Videum Duo & Quattro Xpress Audio/Video PCI Express Capture Card QuickStart Guide Product Description page 2 Scope of Delivery page 2 System Requirements page 3 Safety Instructions page 4 Getting Set Up page 4 Installing Videum page 5 Connecting the Watch Reset Cable... -
Page 2: Product Description
PRODUCT DESCRIPTION The Videum Duo Xpress is a 2-channel streaming PCI Express capture card with 4 audio/ video inputs delivering up to 2 independent streams simultaneously. The Videum Quattro Xpress is a 4-channel streaming PCI Express capture card with 8 audio/video inputs delivering up to 4 independent streams simultaneously. -
Page 3: System Requirements
• OS: Windows 2000 SP4, XP SP2, Vista & SP1 x86, Server 2003 SP2, Server 2008 x86 (DirectX9 or higher required) VIDEUM DUO/QUATTRO XPRESS BOARD DRAWING This drawing illustrates the Videum Duo and Quattro Xpress capture card. Watchdog Interface Watchdog Interface Video Termination to RESET on Mainboard... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Power off the computer when installing and removing PC cards. When the computer is turned off by using the power switch, there still might be power supplied to the motherboard. To ensure that your computer is completely shut down, unplug the computer’s power cord from its power source. -
Page 5: Installing Videum
7. Replace the computer cover. Plug in the power cord and restart your system. Installing Multiple Boards Winnov Videum enables you to install several Videum capture cards into your system. If you have installed multiple boards in one system, Videum software recognizes the num- ber of capture cards that you have. -
Page 6: Connecting The Watch Reset Cable
Front Panel Jumper Reset Front Panel Reset Button Mainboard Note: The polarity of the reset circuit is important. If the watchdog function isn't working, reverse the connection by flipping the black 2-pin connector. Videum DUO/Quattro PCI Express Card page 6... -
Page 7: Connecting Digital I/O
Your Videum board provides 8 digital I/O which can be used as trigger input or as event signaling output. Each input and output is used individually as input or output. The Digi- tal I/O interface on the board is controlled through Winnov’s ActiveX software and the Videum SDK (Software Development Kit). -
Page 8: Modifying Video Input Termination
Modifying Video Input Termination Each video input is terminated with 75 Ohm. For proper video reception this termination is required. In some cases, termination is not desired, for example: • The card is inserted into an existing video link via a T-piece. • All inputs are fed from one video source, for example, to provide streams with different resolutions from the same video stream. • Several Videum cards are cascaded or run in parallel to other video equipment. In these cases, the video termination requires a video amplifier or repeater. -
Page 9: Assembling The Bob
CONNECTING VIDEO AND AUDIO SOURCES This section describes how to connect your video sources to the Videum board. The breakout cable or the Videum breakout box (BOB) can be used. Connecting Video Sources via Breakout Cable To connect the Videum board with the breakout cable: 1. Plug the cable into the Videum board’s DVI connector. 2. -
Page 10: Connecting Video Sources Via Bob
2. The rackmount BOB bracket is designed for 4 BOBs. The following photo shows a rackmount BOB bracket with 4 BOBs. 3. Attach the front panel label to the BOB and attach blank labels to the unused posi- tions. 4. Attach the rackmount BOB bracket onto your rack. Connecting Video Sources via Breakout Box This section describes how to connect video sources to your Videum board via the break- out box (BOB). - Page 11 2. Attach the other end of the A/V Media cable to the capture card’s DVI connector. Note: Be careful handling the A/V Media cable and the pins inside the shrouded cable plug. Bending the cable or pins my cause internal damage to the signal wires and/or shielding wires and result in A/V signal quality degradation or complete signal loss.
-
Page 12: Installing The Videum Software
INSTALLING THE VIDEUM SOFTWARE The Videum Software CD contains the Drivers required for using the Videum board, ap- plications, and documentation. Note: If the “Found New Hardware Wizard” popup appears after you start up your sys- tem, be sure to cancel out of it. 1. - Page 13 The latest drivers, utilities, and documentation are available at Winnov’s support website at www.support.winnov.com. To obtain help or information associated with your Videum board or Videum applications, use the Videum SDK’s help menus, supplied documentation (on the CD), or contact Winnov support via e-mail at support@winnov.com. 2011 copyright Winnov. All Rights Reserved. page 13...
