Revolabs FLX2 Quick Setup Manual

Revolabs FLX2
Congratulations on your purchase of the Revolabs FLX2
state of the art technology providing high bandwidth audio and enabling clear, reliable, untethered
communications with your telephone, PC, mobile device, and video conferencing system.
The Revolabs FLX2 Conference Phone provides enhanced freedom for telephone and video conferences by
allowing independent locations of the microphones and the speaker during the call.
Unpacking
Your Revolabs FLX2™ Conference Phone package
contains the items listed in the table. When unpacking
the system be sure to take inventory of all parts to
ensure that nothing is missing. If parts are missing,
please contact your retailer.
Revolabs FLX2 Conference Phone components are
partially charged. Please charge the Speaker, the
Microphones, and the Dialer for at least 8 hours or
overnight before using the system.
The Revolabs FLX2 Conference Phone comes with
two different power supplies. Please ensure that you
use the correct power supply when connecting the
Base Station and the Charger Base.
Connecting the Base Station
Place the Base Station close to the analog telephone outlet you want to use for
the conference phone.
Connect the Base Station to the telephone network using the provided RJ 11
Telephone cable.
Use the 5 Volt power supply marked with a green ring to connect the Base
Station to a power outlet. The Base Station will power up.
Connecting the Charger Base
Place the Charger Base at a location where you can easily access the
Microphones and the Speaker for your conference calls, e.g. on a side board, a
desk, or the conference table.
Connect the Charger Base to the power outlet using the provided 12-15V power
supply.
Place the Speaker, the Microphones, and the Dialer in the respective openings of
the Charger Base to charge them.
The Dialer and Speaker will automatically connect to the Base Station after a
short time if it is powered up. You will hear a confirmation chime from the
Speaker once the system is ready for use. The Microphones only connect when
taking out of the Charger Base, or if the multi-function button is pressed while in
the Charger Base. If the Speaker or the Dialer are not powered up, take them
out of the Charger Base for a few seconds and put them back in. This will switch
on the component.
TM
– Quick Setup Guide
TM
Wireless Conference Phone. This system utilizes
FLX2 Base Station
FLX2 Charger Base
FLX Speaker
FLX Dialer
2 FLX Microphones (lapel – omni –
directional microphone shown)
12-15V AC adapter for the Charger Base
5 V AC adapter for the Base Station
RJ11 Telephone Cable
Contents
