HIGH EFFICIENCY OIL-FIRED MULTI-POSITIONAL FURNACE
MAX
Installation, Operation and
Maintenance Manual
INSTALLATIONS MUST MEET ALL LOCAL AND FEDERAL
Please read this complete manual before beginning installation. These instructions must be
kept with the furnace for future reference.
CERTIFIED TO:
CONFORMS TO:
GRANBY FURNACES INC.
PO Box 637
12118 Hwy 209
Parrsboro Nova Scotia Canada
B0M 1S0
www.GranbyIndustries.com
SUMMIT
EVO
CODES THAT MAY DIFFER FROM THIS MANUAL
CAN/CSA Std. B140.0 & Std. B140.4
UL 727
- multi
CLASSIC AIR
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Granby max
Summary of Contents for Granby max
- Page 1 Please read this complete manual before beginning installation. These instructions must be kept with the furnace for future reference. CERTIFIED TO: CAN/CSA Std. B140.0 & Std. B140.4 CONFORMS TO: UL 727 GRANBY FURNACES INC. PO Box 637 12118 Hwy 209 Parrsboro Nova Scotia Canada B0M 1S0 www.GranbyIndustries.com...
-
Page 2: Table Of Contents
Restarting Furnace Installation Important Caution Installation Codes Multi-Position Placement & Venting MAX/EVO AC/Auxiliary Sensor Installation Assemble & Install Burner Changing Nozzle Set Burner for Efficient Operation 2.10 Classic Air Blower Settings 2.11 Air Conditioning 2.12 Humidifier 2.13 Thermostat Anticipator Setting 2.14 Fan Control... -
Page 3: Save These Instructions
Oil Tank & Piping Figure – 4 Classic Air Wiring Diagram Figure – 5 EVO 9200i Wiring Diagram Figure – 6 MAX 9300i Wiring Diagram Figure – 7 Sub-base Instructions Figure – 8 Dimensions Figure – 9 Return Air Filter Locations Figure –... -
Page 4: Homeowner Information
SUMMIT-MULTI – INSTALLATION/OPERATION MANUAL HOMEOWNER INFORMATION INTRODUCTION Please read and understand this manual before installing, operating or maintaining the furnace. To ensure you have a clear understanding of the operating procedures of this appliance please take the time to read section 1.0 HOMEOWNER INFORMATION. AIR FILTER To maintain furnace performance and safety, replace dirty filters as required or at least once every heating season. -
Page 5: Restarting Furnace
SUMMIT-MULTI – INSTALLATION/OPERATION MANUAL RESTARTING FURNACE Follow this procedure before restarting a unit that has been shut down for an extended period of time: INSPECTION Have the furnace/system serviced and inspected by a qualified technician. FUEL Turn on fuel supply and check that there are no leaks. POWER Turn on power and check that the furnace starts and operates as usual. -
Page 6: Multi-Position
NFPA 31, Canada: CSA B139). UPFLOW If required, support furnace on a Granby Appliance Stand or four (4) concrete blocks. Make sure each corner of furnace base is supported. For a furnace installed on a combustible floor, ensure that the requirements of the authorities having jurisdiction are satisfied. - Page 7 SUMMIT-MULTI – INSTALLATION/OPERATION MANUAL COMBUSTION & Install openings and ductwork to the furnace room to provide fresh outside VENTILATION AIR combustion and circulation air for cooling the furnace casing, as installation code requires (USA NFPA 31, Canada CSA B139). If installed in a closed room, provide two free air ventilation openings of at least 8”...
-
Page 8: Max/Evo Ac/Auxiliary Sensor Installation
SUMMIT-MULTI – INSTALLATION/OPERATION MANUAL MAX/EVO AC/AUXILIARY SENSOR INSTALLATION Mandatory for MAX series furnaces when equipped with an A/C coil. Optional for EVO series furnaces when equipped with an A/C coil, defaults to full speed on A/C if not installed. AC/Auxiliary sensor kit contents: AC/Auxiliary sensor mounted in sensor box with 86”... -
Page 9: Assemble & Install Burner
SUMMIT-MULTI – INSTALLATION/OPERATION MANUAL ASSEMBLE & INSTALL BURNER ASSEMBLE Check burner model is correct for furnace rating required. Assemble as per burner manufacturer’s instructions. SET END CONE Beckett AFG - see manufacturer’s instructions. Riello - Set turbulator as per furnace operating decal. SELECT NOZZLE Select oil input, nozzle required and burner configuration as shown on furnace operating decal. -
Page 10: Classic Air Blower Settings
MUST be properly installed in the evaporator system to ensure proper operation of the A/C system. The firing rate of 157,000 Btu/h, on the Classic Air, EVO or MAX, cannot be used in conjunction with an air conditioning coil. 2.12 HUMIDIFIER If a humidifier is installed ensure that no water can drip or run from it into the furnace. -
Page 11: Fan Control
2.14 FAN CONTROL CLASSIC AIR Limit 165°F - Factory set. Fan On 45 seconds after burner starts Fan Off Adjustable on electronic board MAX/EVO Standard Mode EVO Only High Limit 180°F (Resets at 120°F) Fan On (Heat) 130°F Fan Off (Heat) 90°F... -
Page 12: Max Blower Operation
SUMMIT-MULTI – INSTALLATION/OPERATION MANUAL 2.16 MAX BLOWER OPERATION The MAX furnace has an advanced control that performs all of the safety and control functions. There are two temperature sensors. One comes installed in the furnace and the AC/auxiliary temperature sensor is installed after the A coil or auxiliary heating device. The control will automatically handle two stage air conditioning and auxiliary heat such as electric plenum heaters or heat pumps. -
Page 13: Burner Specifications
SUMMIT-MULTI – INSTALLATION/OPERATION MANUAL BURNER SPECIFICATIONS CLASSIC AIR Input Pump Output Blower Motor Heating cfm@ Blower Speed Model Burner Nozzle Turbulator Setting USGPH L/h Btu/h (psi) Btu/h Kw (inches) (hp) 0.2”wc 0.5”wc 0.2”wc 0.5”wc Beckett AFG F3 0.92 0.00 128,800 0.75 70B 109,000 32 GT 10-10 1/2 hp 1300 1250... - Page 14 SUMMIT-MULTI – INSTALLATION/OPERATION MANUAL Input Pump Output Blower Motor Model Burner Nozzle Turbulator Heating CFM Setting USGPH L/h Btu/h (psi) Btu/h Kw (inches) (hp) Beckett AFG F3 0.90 3.40 126,000 0.75 70B 0/10 109,000 32 GT 12-10 3/4 hp 1210* 1.02 3.85 142,800 0.85 70B 0.5/5...
