4.4.4 IDE Configuration Sub-Submenus

Maintenance
The sub-submenus represented in Table 56 are used to configure IDE devices.
Table 56.

IDE Configuration Sub-Submenus

Feature
Type
LBA Mode Control
Multi-Sector Transfers
PIO Mode
Ultra DMA
Main
Advanced
Boot Configuration
Peripheral Configuration
IDE Configuration
Primary IDE Master
Primary IDE Slave
Secondary IDE Master
Secondary IDE Slave
Event Log Configuration
Options
• None
• User
• Auto (default)
• CD-ROM
• ATAPI Removable
• Other ATAPI
• IDE Removable
• Disabled
• Enabled (default)
• Disabled
• 2 Sectors
• 4 Sectors
• 8 Sectors
• 16 Sectors (default)
• Auto (default)
• 0
• 1
• 2
• 3
• 4
• Disabled (default)
• Mode 0
• Mode 1
• Mode 2
• Mode 3
• Mode 4 (Available in
primary IDE only)
Security Power
Description
Specifies the IDE configuration mode for IDE devices.
User allows the cylinders, heads, and sectors fields to
be changed.
Auto automatically fills in the values for the cylinders,
heads, and sectors fields.
Enables or disables the LBA mode control.
(Shows when anything other than Auto is selected in the
Type menu above.)
Specifies number of sectors per block for transfers from
the hard disk drive to memory.
Check the hard disk drive's specifications for optimum
setting.
Shows when anything other than Auto is selected in the
Type menu above.
Configures the PIO mode.
Shows when anything other than Auto is selected in the
Type menu above.
Specifies the Ultra DMA mode for the drive.
Shows when anything other than Auto is selected in the
Type menu above.
BIOS Setup Program
Boot Exit
85
