installing the Stand................ TV Front..................TV Rear..................Rear TV Connectors..............Connection Instructions..............Using the Remote Control............... Installing batteries................. The Remote Control Panel............Quick starts.................. -
Page 6: Hisense Declaration
Hisense reserves the rights to restrict the use or access of certain content or service. As the content and service are transmitted through third party’s network and transmission facilities, Hisense undertakes no customer... -
Page 7: Important Safety Precautions
Important safety precautions Safeguards This symbol alerts user about the presence of ATTENTION a dangerous voltage not isolated inside the product which can be sufficiently powerful to RISK OF SHOCK constitute a risk of electrocution. ELECTRIC This symbol alerts user about the presence of Do not open the back cover important operating instructions and In no case the user is allowed to operate inside the TV... - Page 8 Important safety precautions Safeguards Please read the following safeguards for your TV and retain for future reference. Always follow all warnings and instructions marked on the television. 1. A note about safety and operating instructions Read and follow all safety and operating instructions, and retain them safely for future reference. 2.
- Page 9 Important safety precautions Safeguards 12.Power Lines An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. Where installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
-
Page 10: Warning
Important safety precautions Warning If a television is not positioned in a sufficiently stable location, it can be potentially hazardous due to falling. Many injuries, particularly to children, can be avoided by taking simple precautions such as: ● Using cabinets or stands recommended by the manufacturer of the television. ●... -
Page 11: Setting Up
Setting Up Accessories/Installing the Stand Accessories list ALCD101 Batteries Remote Manual Book Installing the Stand Use the four screws ( which in accessories bag to fix the base plate and upright. U s e t h e o s c r e w s G B / T 8 1 8 - 2 0 0 0 M4X12 which in accessories bag to fix the... -
Page 12: Tv Front
Setting Up TV Front TV Front No. Component Component Description Press to turn the main power ON or OFF. POWER Switch Red indicates standby mode. Blue shows that the unit is on. POWER Indicator Remote sensor Receives signals from the remote control. Do not block. Press to turn your TV on or off (standby mode). -
Page 13: Tv Rear
Setting Up TV Rear TV Rear AC INPUT... -
Page 14: Rear Tv Connectors
Setting Up Rear TV Connectors Connectors Brief Description Cables ANT 75Ω Connect an outdoor VHF/UHF antenna Yellow Connect a composite video cable and left-right audio cables from optical equipment. White Yellow Connect a composite video cable and left-right audio cables from optical White equipment. -
Page 15: Connection Instructions
Setting Up Connection Instructions ■ Connecting an Aerial (For analogue and Digital signals) To view television channels correctly, a signal must be received by the set from the following source: -An outdoor VHF/UHF antenna -Before connecting any external device please connect the supplied 15 pin VGA to RCA adaptor. ■... - Page 16 Setting Up Connection Instructions ■ Connecting AUDIO -Connect RCA audio cables to “R -AUDIO - L” the cable supplied on the rear of your set and the other ends to corresponding audio in connectors on the Amplifier or DVD Home Theater. ■...
-
Page 17: Using The Remote Control
Using the remote Control Installing batteries Installing the remote control batteries 1. Slide open the battery cover on the back of the remote control. 2. Install two AAA size(1.5V) batteries. Match the “+” and “-” signs on the batteries to the signs on the battery compartment. -
Page 18: The Remote Control Panel
Using the Remote Control The Remote Control Panel The Remote Control Panel Buttons instructions(from up to down) (1) Remote sensing Window. (2) Indicator glows from white to orange when buttons are pressed. (3) D/A: Digital /Analog TV. (4) Power Standby: Power button(The red big button). (5) Source: Available source selection. -
Page 19: Quick Starts
Using the Remote Control Quick starts ■ Turning your TV on and off To turn your TV on: Connect the TV to an AC power outlet and an external antenna, then turn on the power via switch located below the front right hand side of unit. A few seconds later an image will appear on the screen. Setup wizard-select your state and press OK, Then press OK again to start the Tuning process. - Page 20 Using the Remote Control Quick starts ■ Selecting the picture mode ● To select a picture mode: Press the [Picture] button to select between 5 different pre-adjusted picture modes: Dynamic, Bright, Standard,Soft and User (configurable mode). The User mode automatically preserves your personal settings after adjusting brightness, colour and contrast etc.
