Keyboard/Mouse Connector (CN8/CN17/CN18)

The SBC-370 provides one external keyboard, one external mouse, and one PS/2 key-
board and mouse connector.
CN8: 5-pin Header External Keyboard Connector
•
Pin Number
1
2
3
4
5
CN17: PS/2 Mouse 5-pin Header Connector
•
Pin Number
1
2
3
4
5
CN18: 6-pin Mini-DIN PS/2 Keyboard and Mouse Connector
•
Pin Number
1
2
3
4
5
6
For the location of these connectors, refer to figure 2.
Description
KB CLK
KB DATA
NC
GND
+5V
Description
MS DATA
NC
GND
+5V
MS CLK
Description
KB DATA
NC
GND
+5V
KB CLK
NC
Board Configuration 20
