2.1 Connect camera to power and network
Connect the camera to your router or switch using the network cable.
Using the included power adaptor, plug one end into the Power Connector and
plug the other end into a power outlet.
NOTICE
Please note that for initial setup, you need to connect the camera directly to your
router or switch with a network cable. You cannot connect wirelessly to the
camera without first setting it up via a network cable.
You can set up the wireless via the App or web browser quickly.
Instructions for wireless setup are included later, within this guide.
2.2 Connect using the PoE (Optional)
The Bullet Pro camera can be either connected with the included power adapter
and network cable, or optionally with an Ethernet cable that is connected to an
802.3af compatible PoE Switch or PoE Injector. With a PoE setup, the Ethernet
cable will transmit both power and data over a single cable eliminating the need
for the power adapter.
6

2. Hardware Installation

Extension Box
Power adaptor
Router
