Summary of Contents for Intel PRO/1000 T IP Storage
- Page 1 Intel ® PRO/1000 T IP Storage Adapter Bringing Gigabit Ethernet to Network Storage Quick Installation Guide Full Manual on CD. See inside for details.
-
Page 2: Additional Information
Intel make any commitment to update the information contained herein. * Other names and brands may be claimed as the property of others. Intel is a trademark or registered trademark of Intel Corporation or its subsidiaries in the United States and other countries. -
Page 3: Table Of Contents
Adapter Specifications ........17 Intel Automated Customer Support ......18 How to Use This Guide The Intel®... -
Page 4: System Requirements
System Requirements Before installing the Intel PRO/1000 T IP Storage Adapter, check your system for the following minimum configuration requirements: • One open 32-bit or 64-bit bus master PCI slot • 64 MB of system memory • The latest BIOS for your computer •... -
Page 5: Inserting The Adapter In The Computer
7. Turn the power on. The computer PCI BIOS automatically assigns resources to the adapter(s). If you receive a PCI configuration error, see “Troubleshooting” in the User Configuration Guide on the CD. Intel® PRO/1000 T IP Storage Adapter Quick Installation Guide... -
Page 6: Attaching The Network Cable
(10/100/1000) on a single port. Refer to the switch documenta- tion for details. For 10Base-T, use Category 3, 4, or 5 twisted-pair wiring. Residential environments require the use of a Category 5 cable. Intel® PRO/1000 T IP Storage Adapter Quick Installation Guide... -
Page 7: Installing/Uninstalling The Drivers And Updating Driver Information
Found New Hardware Wizard. Using the Wizard, follow this procedure to install the correct driver. 1. Insert the PRO/1000 T IP Storage Adapter CD in the CD-ROM drive. If the CD autorun program starts, close this window at this time. - Page 8 Linux Red Hat* Version 7.1 1. Place the Intel PRO/1000 T IP Storage Adapter CD in the appropriate drive. To install drivers for Linux Red Hat Version 7.1, you can use the Gnome RPM GUI tool, as shown in Figure 3.
- Page 9 5. Highlight the specific package you want to install (the “is1000-1.0- 1.i386.rpm” package has been highlighted) and click on the Add button. The screen shown in Figure 6 will display. Figure 5. Add Packages screen Intel® PRO/1000 T IP Storage Adapter Quick Installation Guide...
- Page 10 Click on the Query button at the top of the screen A pop-up screen (such as that shown within Figure 7) displays the installed files as a result of that query. Intel® PRO/1000 T IP Storage Adapter Quick Installation Guide...
- Page 11 To uninstall drivers, follow this procedure: 1. Go to Device Manager. 2. Expand SCSI and RAID controllers. 3. Right-click the mouse on “Intel PRO/1000 T IP Storage Adapter” and click on Uninstall. Uninstalling Drivers (NT4) To uninstall drivers, follow this procedure: 1.
- Page 12 Versions of adapter firmware are tied to a specific version of the iSCSI specification (see the Late Breaking News document for complete details). If it is necessary to update the PRO/1000 T IP Storage Adapter firmware, use the “frucmd” command-line utility. The syntax for updating the firmware from the DOS prompt is frucmd -d -f ixworks.bin...
-
Page 13: Basic Configuration Information
Complete installation and configuration information is available on the CD-ROM. Only initial configuration information is presented in this document. To begin configuring the PRO/1000 T IP Storage Adapter, go to the Control Panel and double-click the "Intel PROSet for IP Storage" icon ®... - Page 14 Before you can add Targets to the configuration, you must first configure the network settings. Figure 9. Intel® PROSet for IP Storage Configuration Screen Click on the “Network Settings” tab to display the Network Settings screen (Figure 10). Intel® PRO/1000 T IP Storage Adapter Quick Installation Guide...
- Page 15 The Unique Name for Adapter area, where you enter a unique name for the adapter in the Name field. Refer to the User Configuration Guide on the CD-ROM for complete configuration details and maintenance information. Intel® PRO/1000 T IP Storage Adapter Quick Installation Guide...
-
Page 16: Basic Troubleshooting
Configuration Guide and try the recommended solutions If none of these works, check the Late-Breaking News document that came in the box with the Intel PRO/1000 T IP Storage Adapter, or check the Intel support Web site. See Intel Automated Customer Support for information on connecting to Intel’s online services. -
Page 17: Adapter Specifications
Operating Temperature/Humidity: 0-55 degrees C; 85% at 55 degrees C Hardware Certifications: FCC B, CE, UL 1950, CSA 950, BSMI, VCCI Class 2 INTEL BACKING Limited lifetime warranty; 90-day money-back guarantee (U.S./Canada only) Intel® PRO/1000 T IP Storage Adapter Quick Installation Guide... -
Page 18: Intel Automated Customer Support
For more information about adapter configuration or other topics, see the online User Configuration Guide. To view the guide, insert the Intel CD in your drive and wait for the Autorun to display. Click the User Configuration Guide button to view the guide. Note that a web browser is required to view the guide. - Page 19 Intel® PRO/1000 T IP Storage Adapter Quick Installation Guide...
- Page 20 5200 N.E. Elam Young Parkway Hillsboro, OR 97124-6497 Intel Corporation assumes no responsibility for errors or omissions in this document. Nor does Intel make any commitment to update the information contained herein. * Other product and corporate names may be trademarks of other companies and are used only for explanation and to the owners’...
