Adapter Specifications

CONNECTIONS
IEEE standard/network topology: 10Base-T, 100Base-T, 1000Base-T
Wiring/Connections: CAT-5, 4 pair (1000Base-T)/RJ-45
HOST BUS ADAPTER PRODUCT FEATURES
• Plug and Play Specification support
• Auto-negotiation, full duplex capable
• Power Management (Network Device Class, Power Management Reference
Specification 1.0a)
• 32 MB of external SDRAM for context memory
• 4 MB Flash
• Single ported adapter
• Standard PCI form factor
• Field upgradeable firmware and software via Flash
PCI v2.2 buses supported: 64/66, 64/33, 32/66, and 32/33
NETWORK MANAGEMENT
• SNMP manageable
OPERATING SYSTEMS SUPPORT
Microsoft Windows* 2000 (SP2 or higher), NT* 4.0 (SP 6.0 or higher), Linux
Red Hat* Version 7.1 (2.4 kernel)
TECHNICAL FEATURES
Data rate(s) supported per port: 10/100/1000 Mbps
External Memory: 32 MB ECC SDRAM; 4 MB Flash
IEEE Support: 802.2, 802.3z, and 802.3ab
Data transfer mode: Bus-master DMA
Controller or processor: Intel® XScale™ 80200
Typical power consumption: 7.8 - 8 Watts
Data path width: 32-bit and 64-bit PCI
MAC on-board memory: 64 KB
Interrupt levels: INTA
IETF Support: iSCSI draft standard 0.6+ (visit http://www.ietf.org to download
latest standards). See Late Breaking News for instructions on downloading
firmware to support later versions of the iSCSI specification.
MAC: Intel® 82544EI
I/O Companion Chip: Intel® 80312
Operating Temperature/Humidity: 0-55 degrees C; 85% at 55 degrees C
Hardware Certifications: FCC B, CE, UL 1950, CSA 950, BSMI, VCCI Class 2
INTEL BACKING
Limited lifetime warranty; 90-day money-back guarantee (U.S./Canada only)
