Black Box LGB1108A Command-Line Interface (Cli) Manual
  1. Manuals
  2. Brands
  3. Black Box Manuals
  4. Switch
  5. LGB1108A
  6. Command-line interface (cli) manual

Black Box LGB1108A Command-Line Interface (Cli) Manual

10-, 26-, or 48-port gigabit managed switch
Hide thumbs Also See for LGB1108A:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
10-, 26-, or 48-Port Gigabit Managed Switch
Command-Line Interface (CLI) Guide
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
Customer
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746
Support
www.blackbox.com • info@blackbox.com
Information
LGB1108A
LGB1126A
LGB1148A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LGB1108A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Black Box LGB1108A

Summary of Contents for Black Box LGB1108A

  • Page 1 LGB1108A LGB1126A LGB1148A 10-, 26-, or 48-Port Gigabit Managed Switch Command-Line Interface (CLI) Guide Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) Customer FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 Support www.blackbox.com •...
  • Page 2 Gigabit Managed Switches Command-Line Interface (CLI) Guide 10-Port Gigabit Managed Switch (LGB1108A) 26-Port Gigabit Managed Switch (LGB1126A) 48-Port Gigabit Managed Switch (LGB1148A) Publication date: May., 2014 Revision A1...

  • Page 3: About   T His   G Uide

              ABOUT   T HIS   G UIDE   Copyright   Copyright   ©   2 015.   B lack   B ox   C orporation.   A ll   r ights   r eserved.   This  guide  contains  proprietary  information  protected  by  copyright.  No  ...

  • Page 4: Revision   H Istory

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.     Revision   H istory   Release Date Revision V2.60 05/20/2014 Publication date: May, 2014 Revision A1...

  • Page 5: Table Of Contents

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   CONTENTS           ABOUT   T HIS   G UIDE ........................ 2   Revision   H istory ..........................3   Chapter 1  ...
  • Page 6 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   SNMP   C ommands   o f   C LI ..................141   Chapter 41 SSH   C ommands   o f   C LI ..................147   Chapter 42 STP  ...

  • Page 7: Operation   O F   C Li   M Anagement

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.         Operation   o f   C LI   M anagement   Chapter 1   Initial         This  chapter  explains  how  to  configure  and  manage  the  Gigabit  Managed  ...
  • Page 8 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   CONNECTING     The   D B-­‐9   s erial   p ort   o n   t he   s witch’s   f ront   p anel   i s   u sed   t o   c onnect   t o   TO  ...
  • Page 9 Figure 2: Plug in the Console Port Figure 3: Console configure After  the  Gigabit  Managed  Switch  configures  the  IT  interface,  you  can  access  It  via   the   s witch’s   c onsole   p ort.   F or   i nstance,   i t   w ill   s how   t he   f ollowing   s creen   a nd   a sk   y ou   to  ...
  • Page 10 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Figure 4: Console CLI interface   Type “?” or “help” to get the switch help. It includes syntax or all functions explanations. The screen below is displayed.

  • Page 11: Aaa   C Ommands   O F   C Lid

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   AAA   C ommands   o f   C LI Chapter 2...
  • Page 12 AAA   This  section  shows  you  how  to  use  an  AAA  (Authentication,  Authorization,   Accounting)   server   to   provide   access   control   to   your   network.   The   AAA   server  can  be  a  TACACS+  or  RADIUS  server  to  create  and  manage  objects   that  ...
  • Page 13 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   accounting   :   Use   t his   c ommand   t o   e nable   o r   d isable   t he   R ADIUS   accounting  ...
  • Page 14 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   authorization:   Use   t his   c ommand   t o   c onfigure   ( enable/disable)   RADIUS   A uthorization   m ode.   authorization <enable/disable>...
  • Page 15 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   radius:         Use   t his   c ommand   t o   c onfigure   t he   R ADIUS   S erver   detailed  ...
  • Page 16 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   tacacs+   :     Use   t his   c ommand   t o   c onfigure   t he   T ACACS+   authentication  ...

  • Page 17: Chapter 3 Access   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Access   C ommands   o f   C LI   Chapter 3 Access     This   s ection   s hows   y ou   h ow   t o   c onfigure   t he   a ccess   m anagement   t able   o f   the  ...
  • Page 18 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Syntax: Clear < statistics> <None> Clear access management statistics Parameter : EXAMPLE: delete:     Use   t his   c ommand   t o   d elete   a n   a ccess   m anagement   entry.  ...

  • Page 19: Chapter 4 Account   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Account   C ommands   o f   C LI   Chapter 4 Account   In  this  function,  only  the  administrator  can  create,  modify,  or  delete  the   username  ...
  • Page 20 show   :   Use   t his   c ommand   t o   d isplay   u ser   a ccount   information   t hat   y ou   s et   i n   t he   s witch.   Show <name>...

