F R O N T P A N E L
1
1. MAIN POWER INDICATOR
Lights red when the unit is operating and
when it is in standby mode. Indicator light is off
when the unit is switched off.
2. DISPLAY
Displays the input selection and the main vo-
lume level, as well as the setup menus.
3. INFRARED REMOTE CONTROL SENSOR
Receives signals from the remote control
transmitter.
ORPHEUS TWO
4. CONTROL BUTTONS
Drive the main volume level control and the
input selection. Also used for menu navigation
and unit setup.
LEFT
DOWN
2 3
UP & DOWN
Used for increasing, decreasing or choosing va-
lues, for instance, while adjusting volume levels,
dimming the display or renaming inputs.
LEFT & RIGHT
UP
Used for selecting options, menus and inputs.
SELECT
RIGHT
Used for entering menu structure and accessing
menu options as well as confirming choices and
settings.
SELECT
4
3
