C O N N E C T I O N S - D U A L M U L T I C H A N N E L
Stereo output with
parallel left & right
main channels when
stereo inputs are se-
6 5 4 3
Multichannel output with parallel main
channel 1 & 2 when multichannel in-
puts are selected
1 : main left channel
R : right channel 2 : main right channel
L : left channel 3 : left surround channel
ORPHEUS TWO
output
R L R L R L
Input and output for
monitoring or recor-
ding equipment, e.g.
tape deck
2 1
4 : right surround channel
5 : center channel
6 : subwoofer channel
input
6 5
Input for second 6-
channel audio source,
e.g. SACD, DVD-A or
DVD-V players
R L
Input for one stereo
source, e.g. CD player
or DA converter
4 3 2 1
6 5 4 3
Input for first 6-
channel audio source,
e.g. SACD, DVD-A or
DVD-V players
2 1
