- Page 1 Installation and Operation Manual OKANOGAN Rotisserie Single Spit Rotisserie OKANOGAN WS-SSR WOOD STONE CORPORATION Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 www.woodstone-corp.com DOC NO M0058.00 REVISED March 2015...
-
Page 2: Table Of Contents
ELECTRICAL DIAGRAM � � � � � � � � � � � � � � � � 10 LIMITED WARRANTY � � � � � � � � � � � � � � � � � 11 Wood Stone Corporation Toll Free 800.988.8103 1801 W. -
Page 3: The Okanogan
THE OKANOGAN Okanogan Single Spit Rotisserie Installation and Operation Manual INSTALLATION AND OPERATION MANUAL FOR THE WOOD STONE OKANOGAN ROTISSERIE STONE-FIRED COOKING EQUIPMENT SINGLE SPIT ROTISSERIE WS-SSR ADDITIONAL MANUAL COPIES AVAILABLE UPON REQUEST Right-hand drive model shown on Mt� St� Helens Charbroiler (with optional pan rails and shelf)�... -
Page 4: Cautions & Warnings
Wood Stone’s Okanogan Single Spit Rotisserie has been tested and approved by Intertek Testing Services, and is ETL Listed to ANSI/UL-197, CSA 22.2 No. -
Page 5: Specifications
800mm SSR-57 66" Note: The Single Spit Rotisserie is intended to be installed on top of the Wood Stone Mt� St� Helens or Mt� Shuksan Charbroilers� Side view Total height of unit on top of the Mt� St� Helens is 67 inches 19 3/4"... -
Page 6: Clearances & Venting
The rotisserie must be vented in accordance with all relevant local and national codes, and in a manner acceptable to the authority having jurisdiction� IMPORTANT: This model must be vented as a solid fuel appliance� Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. -
Page 7: Installation
INSTALLING THE ROTISSERIE DRIVE To install the Okanogan rotisserie drive on a Wood Stone charbroiler (if ordered together), simply place the unit on the rails located at the top of the charbroiler and plug it in� Make sure that the unit glides smoothly on the rails, that the power switch is facing the operator and that the cord and plug are not restricted or in danger of getting too hot�... -
Page 8: Spit Loading & Unloading
3. Make sure that the pointed end of the spit is backed out of its hole far enough to allow the spit to turn freely� Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166... -
Page 9: Optional Spits
Okanogan Single Spit Rotisserie Installation and Operation Manual A. STANDARD ANGLE SPIT This is the standard spit included with all Wood Stone Rotisseries� 6 to 7 average sized birds can be quickly loaded� The perforations are convenient for securing the string or skewers used to bind the legs�... -
Page 10: Electrical Diagram
Gray Motor Start Switch / Circuit Breaker .8 A 120 VAC Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... -
Page 11: Limited Warranty
LIMITATIONS OF LIABILITY In the event of warranty claim or otherwise, the sole obligation of Wood Stone shall be the repair and/or replacement, at the option of Wood Stone, of the appliance or component or part thereof� Such repair or replacement shall be at the expense of Wood Stone with the exception of travel over 100 miles or two hours, overtime, and holiday charges which shall be at the expense of the purchaser�...
