Card Tab:

Image Size

Allows the customer to choose between Full bleed
edge to edge setting, with the whole surface of the
card printed, or printed with a white border around the
edge of the card.

Card Orientation

Either landscape or portrait.
o
Flip Front / Back 180
Changes the orientation of the print as it is transferred
to the card.

Colours Tab:

Gamma Curve

Set to 'Default' to give a boost to mid-tone colours, -
good for photos etc, or to 'None' for a linear colour
output.

RGB Adjustment button

Allows you to adjust the image colour contrast and
intensity levels, these changes apply to the whole
card and not just the pictures.
Intensity
Increase or decrease the image intensity by moving
the RGB sliders left or right. This will change the
overall lightness or darkness of the individual colour
on the image.
Contrast
Magnifies or minimises the difference between the
light and dark parts of the image for each individual
colour.
A Restore Defaults button allows you to reset the
driver default settings.
NOTE:
PRINTED COLOURS CAN APPEAR DIFFERENT TO DISPLAY COLOURS.
CONTROLS SHOULD ALLOW YOU TO OPTIMIZE THE PRINTED RESULT.

Printhead Power Adjustments

This control allows the customer to adjust the energy applied to the nominated panel of the dye film
during the printing process. It allows adjustments to compensate for image quality issues related to
the use of differing card stocks.

Perform Colour Matching

When selected this automatically attempts to match the monitor and the
print colours.

Advanced button

Allows you to alter the mathematical composition of the monitor colour
matching parameters if you know them.
12