  • Page 21: Chapter 5 Acl   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   ACL   C ommands   o f   C LI   Chapter 5 ACL   The  switch  access  control  list  (ACL)  is  probably  the  most  commonly  used   object  ...
  • Page 22 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   policy: Policy ACE keyword, the rule applies to all ports configured with the specified policy. port: Port ACE keyword, the rule applies to the specified port only. switch: Switch ACE keyword, the rule applies to all ports <port-list>...
  • Page 23 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   EXAMPLE: logging   :   Use   t his   c ommand   t o   c onfigure   a n   A CL   p ort   d efault   logging  ...
  • Page 24 Syntax: policy <port-list> <1-8> <port-list> Port list, available value is from switch physical port Parameter : density, format: 1,3-5 <1-8> Policy number EXAMPLE:   Use   t his   c ommand   t o   s et   a n   a cl   p ort-­‐rate   o n   t he    ...
  • Page 25 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   acl-status Show ACL status port Show ACL port configuration rate-limiter Show ACL rate limiter EXAMPLE: shutdown:   Configure   A CL   p ort   d efault   s hut   d own   o peration.   Syntax: shutdown <port-list>...
  • Page 26 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   state:   Use   t his   c ommand   t o   c onfigure   a n   A CL   p ort   s tate.   state <port-list>...

  • Page 27: Chapter 6 Aggregation   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Aggregation   C ommands   o f   C LI   Chapter 6 Aggregation     Aggregation   configures   the   Link   Aggregation   settings.   You   can   bundle   more  ...
  • Page 28 mode:   Use   t his   c ommand   t o   c onfigure   t he   l ink   a ggregation   traffic   d istribution   m ode.   mode dmac/ ip/ port/ smac disable/enable Syntax: Parameter : dmac Destination MAC address.

  • Page 29: Chapter 7 Arp-­-Inspection   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Arp-­‐inspection   C ommands   o f   C LI   Chapter 7 Arp   i nspection     The   section   describes   how   to   configure   the   switch’s   ARP   Inspection   parameters.  ...
  • Page 30 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   mode   :     Use   t his   c ommand   t o   c onfigure   A RP   i nspection   m ode.   delete <port-list>...
  • Page 31 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   translate:   This   c ommand   l ets   y ou   a dd   A RP   i nspection   s tatic   e ntry.   Syntax: translate Parameter :...

  • Page 32: Chapter 8 Auth   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Auth   C ommands   o f   C LI   Chapter 8 Auth   m ethod     This   p age   s hows   h ow   t o   c onfigure   a   u ser   a s   a uthenticated   w hen   h e   l ogs   into  ...
  • Page 33 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   telnet Use remote RADIUS authentication. tacacs+ Use remote TACACS+ authentication. EXAMPLE: show:   Use   t his   c ommand   t o   d isplay   t he   A RP   i nspection   configuration  ...

  • Page 34: Chapter 9 Config-­-File   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Config-­‐file   C ommands   o f   C LI   Chapter 9 Config-­‐file     This   s ection   d escribes   h ow   t o   e xport   a nd   i mport   t he   S witch   c onfiguration.   Any  ...

  • Page 35: Chapter 10 Dhcp   R Elay   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   DHCP   R elay   C ommands   o f   C LI   Chapter 10 DHCP   R elay     The  ...
  • Page 36 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   relay-­‐option:   Use   t his   c ommand   t o   c onfigure   t he   D HCP   r elay   a gent   information  ...
  • Page 37 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Syntax: show config/statistics Parameter : config The parameter sets show DHCP relay configuration. statistics The parameter sets show DHCP relay statistics. EXAMPLE: Publication date: May, 2014 Revision A1...

  • Page 38: Chapter 11 Dhcp   S Nooping   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   DHCP   S nooping   C ommands   o f   C LI   Chapter 11 DHCP   The   s ection   d escribes   h ow   t o   c onfigure   t he   D HCP   S nooping   p arameters   o f   the  ...
  • Page 39 port-­‐mode:   Use   t his   c ommand   t o   c onfigure   D HCP   s nooping   p ort   mode.   Syntax: Mode <port-list> trusted/ untrusted <port-list> Port list, available value is from 1 to 10B format:1,3-5 Parameter : trusted Configures the port as a trusted source of the DHCP message.

  • Page 40: Chapter 12 Diagnostic   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Diagnostic   C ommands   o f   C LI   Chapter 12 Diagnostic     This   section   provides   a   set   of   basic   system   diagnoses.   It   let   users   know   whether  the  system  is  operating  correctly  or  needs  to  be  fixed.  The  basic  ...

  • Page 41: Chapter 13 Easyport   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Easyport   C ommands   o f   C LI   Chapter 13 Easyport   Easy   Port   provides   a   convenient   way   to   save   and   share   common   configurations.  ...
  • Page 42 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   IP Camera. <1-4094> Access VLAN ID, available value is from 1 to 4094. <admin-edge> The parameter lets you to configure spanning tree admin-edge for IP Camera.
  • Page 43 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   ip-­‐phone:   Use   this   command   to   configure   an   ip-­‐phone   easily   on   the   s witch   t hrough   p rofile   a nd   r ule. Syntax: ip-phone <port-list>...
  • Page 44 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   <psec-limit> The parameter lets you configure port security maximum for IP Camera. <1-50> Max. number of MAC addresses. <psec-mode> The parameter lets you configure port security mode for IP Camera.
  • Page 45 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Parameter : <port-list> Port list, available value is from 1 to 10B format:1,3-5 level), below are 2 level parameter. <access-vlan> The parameter lets you configure access VLAN for IP Camera.

  • Page 46: Chapter 14 Eee   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   EEE   C ommands   o f   C LI   Chapter 14 EEE     The   s ection   a llows   t he   u ser   t o   i nspect   a nd   c onfigure   t he   c urrent   E EE   p ort   settings.  ...
  • Page 47 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   EXAMPLE: show:     Use   t his   c ommand   t o   S how   E EE   i nformation. Syntax: show <cr>...

