Caraudio-Systems c.LOGiC C2-MFD2 Manual page 13

Button assignment table c.LOGiC MFD2/RNS2/Nexus
Head- DVB-T Interner USB
unit Tuner
button
1
OK
2 AV
3 EPG
4 INFO
5
SCAN
6
MENU
7
DISPLAY
8
AUDIO
→
9
←
10
↓
12
↑
13
14
OK OK / PLAY
11
EXIT
15
CH -
16 CH + TRACK +
Additionally to the head-unit buttons, the steering-wheel buttons UP and DOWN can be
used for remote functions. DOWN-button has the same function as 15 on the head-unit and
UP-button has the same function as 16 on the head-unit.
Version 01.09.2011
DVD-player
POWER PLAY
MEDIA AV
VOL+ PBC
VOL- TITLE
ZOOM ZOOM
SETUP SETUP
MEDIA DISPLAY
AUDIO AUDIO
→ →
← ←
↓ ↓
↑ ↑
OK
EXIT STOP
TRACK - TRACK -
TRACK +
DVD- iPod®-control
changer
PLAY PLAY/PAUSE
AV EJECT
PBC SHUFFLE
TITLE REPEAT
DISC
SETUP LIGHT
DISPLAY
AUDIO
→ →
← ←
↓ ↓
↑ ↑
OK ENTER
STOP PLAY
TRACK - TRACK -
TRACK + TRACK +
Analog-tuner
SCAN
MODE
FM
DISPLAY
SCAN
ADJUST
DISPLAY
AUDIO
CH +
CH -
VOL -
VOL +
MODE
MUTE
CH -
CH +
C2-MFD2