-
Page 21: Changing The Tv Settings
Changing the TV Settings Using the Channel Menu Press [Menu] to open the main menu. CHANNEL Press [ / ] to select Channel, then press [ /OK] to Tuning Type DTV+ATV enter the Channel menu. Auto Tuning Press [ / ] to select an option. DTV Manual Tuning Press [ /OK] to enter the submenu. - Page 22 Changing the TV Settings Using the Channel Menu ■ Program Edit After you scan for channels, you can delete a channel from memory if you want to skip the channel when you press [▲/▼]. You can still select the skipped channels using the number buttons. You can also rename the channels, lock or unlock the channels from memory.
-
Page 23: Using The Picture Menu
Changing the TV Settings Using the Picture Menu PICTURE Press [Menu] to open the main menu. Colour Temperature Normal Noise Reduction Medium Press [ / ] to select Picture, then press [ /OK] to MEMC Normal enter the Picture menu. Press [ / ] to select an option. -
Page 24: Using The Sound Menu
Changing the TV Settings Using the Sound Menu Press [Menu] to open the main menu. SOUND Press [ / ] to select Sound, then press [ /OK] to Sound Mode Standard enter the Sound menu. Equalizer Press [ / ] to select an option. Balance Press [ / ] to adjust the option or press [ /OK] to Auto Volume... -
Page 25: Using The Option Menu
Changing the TV Settings Using the Option Menu OPTION Press [Menu] to open the main menu. DivX Setting Version Ver A070216 Press [ / ] to select Function, then press [ /OK] to enter the Function menu. OPTION Press [ / ] to select an option. Blue Screen Press [ / ] to adjust the option or press [ /OK] to Installation Guide... -
Page 26: Using The Lock Menu
Changing the TV Settings Using the Lock Menu Press [Menu] to open the main menu. LOCK Press [ / ] to select Lock, then press [ /OK] to enter Lock System the Lock menu. Change Password Press [ / ] to select an option. Block Program Press [ / ] to adjust the option or press [ /OK] to Parental Guidance... -
Page 27: Using The Screen Menu
Changing the TV Settings Using the Screen Menu Press [Menu] to open the main menu. Screen Press [ / ] to select Screen, then press [ /OK] to H.Position enter the Screen menu. V.Position Press [ / ] to select an option. H.Size Press [ / ] to adjust the option or press [ /OK] to V.Size... -
Page 28: Pc Setting
Changing the TV Settings PC Setting PC Setting Set the PC Software properly to match one of the below options. Supported VGA Modes: VGA____ (640×480 60Hz) SVGA___ (800×600 60Hz) XGA____ (1024×768 60Hz) SXGA___ (1280×1024 60Hz) Note: Your PC/Notebook may not be able to display some of these resolutions. Take Windows XP as an example, and the Windows system display setting is as illustrated: 1. -
Page 29: Using The Dmp Menu
Changing the TV Settings Using the DMP Menu Information Press [Source] to open Source menu. File Name: ISP_Tool_4505 _MSTPVR LTDN46T28GA Press [ / ] to select DMP, then press MOVIE [ /OK] to enter the DMP menu.(or press MUSIC 20070516_21_ tek00000.png tek00001.png PHOTE... - Page 30 Changing the TV Settings Using the DMP Menu ■ Watch a movie Select the MOVIE option. Press [▲/▼] to select a movie , press [OK] to enter, press [Play/Pause] to play the movie. Also you can select more than one movie at the same time,press [Play/Pause] to play all the movies one by one. Press [◄◄...
- Page 31 Changing the TV Settings Using the DMP Menu Tool Bar Menu: If you've opened a photo, press [Menu] to open the play menu Tool Bar , the following items are its operations: (1) - Back - chooses previous JPEG. (2) - Forward - chooses next JPEG. (3) - Rotates the photo clockwise.
-
Page 32: Appendix
Appendix Trouble shooting If you feel there's a problem with your TV, you can try turning off the TV then restart it. You can also check below chart of remedies. If the problem isn't resolved, please contact ph 1800 447 367. for further assistance. -
Page 33: Specifications
Weight without base(kg) 23kg Wall Mount size: 400mm x400mm Environmental Temperature 5˚C~35˚C Conditions Humidity : 20%-80%RH Humidity : 20%-80%RH Atmospheric pressure: 86kPa-106kPa Note: Hisense is committed to continued product improvement which may result in changes to specifications and appearance without previous notice. - Page 34 HL55T36PZL...