  • Page 48: Chapter 15 Event   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Event   C ommands   o f   C LI   Chapter 15 Event     The  function  is  used  to  set  an  Alarm  trap  and  get  the  Event  log.  The  Trap   Events  ...
  • Page 49 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Show:   Use   this   command   to   display   trap   event   configuration   that   y ou   s et   o n   t he   s witch.   show <cr>...

  • Page 50: Chapter 16 Fdb   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Fdb   C ommands   o f   C LI   Chapter 16 Fdb   ( Filtering   Filtering  Data  Base  Configuration  gathers  many  functions,  including  MAC   Table  Information,  Static  MAC  Learning,  which  cannot  be  categorized  to  ...
  • Page 51 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   delete:     Use   t his   c ommand   t o   d elete   a   s tatic   M AC   a ddress   e ntry   that  ...
  • Page 52 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   learning:     Use   t his   c ommand   t o   c onfigure   t he   l earning   m ode   o f   switch  ...
  • Page 53 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   <mac-address> the parameter is MAC address, format 0a-1b-2c-3d-4e-5f. <port-list> The physical port’s available value is from 1 to 28 format: 1,3-5. <1-4094> VLAN ID, available value is from 1 to 4094. static-mac Show static MAC address.

  • Page 54: Chapter 17 Firmware   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Firmware   C ommands   o f   C LI   Chapter 17 firmware     This   section   describes   how   to   upgrade   Firmware.   The   Switch   can   be   enhanced  ...
  • Page 55 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   upgrade   :   Use   t his   c ommand   t o   u pgrade   t he   s ystem   f irmware   t o   an  ...

  • Page 56: Chapter 18 Garp   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   GARP   C ommands   o f   C LI   Chapter 18 GARP   The   Generic   Attribute   Registration   Protocol   (GARP)   provides   a   generic   framework  ...
  • Page 57 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   join-­‐time: Use   t his   c ommand   t o   s et   t he   G ARP   j oin   t imer   configuration  ...
  • Page 58 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   If you didn’t set the GARP environment already, then the switch will show “Set leavetimer failed”. show:   Use   this   command   to   display   the   GARP   configuration   that  ...

  • Page 59: Chapter 19 Gvrp   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   GVRP   C ommands   o f   C LI   Chapter 19 GVRP   GVRP   is   an   application   based   on   Generic   Attribute   Registration   Protocol   (GARP),  ...
  • Page 60 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   control:   Use   t his   c ommand   t o   e nable   o r   d isable   t he   G VRP   globally.
  • Page 61 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   show:     Use   t his   c ommand   t o   d isplay   t he   G VRP   f unction   information.  ...

  • Page 62: Chapter 20 Https   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   HTTPs   C ommands   o f   C LI   Chapter 20 Https     This  section  shows  you  how  to  use  HTTPS  to  securely  access  the  Switch.   HTTPS  is  a  secure  communication  protocol  that  combines  authentication  ...
  • Page 63 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   show:     Use  this  command  to  display  the  all  HTTPs  settings  on   the   s witch   o r   s tatus   i nformation.   show <cr>...

  • Page 64: Chapter 21 Igmp   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   IGMP   C ommands   o f   C LI   Chapter 21 IGMP   The   function,   is   used   to   establish   which   multicast   groups   can   forward   a   multicast  ...
  • Page 65 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   snooping Set IGMP Snooping Mode ssm-range Set IGMP SSM Range state Enable/Disable per-VLAN IGMP Snooping Mode throttling Set per-port Throttling Set per-VLAN Unsolicited Report Interval compatibility: Use  ...
  • Page 66 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Parameter : <port-list> The switch’s physical port; available value is from 1 to 28; format: 1,3-5. disable: To disable the port fast-leave function. enable: To enable the port fast-leave function When you enable IGMP fast-leave processing, the switch immediately removes a port when it detects an IGMP...
  • Page 67 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Syntax: lmqi <vlan-list> <0-31744> <vlan-list>: VLAN list, available value is from 1 to 4094, and the Parameter : format is: 1,3-5. <0-31744>: Range:0~31744 tenths of sec, Default:100 tenths of sec EXAMPLE: proxy:  ...

  • Page 68: Chapter 22 Ip   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   IP   C ommands   o f   C LI   Chapter 22 IP   IP   is   an   acronym   for   Internet   Protocol.   It   is   a   protocol   used   for   communicating  ...
  • Page 69 dns-­‐proxy: Use   t his   c ommand   t o   c onfigure   D NS   p roxy.     dns-proxy disable/ enable Syntax: disable: Disable DNS proxy operation. Parameter : enable: Enable DNS proxy operation. EXAMPLE: mgmt-­‐vlan:  ...
  • Page 70 show:   Use   t his   c ommand   t o   s how   I P   i nformation.   show <cr> Syntax: Parameter : <cr> Press the carriage return key. EXAMPLE: Publication date: May., 2014 Revision A1...

