Summary of Contents for Harley Benton PB 5
- Page 1 PB 5 pedal board user manual...
- Page 2 Musikhaus Thomann e. K. Treppendorf 30 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 31.07.2012...
-
Page 3: Table Of Contents
Table of contents Table of contents General notes............................... 4 Safety instructions............................. 6 Features ................................. 9 Installation and starting up........................ 10 4.1 Pin assignment..........................11 Connections and operating elements................... 13 Technical specifications........................16 Protecting the environment......................17 PB 5... -
Page 4: General Notes
General notes General notes This user manual contains important information on safe operation of the device. Read and follow all safety notes and all instructions. Save this manual for future reference. Make sure that it is available to all persons using this device. If you sell the device to other users, be sure that they also receive this manual. - Page 5 NOTICE! This combination of symbol and signal word indicates a possible dangerous situation that can result in material and environmental damage if it is not avoided. Warning signs Type of danger Warning – danger zone. PB 5...
-
Page 6: Safety Instructions
Safety instructions Safety instructions Intended use This device is intended to be used for hosting, fixation and voltage supply of several effects pedals for musical instruments connected in series. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. - Page 7 They could swallow the pieces and choke! Never let children unattended use electrical devices. NOTICE! Risk of fire Do not block areas of ventilation. Do not install the device near any direct heat source. Keep the device away from naked flames. PB 5...
- Page 8 Safety instructions NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. NOTICE! External power supply The device is powered by an external power supply. Before connecting the external power supply, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual cur‐...
-
Page 9: Features
Clear array of up to five effects pedals Sturdy plastic housing with removable lid and special foam insert Built-in headphone jack and 1 watt speaker Built-in power supply cable for effects pedals Including patch cables with angled connectors and 9V power supply PB 5... -
Page 10: Installation And Starting Up
Installation and starting up Installation and starting up Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. -
Page 11: 4.1 Pin Assignment
Installation and starting up 4.1 Pin assignment 1/4" phone sockets for signal in Drawings and tables indicate the pin assignment of 1/4" phone plugs. and outputs Unbalanced wired TS plug: Signal Ground, shielding PB 5... - Page 12 Installation and starting up Unbalanced wired TRS plug: Signal 2, 3 Ground, shielding Balanced wired TRS plug: Positive signal (+) Negative signal (–) Ground, shielding pedal board...
-
Page 13: Connections And Operating Elements
Connections and operating elements Connections and operating elements Front panel PB 5... - Page 14 Connections and operating elements 1 Input RETURN A / B 1/4" connection socket for effects pedals. Connect the output of the last effects pedal through one of the supplied patch cables to this connection socket, to feed the modified audio signal into the connected audio amplifier, the headphones output and the integrated speaker.
- Page 15 Connection socket for effects pedals. Connect the input of the first effects pedal through one of the supplied patch cables to this connection socket, to feed the audio signal into the connected effects pedals. Connect all utilised effects pedals in series using the supplied patch cables. 10 Input INPUT Connection socket for 1/4" instrument cables. PB 5...
-
Page 16: Technical Specifications
Technical specifications Technical specifications Operating voltage supply 9V mains power adapter ( , 1000 mA) Housing Plastic Dimensions (W × H × D) 680 mm × 110 mm × 375 mm Weight 4 kg pedal board... -
Page 17: Protecting The Environment
Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. PB 5... - Page 18 Notes pedal board...
- Page 20 Musikhaus Thomann e.K. · Treppendorf 30 · 96138 Burgebrach · Germany · www.thomann.de...
