Sharp LC-30HV4U Service Manual page 227

Ref. No. Part No.
DUNTKB658FE01 (LC-30HV4U)
DUNTKB658FE02 (LC-30HV4D)
AV Unit (AVC System) (Continued)
R1148 VRS-CY1JF104JY J 100k 1/16W Metal Oxide
R1149 VRS-TX2HF750JY J 75
R1150 VRS-CY1JF104JY J 100k 1/16W Metal Oxide
R1151 VRS-CY1JF102JY J 1k
R1152 VRS-TQ2BD750JY J 75
R1153 VRS-CY1JF102JY J 1k
R1154 VRS-TQ2BD750JY J 75
R1155 VRS-CY1JF102JY J 1k
R1156 VRS-TQ2BD750JY J 75
R1157 VRS-TQ2BD750JY J 75
R1158 VRS-CY1JF221JY J 220 1/16W Metal Oxide
R1159 VRS-CY1JF221JY J 220 1/16W Metal Oxide
R1160 VRS-TQ2BD750JY J 75
R1161 VRS-CY1JF221JY J 220 1/16W Metal Oxide
R1162 VRS-CY1JF221JY J 220 1/16W Metal Oxide
R1163 VRS-CY1JF102JY J 1k
R1164 VRS-TQ2BD750JY J 75
R1165 VRS-TX2HF750JY J 75
R1166 VRS-CY1JF104JY J 100k 1/16W Metal Oxide
R1167 VRS-CY1JF221JY J 220 1/16W Metal Oxide
R1168 VRS-CY1JF271JY J 270 1/16W Metal Oxide
R1169 VRS-CY1JF564JY J 560k 1/16W Metal Oxide
R1170 VRS-CY1JF221JY J 220 1/16W Metal Oxide
R1171 VRS-CY1JF271JY J 270 1/16W Metal Oxide
R1172 VRS-CY1JF564JY J 560k 1/16W Metal Oxide
R1173 VRS-CY1JF564JY J 560k 1/16W Metal Oxide
R1174 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1175 VRS-CY1JF564JY J 560k 1/16W Metal Oxide
R1180 VRS-CA1JF101JY J 100 1/16W Metal Oxide
R1182 VRS-CB1JF223JY J 22k 1/16W Metal Oxide
R1185 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1187 VRS-CY1JF561JY J 560 1/16W Metal Oxide
R1188 VRS-CY1JF561JY J 560 1/16W Metal Oxide
R1189 VRS-TQ2BD750JY J 75
R1190 VRS-TQ2BD750JY J 75
R1191 VRS-CY1JF102JY J 1k
R1192 VRS-TQ2BD750JY J 75
R1193 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1195 VRS-CY1JF274JY J 270k 1/16W Metal Oxide
R1196 VRS-CY1JF680JY J 68
R1197 VRS-CY1JF680JY J 68
R1198 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide
R1199 VRS-CY1JF102JY J 1k
R1200 VRS-CY1JF123JY J 12k 1/16W Metal Oxide
R1201 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1202 VRS-CY1JF683JY J 68k 1/16W Metal Oxide
R1203 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide
R1204 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1205 VRS-CA1JF101JY J 100 1/16W Metal Oxide
R1206 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide
R1207 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide
R1208 VRS-CY1JF333JY J 33k 1/16W Metal Oxide
R1209 VRS-TQ2BD561JY J 560 1/8W
R1211 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide
R1212 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide
R1213 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1214 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide
R1215 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide
R1216 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide
R1217 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1218 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide
R1219 VRS-TQ2BD561JY J 560 1/8W
R1220 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1221 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide
R1222 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1223 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1224 VRS-CY1JF473JY J 47k 1/16W Metal Oxide
R1225 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide
R1226 VRS-CY1JF333JY J 33k 1/16W Metal Oxide
R1227 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide
R1228 VRS-CY1JF102JY J 1k
Description Code
AA
1/2W Metal Oxide AB
AA
1/16W Metal Oxide AA
1/8W Metal Oxide AA
1/16W Metal Oxide AA
1/8W Metal Oxide AA
1/16W Metal Oxide AA
1/8W Metal Oxide AA
1/8W Metal Oxide AA
AA
AA
1/8W Metal Oxide AA
AA
AA
1/16W Metal Oxide AA
1/8W Metal Oxide AA
1/2W Metal Oxide AB
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
1/8W Metal Oxide AA
1/8W Metal Oxide AA
1/16W Metal Oxide AA
1/8W Metal Oxide AA
AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
Metal Oxide AA
AA
AA
AA
AA
AA
AA
AA
AA
Metal Oxide AA
AA
AA
AA
AA
AA
AA
AA
AA
1/16W Metal Oxide AA
227
Ref. No. Part No.
R1229 VRS-CY1JF102JY J 1k
R1230 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide
R1231 VRS-CY1JF331JY J 330 1/16W Metal Oxide
R1232 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1233 VRS-CY1JF123JY J 12k 1/16W Metal Oxide
R1301 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1302 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide
R1303 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1304 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide
R1305 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1306 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1307 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1308 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1309 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide
R1310 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1311 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide
R1312 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1313 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1314 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide
R1315 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1316 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide
R1317 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1318 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1319 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1320 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide
R1321 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1322 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide
R1323 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1324 VRS-CY1JF102JY J 1k
R1325 VRS-CY1JF102JY J 1k
R1326 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide
R1327 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide
R1328 VRS-TW2ED221JY J 220 1/4W
R1329 VRS-TW2ED221JY J 220 1/4W
R1330 VRS-TW2ED221JY J 220 1/4W
R1331 VRS-CA1JF101JY J 100 1/16W Metal Oxide
R1334 VRS-CY1JF561JY J 560 1/16W Metal Oxide
R1335 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1336 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1338 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1340 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1341 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1342 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1343 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1348 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1349 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1350 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1354 VRS-CY1JF102JY J 1k
R1405 VRS-CY1JF220JY J 22
R1406 VRS-CY1JF220JY J 22
R1407 VRS-CY1JF220JY J 22
R1411 VRS-CY1JF220JY J 22
R1412 VRS-CY1JF220JY J 22
R1413 VRS-CY1JF220JY J 22
R1418 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R1421 VRS-CA1JF101JY J 100 1/16W Metal Oxide
R1422 VRS-CY1JF100JY J 10
R1423 VRS-CY1JF100JY J 10
R1424 VRS-CY1JF100JY J 10
R1425 VRS-CY1JF100JY J 10
R1429 VRS-CY1JF100JY J 10
R1430 VRS-CY1JF100JY J 10
R1431 VRS-CY1JF100JY J 10
R1432 VRS-CY1JF100JY J 10
R1433 VRS-CY1JF100JY J 10
R1437 VRS-CY1JF220JY J 22
R1438 VRS-CY1JF220JY J 22
R1439 VRS-CY1JF220JY J 22
R1443 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1444 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1445 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1446 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1447 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1448 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1457 VRS-CY1JF102JY J 1k
LC-30HV4U
LC-30HV4D
Description Code
1/16W Metal Oxide AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
AA
Metal Oxide AB
Metal Oxide AB
Metal Oxide AB
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
AA
AA
AA
AA
AA
1/16W Metal Oxide AA