  • Page 71: Chapter 23 Ip-­-Source-­-Guard   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   IP-­‐Source-­‐Guard   C ommands   o f   C LI   Chapter 23 IP-­‐Source   The   section   describes   how   to   configure   the   IP   Source   Guard   detailed   parameters  of  the  switch.  You  can  use  the  IP  Source  Guard  configure  to  ...
  • Page 72 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   <ip-address>: IP address <ip-mask>: IP mask for allowed IP address EXAMPLE: limit:   Use   t his   c ommand   t o   s et   u p   I P   s ource   g uard   p ort   limitation  ...
  • Page 73 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   port-­‐mode:   Use   t his   c ommand   t o   s et   I P   s ource   g uard   p ort   m ode.   Move <port-list>...

  • Page 74: Chapter 24 Ipv6   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   IPv6   C ommands   o f   C LI   Chapter 24 IPv6   This   section   describes   how   to   configure   the   switch-­‐managed   IPv6   information.  ...

  • Page 75: Chapter 25 Lacp   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   a colon separating each field (:). For example, 'fe80::215:c5ff:fe03:4dc7'. The symbol '::' is a special syntax that can be used as a shorthand way of representing multiple 16-bit groups of contiguous zeros;...

  • Page 76: Clear Statistics

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Configure the LACP key mode Configure the LACP mode role Configure the LACP role Show Show LACP information clear:     Use  ...
  • Page 77 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Use   t his   c ommand   to   c onfigure   t he   L ACP   r ole.   role <port-list>...

  • Page 78: Chapter 26 Lldp   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   LLDP   C ommands   o f   C LI   Chapter 26 LLDP     The   s witch   s upports   L LDP.   F or   c urrent   i nformation   o n   y our   s witch   m odel,   the  ...
  • Page 79 clear:   Use   t his   c ommand   t o   c lear   L LDP   s tatistics.   clear Syntax: Parameter : <cr> EXAMPLE: delay   :     Use   t his   c ommand   t o   c onfigure   L LDP   T x   d elay.   Publication date: May., 2014 Revision A1...
  • Page 80 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Syntax: delay <1-8192> Parameter : <1-8192>: LLDP transmission delay EXAMPLE: hold:   Use   t his   c ommand   t o   c onfigure   L LDP   T x   h old   v alue.   Syntax: hold <2-10>...
  • Page 81 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   mode:   Use   t his   c ommand   t o   c onfigure   t he   L LDP   m ode.   Syntax: mode <port-list>...
  • Page 82 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Syntax: reinit <1-10> <1-10>: LLDP reinit delay Parameter : EXAMPLE: show:   Use   t his   c ommand   t o   s how   L LDP   i nformation.   Syntax: show config/ info/ statistics Parameter :...

  • Page 83: Chapter 27 Lldp   M Edia   C Ommands   O F   C Li

    LLDP   M edia   C ommands   o f   C LI   Chapter 27 LLDP   M edia     Media   E ndpoint   D iscovery   i s   a n   e nhancement   o f   L LDP,   k nown   a s   LLDP-­‐MED,  ...
  • Page 84 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   comm-name: Postal community name. country-code: The two-letter ISO 3166 country code. county: County, parish, gun (Japan), district. district: City division, borough, city district, ward, chou(Japan). floor: Floor house-no: House number house-no-suffix: House number suffix...
  • Page 85 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   specified. datum : Map datum nad83-mllw North American Datum 1983, CRS Code 4269, Prime Meridian Name: Greenwich; The associated vertical datum is Mean Lower Low Water (MLLW).
  • Page 86 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   ecs:   Use   t his   c ommand   t o   c onfigure   L LDP-­‐MED   E mergency   Call  ...
  • Page 87 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   such as PCs or laptops. This class of endpoints frequently does not support multiple VLANs, if at all,and are typically configured to use an untagged VLAN or a single tagged data specific VLAN streaming-video Streaming Video for use by broadcast or...
  • Page 88 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   EXAMPLE: show:   Use   t his   c ommand   t o   d isplay   L LDP-­‐MED   i nformation.  ...

  • Page 89: Chapter 28 Loop   P Rotection   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Loop   p rotection   C ommands   o f   C LI   Chapter 28 Loop   The   l oop   d etection   i s   u sed   t o   d etect   t he   p resence   o f   t raffic.   W hen   s witch   receives  ...
  • Page 90 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   port   a ction.   port-action <port-list> both/ log/ shutdown Syntax: Parameter : <port-list>: available value is from switch physical port density, format: 1,3-5 both: Shut down the port and log event.

  • Page 91: Chapter 29 Port   M Irroring   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   information.   show config/ status Syntax: Parameter : config: Show loop protection configuration status: Show loop protection status EXAMPLE: shutdown:   Use   t his   c ommand   t o   c onfigure   l oop   p rotection   shutdown  ...
  • Page 92 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Port   r espectively,   s o,   t he   traffic   r eceived   b y   P ort   B   w ill   b e   c opied   t o   P ort   A   f or   m onitoring. Table 27: Port Mirroring Commands Command Function...
  • Page 93 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Publication date: May, 2014 Revision A1...

