1020W ANGLE GRINDER
After Sales Support
Now you have purchased a Power Craft
product you can rest assured in the
knowledge that as well as your 3 year
parts and labour warranty you have
the added peace of mind of dedicated
helplines and web support.
User Guide & Warranty
UK HELPLINE NO
IRELAND HELPLINE NO
WEB SUPPORT
MODEL NUMBER: PAG-125/1020
AFTER SALES SUPPORT
0905-460005
www.heltec.eu
1520-932626
Advertisement
Table of Contents
Related Manuals for Power Craft 1020W
Summary of Contents for Power Craft 1020W
- Page 1 1020W ANGLE GRINDER User Guide & Warranty After Sales Support AFTER SALES SUPPORT Now you have purchased a Power Craft product you can rest assured in the UK HELPLINE NO 0905-460005 knowledge that as well as your 3 year IRELAND HELPLINE NO...
-
Page 2: Table Of Contents
Contents Introduction Machine specifications Safety instructions General Safety Instructions Additional safety instructions Assembly - Assembling the hand grip - Assembling and removing the protective cover - Mounting a grinding disc - Mounting cutting, grinding discs and roughing discs Operation - Deburring - Cutting Maintenance Exploded view... -
Page 3: Introduction
3 Year Warranty. We hope you will enjoy using your purchase for many years to come. 1020W ANGLE GRINDER Always read the instructions for electrical products carefully before use. It will help you understand your product better and avoid unnecessary risks. -
Page 4: Machine Specifications
Machine specifications Technical specifications Voltage 230 V~ Frequency 50 Hz Power input 1020 W No-load speed 11000/min Disc diameter 125 mm Spindle thread size Weight 2.6 kg Lpa (sound pressure) 94.0 dB (A) Lwa (sound power) 107.0 dB (A) Vibration value 8.26 m/s Product information Fig. - Page 5 Machine specifications Fig. A (page 4) 1. On/off switch 2. Guard 3. Grinding disc (not included) 4. Spindle lock 5. Side handle 6. Switch lock Package contents 1 Angle grinder 1 Side handle 1 Spanner 1 Protective guard 1 Carbon brush set 1 Safety goggles 1 Instructions manual 1 After sales card...
-
Page 6: Safety Instructions
Safety instructions The following symbols are used in these instructions: Read the instructions carefully. Conformity with the relevant EU safety directives. Class II machine - double insulation - earth connection not required. Danger of life and risk of injury as well as risk of damage to the machine in case of non-adherence to the safety instructions in these instructions of use. -
Page 7: General Safety Instructions
Safety instructions Faulty and/or discarded electrical or electronic machines have to be collected at the appropriate recycling locations. General Safety Instructions Attention! When using electric machines always observe the safety regulations applicable in your country to reduce the risk of fire, electric shock and personal injury. - Page 8 Safety instructions 9. Use safety glasses. Also use face or dust mask when operation is dusty. Use ear protection. 10. Connect dust extraction equipment If devices are provided for the connection of dust extraction and collection facilities ensure these are connected and properly used. 11.
-
Page 9: Additional Safety Instructions
Safety instructions customer service centre unless otherwise indicated elsewhere in this instructions manual. Have defective switches replaced by our customer service centre. Do not use tool if the switch does not turn on and off. 21. Warning. The use of any other accessory or attachment other than recommended in this operation instructions or the catalogue may present a risk of personal injury. - Page 10 Safety instructions the machine in case of abnormal vibrations or occurrence of another defect. Carefully inspect the machine and grinding disc before switching the machine on again. • Make sure that sparks do not put people into danger or that they contact highly flammable substances.
- Page 11 Safety instructions Replacing cables or plugs Repairs and servicing should only be carried out by a qualified technician or service firm. Using extension cables Only use an approved extension cable suitable for the power input of the machine. The minimum conductor size is 1.5 mm .
-
Page 12: Assembly
Assembly Assembling the hand grip Fig. A The hand grip is suitable for either left or right-handed use. • Turn the hand grip (Fig A, 5, page 4) to the notch on the right side of the machine for left-handed use. •... -
Page 13: Mounting A Grinding Disc
Assembly • Place the fixing-ring (8) on the guard: the ring-holes have to be on the screw-holes. • Mount the guard and fixing-ring with help of the 4 screws and washers (7). • To dismantle the protective cover, proceed in reverse order. Be aware the screws are tightened well enough. -
Page 14: Mounting Cutting, Grinding Discs And Roughing
Assembly When doing so, ensure that the flange nut is fitted in the correct direction, determined by the thickness of grinding disc (description in the next section). Ensure that the top flange has been fully turned onto the spindle and that the grinding disc is firmly clamped between the two flanges so that the disc cannot move. -
Page 15: Operation
Operation Always follow the safety instructions and keep to the applicable regulations. Hold the machine away from the workpiece when turning it on and off because the grinding disc could damage the workpiece. • Clamp the workpiece firmly or use another method to ensure that it cannot move while working. -
Page 16: Cutting
Operation Never use abrasive cutting discs for deburring work! Cutting Fig. G Maintain firm contact with the workpiece to prevent vibration and do not tilt or apply pressure and when cutting. Use moderate pressure when working, appropriate to the material that is being worked on. Do not slow down grinding discs by applying sideways counter pressure. - Page 17 Operation The lock can be released by quickly pressing on the ON/OFF/ switch (1). The grinder will continue to run after it is turned off. Only lay the machine down once the motor has completely stopped turning. Do not put the machine on a dusty surface. Dust particles can penetrate the machine.
-
Page 18: Maintenance
Maintenance Disconnect the machine from the mains before carrying out cleaning and maintenance work. This machine has been designed to operate over a long period of time with a minimum of maintenance. Continuous satisfactory operation depends upon proper machine care and regular cleaning. Cleaning Regularly clean the machine housing with a soft cloth, preferably after each use. - Page 19 Maintenance Troubleshooting • Machine fails to • Power turned off • (Extension) cable operate: damaged • The motor does not • The extension cable • The mains voltage is reach maximum is too thin and/or too lower than 230 V speed: long •...
- Page 20 UK Helpline 0905-460005 • Ireland Helpline 1520-932626 Web Support: www.heltec.eu Model Number: PAG-125/1020...
- Page 21 UK Helpline 0905-460005 • Ireland Helpline 1520-932626 Web Support: www.heltec.eu Model Number: PAG-125/1020...
-
Page 22: Exploded View
Exploded view Parts list Description Position 406847 Outer flange 406846 Inner flange 407008 Protective guard 408642 Spindle gear 406952 Auxiliary handle 408643 Pinion gear 408640 Rotor 408641 Stator 407009 Switch 406814 Spanner UK Helpline 0905-460005 • Ireland Helpline 1520-932626 Web Support: www.heltec.eu Model Number: PAG-125/1020... -
Page 23: Warranty
EC directives. Product Description: 1020W ANGLE GRINDER Model: PAG-125/1020 In confirmity with the following standards or standardization documents: EN55014-1, EN55014-2, EN50144-1,... - Page 24 1020W ANGLE GRINDER PAG-125/1020 If you are requested by the manufacturer to return the item for repair please complete the enclosed section and send it together with your product and your receipt (proof of purchase) to the service address shown below.
