LAN RJ45 Connector (CN10)

The SBC-370 is equipped with a built-in 10/100Mbps Ethernet Controller. You can con-
nect it to your LAN through the RJ45 LAN connector. For the location of this connec-
tor, refer to figure 2.
Pin Number
1
2
3.
4.
5.
6.
7.
8.

LED Connector for LAN (CN5)

For the location of this connector, refer to figure 2.
Pin Number
1
2

Fan Connector (CN13/CN14/CN15)

The SBC-370 provides one CPU cooling fan connector and two system fan connectors.
These connectors can supply 12V/500A (maximum) to the cooling fan. The connector
has a rotation pin that supplies the fan's rotation signal to the system so that the sys-
tem BIOS can read the fan speed. For the location of each connector, refer to figure 2.
CN13: CPU Fan Connector
•
CN14: System1 Fan Connector
•
CN15: System2 Fan Connector
•
Pin Number
1
2
3
23
Description
TX+
TX-
RX+
75 W termination
75 W termination
RX-
75 W termination
75 W termination
Description
VCC
LAN ACT.
Description
Fan Sensor
+12V
GND
