Instruction Manual
SprayStation HV4901
I-Spray 1300
Perfect Spray 800
EN/FR/ES/IT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HV4901 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Earlex HV4901

Summary of Contents for Earlex HV4901

  • Page 1 Instruction Manual SprayStation HV4901 I-Spray 1300 Perfect Spray 800 EN/FR/ES/IT...
  • Page 2 HV4901 Testposter Cover up ! 20-30 cm 0 - 10% Materialnr. 233 0627 EBSS 2330627_Testposter_W565.indd 1 11.06.12 10:01 Instruction Manual SprayStation HV4901 I-Spray 1300 Perfect Spray 800 EN/FR/ES/IT...
  • Page 3 HV4901...
  • Page 4 HV4901...
  • Page 5 HV4901 20-30 cm...
  • Page 6 HV4901  ...
  • Page 7 HV4901...
  • Page 8 HV4901 ................9 - 27 ................XX - XX ................XX - XX ................XX - XX ..........XX ++ ...

  • Page 9: Table Of Contents

    HV4901 MANY THANKS FOR PLACING YOUR TRUST IN US We would like to congratulate you on purchasing this brand product from Earlex; we are sure that you will enjoy working with it greatly. Please read the Operating Manual carefully and observe the safety information before starting the device.

  • Page 10: Explanation Of Symbols Used

    HV4901 1. Explanation of symbols used This symbol indicates a potential danger for you or for the device. Under this symbol you can find important information on how to avoid injuries and damage to the device. Danger of electrical shock Indicates tips for use and other particularly useful information.
  • Page 11 HV4901 any form. Do not use adaptor plugs together with protective-earthed tools. Unmodified plugs and suitable sockets reduce the risk of an electric shock. b) Avoid physical contact with earthed surfaces such as pipes, heating elements, stoves and refrigerators. The risk through electric shock increases if your body is earthed.
  • Page 12 HV4901 d) Remove setting tools or wrenches before switching on the power tool. A tool or wrench that is in a rotating tool part can lead to injuries. e) Avoid an unnatural posture. Ensure that you are standing securely and have your balance at all times.

  • Page 13: Safety Instructions For Spray Guns

    HV4901 5. Service a) Have your tool repaired only by qualified specialist personnel and only with original spare parts. This ensures that the tool safety is maintained. b) If the supply cord is damaged, it must be replaced by the manufacturer or it’s service agent or a similarly qualified person in order to avoid a safety hazard.

  • Page 14: Description/ Scope Of Delivery

    • DO NOT lay the spray gun down on its side. With original EARLEX accessories and spare parts, you have the guarantee that all safety regulations are fulfilled. 4. Description/ Scope of delivery Description/ Scope of delivery (Fig. 1/2)

  • Page 15: Coating Materials Not Suitable For Use

    HV4901 6. Coating Materials Suitable for Use Interior wall paint (dispersions and latex paint) Water- and solvent-based paints, finishes, primers, 2-component paints, clear finishes, automotive finishes, staining sealers and wood sealer-preservatives. 7. Coating Materials Not Suitable for Use Materials that contain highly abrasive components, facade paint, caustic solutions and acidic coating substances.

  • Page 16: Start-Up

    HV4901 SprayStation HV4901 has been developed for use with all conventional paints in their undiluted form. If the surface is smooth and the paint you are using is very thick and gel-like, dilute it by 10%. Dilution can be necessary if the atomisation is coarse or if the flow rate is too low even at the maximum setting.

  • Page 17: Selecting The Spray Setting (Perfect Spray 800 Spray Attachment)

    HV4901 11. Selecting the Spray Setting (Perfect Spray 800 spray attachment) WARNING! Danger of injury! Never pull the trigger guard while adjusting the air cap. With the union nut (Fig. 6, 1) slightly unscrewed, turn the air cap (2) to the desired spray setting position (arrow).

  • Page 18: Interruption Of Work

    HV4901 Important: Start at the edge of the area to be sprayed. Start the spray movement first of all, and then press the trigger. Avoid interruptions within the area to be sprayed. • The spray movement should come from the arm, not just from the wrist. This ensures that a uniform distance is maintained between the spray gun and the spray surface during the spray operation.

  • Page 19: Cleaning The Perfect Spray 800 Spray Attachment

    HV4901 container. 2) Divide the spray gun. Press the hook (Fig. 5 "click") slightly downwards. Turn the gun front part and gun rear part against each other and take them apart. 3) Unscrew the container. Empty any remaining coating material back into the material tin.

  • Page 20: Cleaning The I-Spray 1300 Spray Attachment

    HV4901 Assembly The unit may only be operated with a diaphragm fitted (Fig. 14, C). 1) Place the diaphragm (Fig. 14, C) with the pin facing upwards on the bottom section of the valve. Also see the marking on the gun body.

  • Page 21: Maintenance

    HV4901 of the valve. Also see the marking on the gun body. 2) Place on the valve cover (Fig. 14, B) and screw it closed. 3) Place the ventilating hose (Fig. 14, A) on the valve cover and on the nipple at the gun body.

  • Page 22: Accessories

    Container with cover 1300 ml 2305 155 (only for I-Spray attachment) Spare Parts List (Fig. 25) Pos. Designation Order No. Retainer clip (for Air hose) HV4901 2352 758 Hose Clip HV4901 2352 756 Air Hose HV4901 3m+adapter 2352 752 Air filter HV4901...

  • Page 23: Environmental Protection

    I-Spray 1300 spray attachment incl. 1300 ml container For processing interior wall paint and high-viscosity coating materials. 2321 896 Further information about the EARLEX range of products for renovating is available under www.earlex.com 22. Environmental protection The device and all accessories and packaging have to be recycled in an environmentally friendly manner.

  • Page 24: Correction Of Malfunctions

    HV4901 24. Correction of Malfunctions Malfunction Cause Remedy • No coating Nozzle clogged ➞ Clean • material emerges Material volume setting turned too ➞ Turn to the right (+) from the nozzle far to the left (-) • No pressure build-up in container ➞...

  • Page 25: Technical Data

    HV4901 Malfunction Cause Remedy • Paint in the Diaphragm soiled ➞ Clean the diaphragm • ventilating hose Diaphragm defective ➞ Replace the diaphragm • Device does not Device overheated ➞ Unplug the power function plug, let the device cool down approx. 30...

  • Page 26: Years Guarantee

    Wearing parts are also excluded from the guarantee. The guarantee excludes commercial use. We expressly reserve the right to fulfil the guarantee. The guarantee expires if the tool is opened up by persons other than Earlex service personnel. Transport damage, maintenance work and loss and damage due to faulty maintenance work are not covered by the guarantee.

  • Page 27: Ec Declaration Of Conformity

    HV4901 EC Declaration of Conformity P EN We declare under sole responsibility that this product conforms to the following relevant stipulations: 2006/42/EC; 2004/108/EC; 2011/65/EU; 2002/96/EC Applied harmonised norms: EN 60335-1:2012; EN 50580:2012; EN 55014-1:2006 + A1:2009 + A2:2011; EN 55014-2:1997 + Corrigendum 1997 + A1:2001 + A2:2008;...
  • Page 28 HV4901...
  • Page 29 01483 454548 0373 204839 00373 204845     www.earlex.com Not responsible for errors and changes. Sous réserves d’erreurs et de modifications. Part. No. L2401 12/14 Errores y modificaciones reservados © Copyright Earlex Ltd Con riserva di errori e modifiche.
