LIBRETTO ISTRUZIONI PER L'INSTALLAZIONE
L'USO E LA MANUTENZIONE DELLE GRIGLIE
INSTRUCTION AND MAINTENANCE MANUAL
FOR VULCANIC-ROCK GRILLS
MANUEL D'INSTRUCTIONS POUR L'UTILISA-
DES GRILLES EN PIERRE DE LAVE
GEBRAUCHS- UND WARTUNGSANLEITUNG
MANUAL DE INSTRUCCIONES PARA EL USO Y
EL MANTENIMIENTO DE LAS PARRILLAS DE
0705
PIETRA LAVICA A GAS
TION ET L'ENTRETIEN
LAVASTEINGRILL
PIEDRA LÁVICA
2006581
COD.: ZSL1501
REV. 01 / 2007
Advertisement
Related Manuals for Bartscher GG740
Summary of Contents for Bartscher GG740
- Page 1 LIBRETTO ISTRUZIONI PER L’INSTALLAZIONE L’USO E LA MANUTENZIONE DELLE GRIGLIE PIETRA LAVICA A GAS INSTRUCTION AND MAINTENANCE MANUAL FOR VULCANIC-ROCK GRILLS MANUEL D’INSTRUCTIONS POUR L’UTILISA- TION ET L’ENTRETIEN DES GRILLES EN PIERRE DE LAVE GEBRAUCHS- UND WARTUNGSANLEITUNG LAVASTEINGRILL MANUAL DE INSTRUCCIONES PARA EL USO Y EL MANTENIMIENTO DE LAS PARRILLAS DE PIEDRA LÁVICA 2006581...
- Page 2 CONTENTS 1. INSTALLATION ..........................Pag. 9 1.1 IMPORTANT NOTICES ................................ Pag. 9 1.2 POSITIONING ..................................Pag. 9 1.3 EVACUATION OF EXHAUST FUMES ..........................Pag. 10 1.4 CONNECTING GAS ................................Pag. 10 INSTALLATION INSTRUCTIONS ............................Pag. 10 CHECK BEFORE INSTALLATION ............................Pag. 10 CHECKING THERMAL POWER ............................Pag.
-
Page 3: Evacuation Of Exhaust Fumes
EVACUATION OF EXHAUST FUMES The appliances must be placed in premises from which exhaust fumes can be evacuated in compliance with installation standards. Our appliances are classifi ed type A and cannot be connected to an exhaust fume pipe. The exhaust fumes must be evacuated via extraction hoods or similar devices that are connected to an effi cient fl... -
Page 4: Checking Gas Pressure
The appliance must be supplied with one of the types of gas whose properties and pres- sure are set out in the table below: Connect the appliance to a special gas pipe with an internal diameter of at least 16 mm for G1/2”... - Page 5 ADJUSTING PRIMARY AIRSUPPLY TO MAIN BURNER (Fig. 3) Unscrew the bolt (Ref. D) that fi xes the bush that adjusts the primary air supply (Ref. C). Position the bush (Ref. C) at distance “H” according to the type of gas installed (see ‘Primary air’ on the spe- cifi...
-
Page 6: Operating Instructions
OPERATING INSTRUCTIONS The appliance must be used only for the purpose for which it was designed. Any other use is improper. During operation, supervise the appliance. 2.1 COMMISSIONING Before starting up the appliance for the fi rst time, unpack it and carefully remove all the grease that protects the grid, following this procedure: use a liquid detergent to clean the grid. -
Page 7: Cleaning And Maintenance
If the part is damaged during dismantling or reassembly it must be replaced with a new one. MANAGING SPARE PARTS The spare parts must be replaced only by Description GG740 GG780 GG940 GG980 personnel of an authorised Customer Servi-... - Page 8 SPECIFICATIONS TABLE FOR GAS VULCANIC ROCK GRIDS, CATEGORY II2H3+ Consumption combustion THE MANUFACTURER ACCEPTS NO RESPONSIBILITY FOR HARM CAUSED BY INCORRECT INTERVEN- TIONS, TAMPERING WITH THE APPLIANCE, MISUSE, POOR MAINTENANCE, NON-COMPLIANCE WITH CURRENT REGULATIONS AND INEXPERT USE. THE MANUFACTURER RESERVES THE RIGHT TO WITHOUT NOTICE MODIFY THE FEATURES OF THE APPLIANCES DESCRIBED IN THIS MANUAL.
