Black Box LGB1001A Quick Start Manual

8-, 16-, and 24-Port 1000BASE-TX L2
Managed Ethernet Switches
What's Included
Before you install an 8-, 16-, or 24-Port 1000BASE-TX L2 Managed Ethernet Switch, verify that the package
includes the following items.
• 8-, 16-, or 24-Port 1000BASE-TX L2 Managed Ethernet Switch
• CD-ROM containing a user's manual in PDF format
• This guide
• AC power cord
• DB9 female to DB9 female RS-232 cable
• Rackmount kit (16- and 24-port switches only)
• (4) rubber feet
If anything is missing or damaged, contact Black Box at 724-746-5500.

Power Requirements

The switch requires an AC line, 100–240 VAC, 50–60 Hz, and 13 watts.
Quick Installation
1. For the 8-port switch, install the rubber feet and place it on a desktop. For the 16- or 24-port switch, attach
the rubber feet and place it on a desktop, or install the switch in the rack with mounting hardware.
2. Connect the switch to an AC power source.
3. Use Category 5 UTP cable to connect the RJ-45 connectors on switch ports 1–8, 1–16, or 1–24.
CUSTOMER
SUPPORT
INFORMATION

Quick Start Guide

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: info@blackbox.com
MAY 2006
LGB1001A
LGB1002A
LGB1003A