  • Page 94: Chapter 30 Mld   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   MLD   C ommands   o f   C LI   Chapter 30 MLD   A   n etwork   n ode   t hat   a cts   a s   a   s ource   o f   I Pv6   m ulticast   t raffic   i s   o nly   a n   indirect  ...
  • Page 95 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   state Enable/Disable the per-VLAN MLD Snooping throttling Set per-port Throttling Set the per-VLAN Unsolicited Report Interval compatibility:   Use   t his   c ommand   t o   s et   t he   V ersions   o f   M LD   Operating  ...
  • Page 96 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   will   b e   f iltered. filtering <port-list> <ipv6-address> Syntax: Parameter : <port-list> available value is from switch physical port density, format: 1,3-5 <ipv6-address>: IPv6 address is in 128-bit records represented as eight fields of up to four hexadecimal digits with a colon separating each...
  • Page 97 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Enable: Enable MLD proxy. EXAMPLE: qi:   Use   t his   c ommand   t o   s et   t he   p er-­‐VLAN   Q uery   I nterval. Syntax: qi <vlan-list>...
  • Page 98 router:   Use   t his   c ommand   t o   s et   R outer   P ort. router <port-list> disable/ enable Syntax: <port-list> available value is from switch physical port density, Parameter : format: 1,3-5. disable: Disable router port. Enable: Enable router port.
  • Page 99 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Syntax: snooping disable/ enable disable: Disable the global MLD snooping. Parameter : Enable: Enable the global MLD snooping. EXAMPLE: ssm-­‐range:   Use   t his   c ommand   t o   s et   M LD   S SM   R ange.   Syntax: ssm-range <ipv6-address>...
  • Page 100 Syntax: uri <vlan-list> <0-31744> <vlan-list>: VLAN list, available value is from 1 to 4094 format: 1,3-5. Parameter : <0-31744>: Range:0–31744 sec, default: 1 sec EXAMPLE: Publication date: May., 2014 Revision A1...

  • Page 101: Chapter 31 Mvr   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   MVR   C ommands   o f   C LI   Chapter 31 MVR       The   MVR   feature   enables   multicast   traffic   forwarding   on   the   Multicast   VLAN.  ...
  • Page 102 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   <ipmc-address>: Add a new entry to the group allow table. EXAMPLE: immediate-­‐leave:   Use  this  command  to  configure  the  MVR  port  state  for   immediate  ...
  • Page 103 port-­‐type:   Use   t his   c ommand   t o   c onfigure   M VR   p ort   t ype. port-type <port-list> receiver/ source Syntax: Parameter : <port-list>: available value is from switch physical port density, format: 1,3-5 receiver: Define the port as a receiver port.

  • Page 104: Chapter 32 Nas   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   NAS   C ommands   o f   C LI   Chapter 32 NAS   The   section   describes   how   to   configure   the   Network   Access   Server   parameters  ...
  • Page 105 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   clear:   Use   t his   c ommand   t o   c lear   N AS   s tatistics.   clear <port-list>...
  • Page 106 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   hold-­‐time:   Use   t his   c ommand   t o   c onfigure   t he   t ime   i n   s econds   before  ...
  • Page 107 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Syntax: port-radius-qos <port-list> disable/ enable <port-list>: available value is from switch physical port density, Parameter : format: 1,3-5 disable: Disable RADIUS-assigned QoS. Enable: Enable RADIUS-assigned QoS.
  • Page 108 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   QoS   m ode.   radius-qos disable/ enable Syntax: Parameter : disable: Disable RADIUS-assigned QoS. Enable: Enable RADIUS-assigned QoS. EXAMPLE: radius-­‐vlan:   Use  ...
  • Page 109 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   reatart:   Use   t his   c ommand   t o   r estart   t he   N AS   a uthentication   process.

  • Page 110: Chapter 33 Port   C Onfiguration   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Port   c onfiguration   C ommands   o f   C LI   Chapter 33 Port     This   chapter   describes   how   to   view   the   current   port   configuration   and   how  ...
  • Page 111 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   <LINE>: Up to 47 characters describing this interface. EXAMPLE: excessive-­‐collision:   Use   t his   c ommand   t o   c onfigure   e xcessive   c ollision   operation.  ...
  • Page 112 power-­‐saving:   Use   t his   c ommand   t o   c onfigure   p ower   s aving   operation.   power-saving <port-list> actiphy/ disable/ dynamic/ enable Syntax: Parameter : <port-list>: available value is from switch physical port density, format: 1,3-5 actiphy: Enable ActiPHY power control.
  • Page 113 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   operation.   speed-duplex <port-list> 10-full/ 10-half…/ 100fx-ams Syntax: Parameter : <port-list>: available value is from switch physical port density, format: 1,3-5 10-full: Force speed duplex to 10-full operation.

  • Page 114: Chapter 34 Port   S Ecurity   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Port   s ecurity   C ommands   o f   C LI   Chapter 34 Port   s ecurity     This  ...
  • Page 115 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   aging:     Use   t his   c ommand   t o   c onfigure   t he   a ging   m ode   a nd   period.
  • Page 116 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Parameter : <port-list>: available value is from switch physical port density, format: 1,3-5 disable: Disable port security on selected port. enable: Enable port security on selected port. EXAMPLE: reopen:  ...
  • Page 117 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Syntax: show config/ switch-status port-status <port> config: Show port security configuration Parameter : port-status: Show MAC addresses learned by port security. <port>: Port number, available value is from switch physical port density.

  • Page 118: Chapter 35 Privilege   L Evel   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Privilege   l evel   C ommands   o f   C LI   Chapter 35 privilege     This   page   provides   an   overview   of   the   privilege   levels.   The   switch   provides  ...
  • Page 119 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Publication date: May, 2014 Revision A1...

