PRIVILEGE SERIES
PREAMPLIFIER
User manual
1/19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRIVILEGE SERIES and is the answer not in the manual?

Questions and answers

Related Manuals for ORPHEUS PRIVILEGE SERIES

Summary of Contents for ORPHEUS PRIVILEGE SERIES

  • Page 1 PRIVILEGE SERIES PREAMPLIFIER User manual 1/19...

  • Page 2: Table Of Contents

    Table of Contents Introduction............................2 Contact.............................3 Document overview.........................3 FRONT PANEL...........................5 REAR PANEL............................6 CONNECTIONS..........................7 DISPLAY AND MENU STRUCTURE....................8 QUICK GUIDE..........................8 1. START UP DISPLAY.........................9 3. STANDBY MODE........................10 4. INPUT SELECTION.........................10 5. INPUT NAME SETTING......................11 6. RECORD SELECTION......................12 7. INPUT LEVEL..........................12 8. BALANCE SETTING.......................13 9.

  • Page 3: Introduction

    ORPHEUS MEDIA SARL Avenue des Sciences 3 1400 Yverdon-les-Bains Phone : +41 24 423 9088 Fax : +41 24 424 9089 E-mail: info@orpheuslab.com Web: www.orpheuslab.com Document overview This document is the user manual for the Orpheus Media Privilege series Preamplifier. 3/19...

  • Page 4: Read This Before Operating Your Unit

    Unpacking First check and identify the contents of your preamplifier package, as listed below: ● Preamplifier ● CD User manual Read this before operating your unit ● Please read this manual carefully, to assure proper operation and the possible performance. ●...

  • Page 5: Front Panel

       INFRARED REMOTE CONTROL SENSOR Receives signals from the remote control transmitter. Compatible with all Orpheus remontes controls transmitter.  DISPLAY Displays the input selection and the main volume level, as well as the setup menus.  POWER Lights red when the unit is in standby mode.

  • Page 6: Rear Panel

    REAR PANEL         UNBALANCED INPUT 1 TO 4 4 stereo inputs ➁ TRIGGER OUTPUT 1 TO 4 4 Trigger output ➂ BALANCED INPUT 1 & 2 2 stereo inputs ➃ MONITORING Monitoring section with stereo input and output ➄...

  • Page 7: Connections

    CONNECTIONS input output Input for 2 Input and output Input for 4 sources, Parallel main stereo balanced sources, for monitoring or e.g. CD player, outputs e.g. CD player or recording tuner or DA DA converter equipment, e.g. converter Tape deck 7/19...

  • Page 8: Display And Menu Structure

    DISPLAY AND MENU STRUCTURE SETUP AND OPERATIONS QUICK GUIDE POWER ON Flip the main power switch on the lefthand side of the rear panel from 0 to 1. MAIN SCREEN After switching on the unit, the display windows shows the start up screen shortly. It then switches to the default screen which shows input selection for listening.

  • Page 9: Start Up Display

    1. START UP DISPLAY REFERENCE SERIES Preamplifier The start up display is shown approximatively 5 seconds when main power is switched on. It is then replaced by the main screen. 2. MAIN SCREEN and MAIN VOLUME SCREEN Main volume Level INPUT 1 Input selected Main screen shows the name of the selected input format.

  • Page 10: Standby Mode

    From main screen press on the button to enter setup menu. To choose between the setup menu options turn to right or left with the button until the desired option is displayed. 3. STANDBY MODE SETUP> STANDBY Pressing on the button the unit in to standby mode. Pressing any navigation button resumes normal operations.

  • Page 11: Input Name Setting

    5. INPUT NAME SETTING SETUP> NAME To enter name setting press on the button. SETUP>NAME> INPUT 1 INPUT SELECTION Select the input that should be renamed by turning to right or left until the chosen input is displayed. Press on the button to confirm. RENAMING Each input can have any individually defined name.

  • Page 12: Record Selection

    6. RECORD SELECTION SETUP> RECORD To enter record selection mode press the button. A source can be recorded while another one is listened to. The input to be recorded is selected in this menu and is driven into the MONITOR OUT output. The recording device should thereforce be connected to this output.

  • Page 13: Balance Setting

    SETUP>INPUT LEVEL> INPUT 1 : +1.0dB To increase or decrease the volume level value turn to right or left. Press on the button to confirm. 8. BALANCE SETTING SETUP> BALANCE To enter balance setting mode press on the button. The speakers can be balanced. Each step is 0.5dB per channel, which balances 1dB betwen the two speakers.

  • Page 14: Bypass

    9.1 BYPASS Selecting ON, the main volume will then be controlled by another unit. You can't increase or decreased the volume level from main screen. 9.2 AUTOVOL Selecting ON, the main volume will be automatically decrease when you enter in the INPUT setting.

  • Page 15: Ring Leds

    11. RING LEDS SETUP> RING LEDS To enter RING LEDS mode press the button. The leds brightness can be adjusted from 100% to 12.5% in 12.5% steps. To increase or decrease the value turn to right or left. Press on the button to select. 12.

  • Page 16: Preferences

    14. PREFERENCES SETUP> PREFERENCES The various parameter setings allow personalized unit configuration. It is possible to restore previously stored settings as well as to call back the initial factory settings. Menu SAVE saves the current setup, it is advisable to save any configuration through menu SAVE prior to switching off the unit.

  • Page 17: Specifications

    SPECIFICATIONS Technical data Dynamic (Vref. 7.05Vrms) : -126dB Signal to noise ratio : - -126dB Residual noise 20 Hz to 22 kHz: Unbalanced : 3.6uVrms Balanced : 3.2uVrms 17/19...
  • Page 18 Media sàrl. IMPORTANT NOTICE ORPHEUS Media Sàrl reserve the right to make changes to their products or discontinue any product or service without notice. Adequate operating safeguards must be used to minimize hazards. Reproduction of user manual information is permissible only if it is without alteration and is accompanied by all relevant conditions, limitations and notices.
  • Page 19 LIMITED WARRANTY CERTIFICATE ORPHEUS Media guarantees that the product described below is free of defective material and workmanship. The warranty extends for a period of one year form original purchase date, but at maximum two years form manufacturing date. ORPHEUS Media agrees to repair or replace defective parts or the complete unit at its option, provided that the equipment is returned exclusively to the original dealer.
