Monessen Hearth Radiant Wood Burning HWB600/HWB600HB Product Specifications

PRODUCT SPECIFICATIONS
HWB600/HWB600HB Radiant Wood Burning
I N T E R I O R D I M E N S I O N S
Front opening width: 38"
Front opening height: 27"
Rear wall width: 28"
Firebox depth: 22"
T E C H N I C A L I N F O R M A T I O N
Flue Series (Std.): "L" Series Double Wall
Flue Size: 11" Inner; 13" Outer
Clearance to Flue : 2"
Firestop Framing**: 17" x 17"
Minimum Flue Height: 15'
Maximum Flue Height: 86'
Minimum Height with 2 Elbows: 15'
Minimum Height with 4 Elbows: 21'
Clearance to Fireplace: 1-1/2"
Minimum Hearth Size (D x L): 20" x 68"
UL Design Certified
F A C T O R Y I N S T A L L E D O P T I O N S
Refractory firebrick: HWB600
Refractory Herringbone firebrick: HWB600HB
F I E L D I N S T A L L E D A C C E S S O R I E S
Glass Doors : GDPB48 (Polished Brass finish), GDB48 (Black)
Outside Air Kit - AK4, FP4U, 403
Terminations(Std.): "L" Series LC, LCL, CF11, SQ8, LFSQT, LPC
HPBA
Hearth, Patio & Barbecue Association
MADE IN U.S.A.
A Brand of Monessen Hearth Systems Co.
149 Cleveland Drive, Paris, Kentucky 40361
To avoid personal injury or property damage, the product described by this brochure must be installed, operated and maintained in strict compliance with the instructions packaged with the product and all applicable
building or fire codes. Contact local building or fire officials about restrictions and installation inspection requirements. All photographs and drawings on this brochure are for illustrative purposes only and are not intended
for, nor should they be used as a substitute for the instructions packaged with the unit. Appearance and specifications of the product are subject to change without notice. © 2007 Monessen Hearth Systems Co.
www.monessenhearth.com
Framing dimensions in illustrations
accommodate 1/2" finishing material.
