3.3.4. After-market rear-seat-entertainment

Using RCA-cables, connect the rear-seat-entertainment to the female RCA-connector
VIDEO OUT of Interface-box C2C-M200.
Note: As the output is a full output, not shared with the video signal for the
navigation system, splitting the video with an RCA Y-cable might give a good enough
picture for two rear-seat-entertainment monitors. If not, or if connecting more than
two monitors, use a video splitter.

4. Operation

4.1.

Activation of the video-in-motion function

The video-in-motion function is activated permanently without disturbing the navigation
performance.
4.2.

Selecting the c.LOGiC as current AV-source

CD-Version - Push AUX button of head-unit , then select
TV to choose the c.LOGiC as current AV-source.
DVD-Version - Push CD button of head-unit, then select
AUX to choose the c.LOGiC as current AV-source.
Version 01.09.2011 C2-MFD2
