2.5 Mount the camera

Before mounting, please ensure wireless settings are completed and operational
– to set wireless up, you need to connect the camera directly to your router with
an Ethernet cable.
If you plan to use Wi-Fi transmission, the Wi-Fi must be setup before the camera
is disconnected from the Ethernet cable of the local network. Minimum signal
strength of 3 bars is required for 1080P video transmission. Please ensure the
required signal strength is available at the place of installation, prior to mounting
the camera.

2.5.1 Mount the bracket

Drill three holes into the wall or ceiling.
Then hammer the supplied plastic
wall plug into the holes. Mount the
bracket and camera with supplied screws.
2.5.2 Adjust the angle of the bracket
Adjust the angle of the mount bracket to aim at
the shooting area and then screw the hex screw
on mount bracket with the included hex wrench.
The supplied L-type hex wrench is exclusively
designed to match hex screw on mount bracket.
In case you will need to adjust the lens later,
do not discard the wrench.
2.5.3 Drop ceiling mounting
The camera can be mounted under the
eaves or ceiling.
You can replace one of the Sun Shield
mounting screws with the included
special mounting nut to mount the
camera bracket from above.
Mount bracket
Sun shield
mounting screw
Mounting nut
