Phylink Bullet Pro PLC-336PW Quick Install Manual

Hide thumbs Also See for Bullet Pro PLC-336PW:
Table of Contents

Advertisement

Quick Links

Quick Install Guide
For
Outdoor Network Camera
Quick Install Guide
VERSION 2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bullet Pro PLC-336PW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Phylink Bullet Pro PLC-336PW

Summary of Contents for Phylink Bullet Pro PLC-336PW

  • Page 1 Quick Install Guide Outdoor Network Camera Quick Install Guide VERSION 2.0...
  • Page 2 This installation guide provides basic instructions for installing the PLC-336PW Outdoor Waterproof IP camera on your network. By following these instructions, you can quickly complete the camera installation on Android, iOS and computer (Windows or Mac OS). Verify the package contents Verify the package contents against the list below.

  • Page 3: Table Of Contents

    Get Support - For technical questions, please email us at support@phylink.com You can also access related technical articles on our support website - For the latest documentation and updates, please visit www.phylink.com Scan QR Code to get support Contents 1. Hardware Overview ................2 2.

  • Page 4: Hardware Overview

    1. Hardware Overview Wi-Fi Antenna Sun Shield Camera Cable Camera’s UID Sticker Front Shell Mount Bracket Extension Box Infrared LED Light Sensor Lens Infrared LED Used to illuminate the camera's field of view at night. Light Sensor The light sensor monitors ambient lighting conditions and switches between color and infrared accordingly.

  • Page 5: Power Connector

    Extension box Used to connect the camera to the power, network, amplified speaker and wired alarm devices. Ethernet RJ45 connector Power Connector General I/O Terminal Audio line out Power indicator LED Power Connector Connects to the included DC 12V power adapter. Audio line out 3.5mm Jack, connects to the amplified speaker.

  • Page 6: Reset Button

    Reset Button Press this button to reset the camera back to Reset Button Factory Settings. Make sure the camera is powered on. Press and hold this button for second or more to reset the camera. Note that all settings will be restored to factory default.

  • Page 7: Mounting Accessories

    Camera Cable The cable extending from the rear of camera is 90cm, which is long enough to route through a building's wall. It would make the installation flexible and easy. Camera Cable Connector Extension box can be separated from the camera cable and connected to the camera with a waterproof connector.

  • Page 8: Hardware Installation

    2. Hardware Installation 2.1 Connect camera to power and network Connect the camera to your router or switch using the network cable. Using the included power adaptor, plug one end into the Power Connector and plug the other end into a power outlet. Power adaptor Extension Box Router...
  • Page 9 Extension Box PoE Injector Power adaptor Router PoE injector connection diagram 2.3 Mount the antenna (Optional) If using a Wi-Fi network connection, the provided external antenna must be mounted to the RP-SMA connector at the rear of camera main body. RP-SMA connector Remove the protective cap on the...

  • Page 10: Micro Sd Card Installation

    To learn how to format the SD card, please refer to the user manual or related technical articles on the Phylink support website. The camera only supports the FAT32 file system; other formats will not be recognized.

  • Page 11: Mount The Camera

    2.5 Mount the camera Before mounting, please ensure wireless settings are completed and operational – to set wireless up, you need to connect the camera directly to your router with an Ethernet cable. If you plan to use Wi-Fi transmission, the Wi-Fi must be setup before the camera is disconnected from the Ethernet cable of the local network.
  • Page 12 2.5.4 Mount the Extension Box The Extension Box is used to connect the camera to the power, network, amplified speaker and wired alarm devices. The Extension Box can be separated from the camera cable. This is a good idea when you need to put the camera cable through a building's wall. NOTICE The Camera Cable Connector has a metal locking ring to fix the cable to the Extension Box, you must unscrew the locking ring before you unplug the...
  • Page 13 If you wish to mount the Extension Box outdoors, you must put it inside the Waterproof Box. Outdoor Indoor Building wall Power cord Network cable A roughly 1/4 inch diameter hole Waterproof Box will be required for either a network cable or the DC plug at the end of the power cord to pass through Mount the extension box outdoors...
  • Page 14 2.6 Reset the camera back to factory settings If you forget your admin password or have any other reason to reset the camera to its factory settings, please use the following procedure: 1. Make sure the camera is powered on. 2.
  • Page 15 Digital output , Max. 40VDC, max. 400mA Digital input, OPEN/Short-to-GND Ground For more details about how to use General I/O terminal , please read the User Manual on the included installation CD or download it from the Phylink support website.

  • Page 16: Quick Installation For Ios Device

    3. Quick installation for iOS device STEP1 Get the free PHYCAM App from App Store. Ensure the camera is connected to your router with the Ethernet cable and powered on. Start the App and the "My Camera" screen will appear. Press the “Add”...
  • Page 17 STEP2 Assign a "Name" to the camera to help identify this camera if more than one camera is in use. ( The default name is "Camera". ) Enter the "Password". ( The default Password is "admin". ) Press "Connect" and the App will connect to the camera. Press "Setup WiFi"...
  • Page 18 STEP3 symbol on the right side of the camera, the sliding menu will be displayed. 1. Add camera 2. View the app version 3. Sliding menu 4. Detect camera 5. Edit Camera, change settings and password 6. Audio mode 7. Video mode...

  • Page 19: Setting Up Wi-Fi Via Ios Device

    4. Setting up Wi-Fi via iOS device symbol on the right side of the camera, the sliding menu will be displayed. Tap the Edit Camera icon from the sliding menu. And then go to Advanced Setting > Network Setup .
  • Page 20 Press “WiFi Networks” , then the camera will search for available Wi-Fi networks around it. Select your network from the list. Type your Wi-Fi password and press the “Join” button to complete the Wi-Fi setup. After a successful wireless setup, you can remove the network cable and the camera should work through the wireless network after a short delay.