  • Page 120: Chapter 36 Private   V Lan   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Private   V LAN   C ommands   o f   C LI   Chapter 36 Private   VLAN   In  a  private  VLAN,  communication  between  ports  in  that  private  VLAN  is   not  ...
  • Page 121 private-­‐vlan:   Use   t his   c ommand   t o   c onfigure   a   p rivate   V LAN   g roup.   private-vlan <1-X> Syntax: <1-X>: Private VLAN ID. The allowed range for a Private VLAN ID is the Parameter : same as the switch port number range.

  • Page 122: Chapter 37 Qos   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   QoS   C ommands   o f   C LI   Chapter 37 QoS   The   s witch   s upports   f our   Q oS   q ueues   p er   p ort   w ith   s trict   o r   w eighted   f air   queuing  ...
  • Page 123 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   port-scheduler QoS egress port schedulers port-shaper Port shaper Add or modify QoS control entry queue-shaper Queue shaper show Show QoS information storm Configure storm rate control tag-remarking QoS egress port tag remarking...
  • Page 124 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   EXAMPLE: dscp-­‐map:   Use   t his   c ommand   t o   c onfigure   D SCP   m apping   t able.   Syntax: dscp-map <dscp-list>...
  • Page 125 Syntax: dscp-trust <port-list> <dscp-list>: DSCP list, format : 1,3,5-7 Parameter : disable: Set DSCP as untrusted DSCP. enable: Set DSCP as trusted DSCP. EXAMPLE: port-­‐classify:   Use   t his   c ommand   t o   c onfigure   Q oS   i ngress   p ort   classification.  ...
  • Page 126 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   format: 1,3-5 Switch(qos)# port-classify dscp 3 enable Switch(qos)# show port-classify <0-7>: Priority Code Point Port QoS class DP level Tag class. DSCP Based ---- --------- --------...
  • Page 127 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   port-­‐dscp:   Use   t his   c ommand   t o   c onfigure   Q oS   p ort   D SCP.   Syntax: port-dscp <port-list>...
  • Page 128 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   EXAMPLE: port-­‐policer:   Use   t his   c ommand   t o   d o   P ort   p olicer.     port-policer flow-control/ mode <port-list>...
  • Page 129 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   <1-100>: Scheduler weight. EXAMPLE: port-­‐shaper:   Use   t his   c ommand   t o   c onfigure   P ort   s haper.   Syntax: port-shaper mode <port-list>...
  • Page 130 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Parameter : <1-256>: If the QCE ID parameter <qce_id> is specified and an entry with this QCE ID already exists, the QCE will be modified. Otherwise, a new QCE will be added.
  • Page 131 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   any: Don't care <0-7>: Priority Code Point show: Show QCE smac: Configure source MAC address for this QCE <oui-address>: A frame that hits this QCE matches this source OUI address value.
  • Page 132 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Syntax: show <port-list> class-map: Show QoS class and DP level to DSCP mapping. Parameter : dscp-map: Show DSCP to QoS class and DP level mapping. dscp-translation: Show DSCP ingress and egress translation.
  • Page 133 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Switch(qos)# show port-dscp Port DSCP translation Ingress classification Egress remark ---- ---------------- ---------------------- ------------- Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Switch(qos)# show port-map 1 Port...
  • Page 134 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Switch(qos)# show qce 200 Switch(qos)# show qcl-status combined Number of QCEs: 0 Switch(qos)# show qcl-status conflicts Number of QCEs: 0 Switch(qos)# show qcl-status static Number of QCEs: 0 Switch(qos)# show qcl-status voice-vlan Switch(qos)# show queue-shaper 1...
  • Page 135 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Switch(qos)# show scheduler-mode Port Mode ---- -------- Strict Strict Strict Switch(qos)# show scheduler-weight 1 Port Queue Weight ---- ----- --------- (17%) (17%) (17%) (17%) (17%)
  • Page 136 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Kfps: Rate in kilo frame per second (Kfps) Mbps: Rate in mega bits per second (Mbps) fps: Rate in frame per second (fps) <1-10000>/ <100-10000000>: Rate EXAMPLE: tag-­‐remarking:  ...

  • Page 137: Chapter 38 Reboot   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Reboot   C ommands   o f   C LI   Chapter 38 Reboot     This   section   describes   how   to   restart   the   switch   for   maintenance.   Any   configuration  ...

  • Page 138: Chapter 39 Sflow   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   SFlow   C ommands   o f   C LI   Chapter 39 SFlow   The   sFlow   Collector   configuration   for   the   switch   can   be   monitored   and   modified  ...
  • Page 139 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   none: Sampling is disabled <0-4095>: If parameter sample_rate is 'N' then 1/N of packets is sampled. <14-200>: Configures the size of the header of the sampled frame to be copied to the Queue for further processing.

  • Page 140: Chapter 40 Single   I P   C Ommands   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Single   I P   C ommands   o f   C LI   Chapter 40 Single   IP     Single  ...
  • Page 141 Syntax: mode disable/ master/ slave disable: Disable single ip operation Parameter : master: Configure as master slave: Configure as slave EXAMPLE: show:   Use   t his   c ommand   t o   s how   s ingle   I P   i nformation.   Syntax: show config/ info Parameter :...