-
Page 15: Blocked Vent Switch
SUMMIT-MULTI – INSTALLATION/OPERATION MANUAL BLOCKED VENT SWITCH Oil-fired appliances installed in Canada require a blocked vent shut-off system when installed on a chimney. A safety switch is included with the furnace to perform this function. It is the installer’s responsibility to install the switch in accordance with the instructions provided. Not applicable for Direct Vent or Power Vent systems. -
Page 16: Classic Air Comfort Adjustments
BLOWER REMOVAL Use a reversing drill with 1/4” hex drive for the sheet metal screws. Granby furnaces have a quick release blower suspension system, which is designed to be tight and rattle free. 1. Disconnect power. - Page 17 External static - Non A/C 0.2” wc External static - A/C 0.5” wc Maximum air temperature rise 85°F High limit, max. design outlet temp. 200°F Thermostat anticipator 0.2 amps (Classic Air) 0.1 amps (MAX/EVO) MOTOR/BLOWER 3/4 hp 4 Speed/GT 12-10...
-
Page 18: Trouble Shooting Guide
SUMMIT-MULTI – INSTALLATION/OPERATION MANUAL OPENING HEIGHTS from floor Burner c/l 27 1/2” (699 mm) Smoke pipe c/l 44 1/2” (1130 mm) SMOKE/VENT PIPE - 5” CLEANOUTS Smoke pipe cover, burner opening, and cleanouts (2), replace baffles after cleaning. AIR FILTER Pleated 20”... -
Page 19: Max/Evo Led Indicators
Replace blower motor. Faulty oil pump Repair or replace oil pump. Reset to correct pressure. Air leak in oil line Tighten all connections. MAX/EVO LED INDICATORS Refer to decal on inside of wiring box cover. GREEN LED (Status) Slow Green Standby. -
Page 20: Max/Evo Sensor Diagnostics
“Y” terminal. If the AC/Aux sensor is suspect then check sensor as below. SENSOR FAULT ON MAX FURNACE If the AC/Aux sensor is bad, the 9300i control will indicate heat sensor trouble with three RED flashes of the LED on the circuit board and a solid GREEN LED. - Page 21 SUMMIT-MULTI – INSTALLATION/OPERATION MANUAL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE. FOR MOST RECENT UPDATES PLEASE VISIT www.GranbyIndustries.com. The following form MUST be completed for the warranty to be valid. Installed by: Address: Telephone: Date: START UP TEST RESULTS Nozzle: Pressure: Air: Turbulator:...
- Page 24 CLASSIC AIR WIRING DIAGRAM FIGURE - 4...
- Page 32 Table - 1 Summit-multi Classic Air Oil-Fired Furnace Order No. Item No. Part Description ELB-P0-0008-00 K6C-1 Wiring Box Cover ELB-P0-0006-00 K6C-2 Wiring Box K00-CB-0103-00 K6C-3 5" Flue Pipe Collar K6C-CB-0045-00 K6C-4 Cabinet Cleanout Cover K6C-CB-0036-00 K6C-5 Cabinet Blower Door K00-HE-0100-00 K6C-6 Smoke Pipe Flange Assembly K00-CB-0037-00...
- Page 33 Table - 2 Summit-multi EVO Oil-Fired Furnace Order No. Item No. Part Description ELB-P0-0008-00 K6C EVO-1 Wiring Box Cover ELB-P0-0006-00 K6C EVO-2 Wiring Box K00-CB-0103-00 K6C EVO-3 5" Flue Pipe Collar K6C-CB-0045-00 K6C EVO-4 Cabinet Cleanout Cover K6C-CB-0036-00 K6C EVO-5 Cabinet Blower Door K00-HE-0100-00 K6C EVO-6...
- Page 34 Table - 3 Summit-multi MAX Oil-Fired Furnace Order No. Item No. Part Description ELB-P0-0008-00 K6C MAX-1 Wiring Box Cover ELB-P0-0006-00 K6C MAX-2 Wiring Box K00-CB-0103-00 K6C MAX-3 5" Flue Pipe Collar K6C-CB-0045-00 K6C MAX-4 Cabinet Cleanout Cover K6C-CB-0036-00 K6C MAX-5...
