SVS 100 - S
EAMLESS
V
S
IDEO
WITCHER
Genlock-free
seamless switching
Accepts up to four
NTSC or PAL video
inputs
Composite and
S-video inputs
and outputs
Color, tint, brightness,
and contrast controls
for each source
24 digital
switching effects
Top & bottom
vertical blanking
controls
128 picture control
user preset memories
Built-in stereo
audio switcher
RS-232/422 control
Advertisement
Related Manuals for Extron electronics SVS 100
Summary of Contents for Extron electronics SVS 100
- Page 1 Composite and S-video inputs and outputs Color, tint, brightness, and contrast controls for each source 24 digital switching effects SVS 100 - S EAMLESS IDEO WITCHER Top & bottom vertical blanking controls 128 picture control user preset memories Built-in stereo...
- Page 2 I Executive mode – Locks out picture controls, audio controls, or third-party control. Extron’s Simple Instruction Set™ is available and genlock; all other functions remain active through for calling up presets as well as all other functions of the SVS 100. RS-232/422. RS-422 control is also available.
- Page 3 This application diagram depicts the same application as above using the SVS 100, eliminating the switcher and expensive genlocking equipment, including the TBCs and black burst generator. The SVS 100 genlocks all source signals and then routes the selected signal to the output, providing a seamless cut or one of 24 digital switching effects.
- Page 4 For videoconferencing applications using multiple sources via a matrix switcher, the SVS 100 may be used to save color correction presets for up to 128 matrix switcher inputs. When each matrix switcher input is switched to the SVS 100, its preset may be recalled via RS-232 control prior to the SVS 100’s switch, ensuring consistent color, tint, brightness, and contrast levels across...
- Page 5 Extron’s Matrix 50 matrix switcher routes multiple DVD players and Betacam cameras to two S-video video inputs on the SVS 100. The SVS 100 switches its inputs to the S-video output for the DVS 150 scaler. The DVS 150 scales its input up to 1024 x 768 and sends the RGBHV signal to the large-venue projector for display.
-
Page 6: Specifications
MTBF ........30,000 hours output, balanced/unbalanced) Warranty ......2 years parts and labor S/N ........>90dB, output +21dBu, balanced Part number ......60-322-01 EXTRON ELECTRONICS/RGB SYSTEMS, INC. EXTRON ELECTRONICS, EUROPE EXTRON ELECTRONICS, ASIA EXTRON ELECTRONICS INFORMATION Beeldschermweg 6C, 3821 AH Amersfoort 41B Kreta Ayer Road, Singapore 089003 WEB™: www.extron.com...