  • Page 21: Quick Installation For Android Device

    5. Quick installation for Android device STEP1 Get the free PHYCAM App from Google Play. Ensure the camera is connected to your router with the Ethernet cable and powered up. Start the App and the following screen will appear. Press to add a new camera.
  • Page 22 STEP2 Enter the "Password". ( The default Password is "admin". ) Assign a "Name" to the camera to help identify this camera if more than one camera is in use. ( The default name is "Camera 0". ) Press the "OK" button and a pop up tips window will say "Do you want to setup the camera to work over WiFi now?".
  • Page 23 Press on to view list of available networks. Select your wireless network from the list. Wi-Fi Setting None SSID Disconnect PHYLINK PHYLINK TP-Link_245416 FAST_11DA2E phr-002 Type in your Wi-Fi password and then press "Apply" to save the settings. After a successful wireless setup, remove the network cable and the camera should work through the wireless network after a short delay.
  • Page 24 STEP3 symbol on the right side of the camera, the sliding menu will be displayed. 1. Add camera 2. View the app version and get support info 3. Sliding menu 4. Detect camera 5. Edit Camera, change settings and password 6.
  • Page 25 1. Quit live video mode 2. View the recorded Videos and photos 3. Start recording / Stop recording 4. Take a snapshot 5. Enable or disable the microphone of the camera 6. Enable or disable the speaker...

  • Page 26: Setting Up Wi-Fi Via Android Device

    6. Setting up Wi-Fi via Android device symbol on the right side of the camera, the sliding menu will be displayed. Tap the Edit Camera icon from the sliding menu. And then go to Advanced Setting > Network Setup .
  • Page 27 Press “Wi-Fi Setting” , then the camera will search for available Wi-Fi networks around it. Wi-Fi Setting SSID None Disconnect PHYLINK PHYLINK TP-Link_245416 FAST_11DA2E phr-002 Press on to view the list of available networks. Select your wireless network from the list.

  • Page 28: Camera Installation On Pc Or Mac

    Phylink Camera Live is a software which makes you find and view your camera from the Internet easily. Phylink Camera Live is also a tool that can search for your camera within your local network. You can configure and view your camera via most popular web browsers such as FireFox, Internet Explorer, Chrome and Safari.
  • Page 29 STEP2 Click the Phylink Camera Live icon on your desktop, click on to add a camera. Setup Camera Multilive Video Album A pop-up window will appear as below. Add Camera Discover Password Name Cancel Click the "Discover" button and the program will automatically search for an available camera within your local network (LAN).
  • Page 30 STEP3 Enter "password" ( The default password is "admin" ). And then enter a name for your camera. Click on "OK" to save. Add Camera Discover C3S998FY5G639HPGU7T1 Password Name Home Cancel After a few minutes the chain icon will turn green , which indicates that the camera is online and connection is established.
  • Page 31 7.2 Play, Delete and Modify cameras Click on “menu” button to play/delete/modify camera. Click on ”play” button for live viewing. Or you can double click on the camera preview for live viewing. Click on ”delete” button to delete a camera. In the lower left corner of camera preview, there is a chain icon which use to indicate camera’s connection status.
  • Page 32 Click ”play” button or double click on a camera preview to enter the live viewing mode. You can perform various operations with the Play Control Panel at the bottom of live viewing window. Setup Camera Multilive Video Album 1920x1080 8FPS 1.3Mbps Live Viewing Window Play Control Panel Take a snapshot...
  • Page 33 7.3 Muliti-viewing on one screen Click on "Muliti-Live" button from main toolbar, click selection icon then the Select Camera window will pop up as below. Video Album Setup Multilive Select Camera Bedroom School Home Office Cancel All cameras will be listed. Select the right cameras for Muliti-viewing on one screen. Click a camera preview to add it to the Muliti-viewing window, the camera preview will have a blue border.
  • Page 34 7.4 Video recording, Storage and Viewing Click on “Video” icon from main toolbar, and select the camera from the list to view and play back the recorded video on your computer. Setup Camera Multilive Video Album Home Office Bedroom school 20140206_102606.mov 20140208_102605.mov 20140108_092905.mov...
  • Page 35 7.5 Snapshots, Storage and Viewing Click on “Album” icon from main toolbar, and select the camera from the list to view the snapshots on your computer. Setup Camera Multilive Video Album Home Office Bedroom school 20140206_102606.jpg 20140208_102605.jpg 20140108_092905.jpg 20140108_092903.jpg...

  • Page 36: Access Camera Via Web Browser

    8. Access camera via Web Browser 8.1 Login to your camera via a browser Phylink Camera Live is a tool that can search for your camera on the local network. You can configure and view your camera via most web browsers such as FireFox, Internet Explorer, Chrome and Safari.
  • Page 37 Password: admin ( The default password is "admin". ) NOTICE 1. Phylink Camera Live can only search for a camera within your local network. That means your computer and your camera need to be connected to the same router via Ethernet or Wi-Fi.
  • Page 38 8.2 Wireless setup on PC or Mac via browser Please note that if you have already set up the wireless connection using the App on a smart phone , you can skip this step. After logging in to the camera via the browser, click "Setting" button to configure the camera.
  • Page 39 For more advanced settings, (such as Record, Task Management, Motion Detection, Alarm Action, Video Quality and more) please read the User Manual on the installation CD included with this package or download from the Phylink support website.

  • Page 40: Technical Support

    Technical support If you encounter any problems, do not return the product to the store If you have any questions please email us at support@phylink.com All Phylink hardware products have a one year warranty. We offer free technical support within warranty time.
