Connecting Other Audio or Video Devices
Once the Videum AV or VO board is installed, you can connect
other audio and video sources to the board such as VCRs,
camcorders, laser disc players, and external CD-ROM players.
The table below shows the types of devices that can be
connected to each connector on the Videum board. The table
also shows the connector type because you may need to
provide your own cables, which you can purchase at your local
electronics or radio/TV store.
Connector
S-Video
MXC
Composite Video In RCA jack
Aux Audio In
Line/Mic In
Stereo Audio Out
All Videum audio connections are stereo. However, you can
connect a mono input if you connect to the left channel,
mono inputs are only played out of the left channel. Special
cables and connectors may be needed to connect the devices
you want. These are all available at your local electronics or
radio/TV store.
Connector Type
4-pin mini-DIN
8-pin mini-DIN
3.5mm stereo mini-jack Audio output from VCR, audio
3.5mm stereo mini-jack Microphone, or audio from an
3.5mm stereo mini-jack Sound card Line In input; takes
9
Connect To ... Device
Only S-Video devices including
VCRs, camcorders, Winnov S-Video
camera, and other S-Video
cameras
Winnov composite video camera
VCRs, camcorders, and other
composite video cameras
output from another sound card
S-Video camera
audio from video camera to
sound card audio input. Can also
be used for external speakers or
headphones