  • Page 142: Snmp   C Ommand   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   SNMP   C ommands   o f   C LI   Chapter 41 SNMP     Any   Network   Management   System   (NMS)   running   the   Simple   Network   Management  ...
  • Page 143 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   <WORD>: group name: max 32 chars Parameter : any: Security Model usm: Security Model AuthNoPriv: Security Level. If security_model is not usm, the security_level value must be NoAuthNoPriv.
  • Page 144 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Parameter : access: Delete snmpv3 access entry <1-14>: table index community: Delete community entry <1-4>: table index group: Delete snmpv3 groups entry <1-14>: table index trap: Delete trap entry <1-6>: table index...
  • Page 145 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Syntax: group <WORD> usm/ v1/ v2c <WORD>:user name: max 32 chars Parameter : usm: Security Model v1: Security Model v2c: Security Model EXAMPLE: mode:  ...
  • Page 146 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Parameter : access: Show snmpv3 access entry community: Show snmpv3 community entry group: Show snmpv3 groups entry mode: Show snmp configuration snmp: Show snmp community configuration trap: Show snmp trap entry user: Show snmpv3 users entry view: Show snmpv3 views entry...
  • Page 147 Syntax: user <WORD> AuthNoPriv/ AuthPriv/ NoAuthNoPriv MD5/ SHA <WORD> Parameter : <WORD>: user name: max 32 chars AuthNoPriv: Security_Level AuthPriv: Security_Level NoAuthNoPriv: Security_Level MD5: Authentication Protocol SHA: Authentication Protocol <WORD>: MD5 Authentication Password is restricted to 8 - 32 EXAMPLE: view:  ...

  • Page 148: Ssh   C Ommand   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   SSH   C ommands   o f   C LI   Chapter 42 SSH   This  section  shows  you  how  to  use  SSH  (Secure  SHell)  to  securely  access   the  ...

  • Page 149: Stp   C Ommand   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   STP   C ommands   o f   C LI   Chapter 43 STP     The   Spanning   Tree   Protocol   (STP)   can   be   used   to   detect   and   disable   network  loops,  and  to  provide  backup  links  between  switches,  bridges  or  ...
  • Page 150 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   p-AutoEdge Set the STP autoEdge port parameter p-bpduGuard Set the bpduGuard port parameter p-cost Set the STP port instance path cost p-edge Set the STP adminEdge port parameter p-mode Set the STP enabling for a port...
  • Page 151 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   EXAMPLE: MaxHops:   Use   t his   c ommand   t o   s et   M axHops. Syntax: maxhops <6-40> <6-40>: STP BPDU MaxHops (6-40)) Parameter : EXAMPLE:...
  • Page 152 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   bpduFilter:   Use   t his   c ommand   t o   e nable   o r   d isable   t he   e dge   p ort   BPDU  ...
  • Page 153 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   <0-7>: STP bridge instance no (0-7, CIST=0, MSTI1=1, ...) <1-4094>: available from 1 to 4094 EXAMPLE: p-­‐AutoEdge:   Use   t his   c ommand   t o   s et   t he   S TP   a utoEdge   p ort   parameter.
  • Page 154 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Syntax: p-cost <0-7> aggregations/<port-list> <0-200000000> <0-7>: STP bridge instance no (0-7, CIST=0, MSTI1=1, ...) Parameter : aggregations: available value is for aggregated port <port-list>: available value is from switch physical port density, format: 1,3-5 <0-200000000>: STP port path cost (1-200000000) or the value zero...
  • Page 155 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   p-­‐p2p:   Use   t his   c ommand   t o   s et   t he   S TP   p oint2point   p ort.   p-p2p aggregations/<port-list>...
  • Page 156 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   parameter.   r-role aggregations/<port-list> disable/ enable Syntax: Parameter : aggregations: available value is for aggregated port <port-list>: available value is from switch physical port density, format: 1,3-5 disable: Disable MSTP restricted role.
  • Page 157 Syntax: show CName/ Statistics/ instance/ msti-vlan/ msti-vlan / pconf show Status/ p-config <0-7> CName: Show MSTP Configuration name. Parameter : Statistics: Show STP port statistics. Status: Show STP Bridge status. <0-7>: STP bridge instance no (0-7, CIST=0, MSTI1=1, ...) instance: Show instance status. msti-vlan: Show MSTP MSTI VLAN mapping configuration.

  • Page 158: Syslog   C Ommand   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Syslog   C ommands   o f   C LI   Chapter 44 Syslog     The   S yslog   i s   a   s tandard   f or   l ogging   p rogram   m essages.   I t   a llows   separation  ...
  • Page 159 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   level:   c Use   t his   c ommand   t o   C onfigure   s yslog   l evel. Syntax: level <0-7>...
  • Page 160 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   mode:     Use   t his   c ommand   t o   c onfigure   s yslog   m ode.   Syntax: mode disable/ enable Parameter :...

  • Page 161: System   C Ommand   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   System   C ommands   o f   C LI   Chapter 45 System     After  you  login,  the  switch  shows  you  the  system  information.  This  page   is  ...
  • Page 162 Syntax: name <WORD> <WORD>: Up to 255 characters describing device name Parameter : EXAMPLE: show:   Use   t his   c ommand   t o   s how   s ystem   i nformation.   Syntax: show <cr> <cr> Press the carriage return key. Parameter : EXAMPLE: Publication date: May., 2014...

