Service and Parts Manual
For Item #9, see Model 402 Ice Maker (page 39) for separate breakdown.
14
9
5
27
23
10
25
21
12
26
22
16
Item Description
1 Handle
2 Door Gasket
3 Door Shelf Retainer (Long)
4 Door Shelf Retainer (Short)
5 Fan Blade, Evaporator
6 Pivot Hinge, Top
7 Pivot Hinge, Bottom
9 Ice Maker Ass'y
10 Ice Bucket
11 Complete Door Ass'y
12 Control
13 Grille
14 Ice Bin Door
*Please indicate color.
**Replaces P/N 2595 or 2632 through installation of kit.
COMBO 29FF (1 of 2)
Previous Design Starting With Serial Numbers
2CF300000, 2CF400000 or 2CF500000
17
15
19
7
13
Part No.
31489-3*
31493-3*
31521-2
31521-3
31656
11697-ST*
11695-S*
402
31501
29-DOOR*
2636
11663*
31523-S
11
2
Item Description
15 Glass Shelf (2) Short
16 Switch On-Off
17 Ice Bin Door Hinge (2)
18 Shelf Retainer Rivet (6)
19 Trim Strip, Front Short (2)
20 Pivot Screw, Top
21 Condenser
22 **Timer
23 Fan Motor, Evaporator
24 Pivot Screw, Bottom
25 Freezer Housing
26 Control Knob
27 Evaporator & Heat Exchanger 2631-S29
44
6
20
1
18
4
3
24
COMBO29FFa
COMBO29FFa
Part No.
31425-1
2053
31463
41824
31443-1
41785-SS*
1893-FFS
2632-1
5299-1
41747-SS*
11471-S
41492
