Summary of Contents for Hisense H75B7530
- Page 8 Plastic bags can cause suffocation and the anti-moisture material is harmful if SIMPLIFIED EU DECLARATION OF CONFORMITY Hereby, Hisense Czech s.r.o declares that the radio equipment type [H75B7510/ H75B7530/H75B7550/H75B7570/H75BE7410/H75BE7430/H75BE7450/H75BE7470/ H75B7510UK/H75BE7410UK] is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://...
-
Page 9: Table Of Contents
Contents Apparatus with CLASS I construction shall be connected to a MAINS socket outlet with a protective earthing connection. Product image is only for reference, actual product may vary in appearance. Parts of the software function changes with the system upgrade. Contents Accessories List......................1 Installing the Stand or Wall mount bracket ..............2... -
Page 10: Installing The Stand Or Wall Mount Bracket
Installing the Stand or Wall mount bracket Installing the Stand CAUTION Be sure to disconnect the A/C power cord before installing a stand or Wall-Mount brackets. The LED display is very fragile, and must be protected at all times when installing the base stand. -
Page 11: Tv Front
TV Front TV Front Single button (Remote sensor / Power indicator / Standby) Item Description Receive remote signals from the remote control. Remote sensor Do not put anything near the sensor, as its function may be affected. Power indicator The light is red in standby mode. Press the single button when in standby mode, TV will be turned on. -
Page 12: Tv Rear
TV Rear TV Rear COMMON INTERFACE Power input HDMI 4 (4K@60Hz) VIDEO AV IN NOTES ANT2 Jack supports power supply for satellite antenna (13/18V, 0.5A max.) Check the jacks for position and type before making any connections. Loose connections can result in image or color problems. -
Page 13: Making Connections
Making Connections Wired setup LAN ( Connect your TV to your network by connecting the LAN port on the back of your TV to an external modem or router using a LAN (Ethernet/Cat 5) cable. See the illustration below. · We recommend to use a modem or router that supports Dynamic Host Configuration Protocol (DHCP). - Page 14 Making Connections Outdoor Antenna Cable ANT OUT ANT 1 DVB-T/T2/C (not included) Antenna Cable (75Ω) VHF/UHF Antenna ANT 2 DVB-S/S2 (not included) Satellite antenna Audio Amplifier/Speaker DIGITAL DIGITAL AUDIO OUT AUDIO OUT DIGITAL AUDIO cable (not included) Audio Amplifier/Speaker HDMI HDMI (ARC) HDMI...
- Page 15 Making Connections CAM CARD SMART CARD NOTES Before you insert/remove the CI+ module, ensure that the TV is switched off. Then insert the CI card into the CI+ module in accordance with the Service Provider’s instructions. COMMON Do not repeatedly insert or remove the Common Access INTERFACE Module as this may damage the interface and cause a malfunction.
-
Page 16: Remote Control
Remote Control POWER: Switch the TV on or into standby mode INPUT: Select input sources Number button: Direct channel selection or numbers input GUIDE: Display the Electronic Program Guide (DTV mode) Subtitle: Activate or deactivate the subtitle mode Special function buttons Display the Quick setup menu TXT: Turn on/off the teletext function / <... - Page 17 Remote Control Installing Batteries in the Remote Control 1. Slide the back cover to open the battery compartment of the remote control. 2. Insert two AAA size batteries. Make sure to match the (+) and ( - ) ends of the batteries with the (+) and ( - ) ends indicated in the battery compartment.
-
Page 18: Turning The Tv On For The First Time
Turning the TV on for the First Time Turning the TV on for the First Time 1. Connect the mains cable to the mains socket after you have completed all the connections. 2. The first time you turn the TV on, it will go straight into the Installation Guide. / <... -
Page 19: Specifications
Specifications Features, appearance and specifications are subject to change without notice. 75" Item 66.0 × 38.0 × 3.0 inches Without Stand (1676 × 965 × 77 mm) Dimension (W × H × D) 66.0 × 40.8 × 13.2 inches With Stand (1676 ×... -
Page 20: Other Information
Other Information Recycling/Licenses WEEE (Waste Electronic Electric Equipment) European Directive 2012/19/EU This symbol on the product or on its packaging indicates that this product must not be disposed of with your household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