  • Page 163: System   T Ime   C Ommand   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   System   t ime   C ommands   o f   C LI   Chapter 46 Time   This   page   configures   the   switch   Time,   including   Time   Configuration   and   NTP  ...
  • Page 164 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Parameter : disable: Disable Daylight Savings operation. enable: Enable Daylight Savings operation. <1-1440>: Minute. Time Set Offset. By-dates: Manually enter day and time that DST starts and ends. <YYYY:MM:DD>: Day that DST starts <HH:MM>: Time that DST starts <YYYY:MM:DD>: Day that DST ends...
  • Page 165 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   < MM- DD-YYYY >: Date and time format is MM-DD-YYYY HH:MM:SS < YYYY-DD-MM >: Date and time format is YYYY-MM-DD HH:MM:SS < 12Hours >: The time is always represented in the 12-hour system <...
  • Page 166 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   time-­‐zone:   Use   t his   c ommand   t o   c onfigure   s ystem   t ime   z one.   time-zone <HH:MM>...

  • Page 167: Upnp   C Ommand   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   UPnP   C ommands   o f   C LI   Chapter 47 UPnP   UPnP   i s   a n   a cronym   f or   U niversal   P lug   a nd   P lay.   T he   g oals   o f   U PnP   a re   t o   allow  devices  to  connect  seamlessly  and  to  simplify  the  implementation  ...
  • Page 168 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   EXAMPLE: ttl:     Use   t his   c ommand   t o   c onfigure   t he   T TL   v alue   o f   t he   I P   header  ...

  • Page 169: Vcl   C Ommand   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   VCL   C ommands   o f   C LI   Chapter 48 VCL   VLAN   Control   List   indicates   two   types   of   VLANs:   MAC   address-­‐based   VLAN  ...
  • Page 170 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   <0x00-0xff>: DSAP value <0x00-0xff>: SSAP value snap: Delete protocol-based VLAN SNAP protocol to group mapping. <oui-address>: address, format 00-40-c7 <0x0000-0xffff>: Protocol ID is the Ethernet type field value for the protocol running on top of SNAP.
  • Page 171 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   <0x00-0xff>: SSAP value snap: protocol-based VLAN SNAP protocol to group mapping <oui-address>: address, format 00-40-c7 <0x0000-0xffff>: Protocol ID is the Ethernet type field value for the protocol running on top of SNAP.

  • Page 172: Vlan   C Ommand   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   VLAN   C ommands   o f   C LI   Chapter 49 VLAN     You  can  assign  a  specific  VLAN  for  management.  The  management  VLAN   is  ...
  • Page 173 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   access: Untag all frames. hybrid: Tag all frames except VLAN ID same as PVID. trunk: Tag all frames. EXAMPLE: forbidden:     Use  ...
  • Page 174 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   format: 1,3-5 disable: Disable ingress filtering. enable: Enable ingress filtering. If ingress port is not a member of the classified VLAN of the frame, the frame is discarded. EXAMPLE: port-­‐type:  ...
  • Page 175 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Parameter : forbidden: Show VLAN forbidden group port-config: Show VLAN port configuration port-status: Show VLAN port status combined: VLAN port status for combined VLAN Users gvrp: VLAN port status for GVRP mstp: VLAN port status for MSTP mvr: VLAN port status for MVR...
  • Page 176 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   custom   S -­‐ports.   This   i s   a   g lobal   s etting   f or   a ll   t he   c ustom   S -­‐ports.   tpid Syntax: Parameter :...

  • Page 177: Voice   V Lan   C Ommand   O F   C Li

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Voice   V LAN   C ommands   o f   C LI   Chapter 50 Voice   VLAN     Voice  ...
  • Page 178 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   delete:     Use   t his   c ommand   t o   d elete   a   c ommand.   delete oui <oui-address>...
  • Page 179 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Syntax: port-mode <port-list> auto/ disable/ force <port-list>: available value is from switch physical port density, Parameter : format: 1,3-5 auto: Enable auto detect mode. It detects whether there is VoIP phone attached on the specific port and configures the Voice VLAN members automatically.

  • Page 180: Global   C Ommand   O F   C Li

    Global   C ommands   o f   C LI   Chapter 51 Global   Global   commands   are   probably   the   most   commonly   used   commands   in   the   C LI   c onsole.   U se   f or   g lobal   c onfiguration   a t   a ny   l evel   o f   c ommand. Table: Global Commands Command Function...
  • Page 181 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   Parameter : <cr>: Press the carriage return key. EXAMPLE: history:   Use   t his   c ommand   t o   s how   a   l ist   o f   p reviously   r un   commands.  ...

  • Page 182: Restore User

    CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   logout:   Use   t his   c ommand   t o   d isconnect. logout Syntax: <cr>: Press the carriage return key. Parameter : EXAMPLE: quit:  ...
  • Page 183 CLI   R eference   G uide   Copyright   2015.   Black   Box   Corporation.   save:   Use   t his   c ommand   t o   s ave   a   r unning   c onfiguration.   Syntax: save start/ user Parameter :...
  • Page 184 About Black Box Black Box provides an extensive range of networking and infrastructure products. You’ll find everything from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by free, live 24/7 Tech support available in 60 seconds or less.

This manual is also suitable for:

Lgb1126aLgb1148a

Table of Contents
