Connection to PC

Adjustment of Display

Key Definition
1
2
3
4
5
6
Make sure that the power supply of your PC is turned off
and the power plug is removed.
Connect and fasten both ends of the signal cable to your
PC host and LCD display respectively.
If your LCD display has built-in speakers, connect the
audio cable attached to the display from the sound card
output of your PC to the audio input on the back of your
LCD display.
Connect the attached power cable to your LCD display.
Plug the power cable to the receptacle.
Turn on the power supplies of your PC and LCD display.
Power Source
Menu
OSD Menu
>
Plus
<
Minus
Auto
Automatic
Adjustment
Speaker
(For the model
with speakers)
Power On/Off
Green indication: Power is on and normal
Orange indication: Sleep status in the energy-saving mode
Colorless indication: Power off
Press this button to enter OSD. Press it again to exit OSD.
Press this button for selection or adjustment when OSD is
shown.
Press this button and click < and > to adjust volume
when OSD is not shown (for the model with speakers only)
Press this button to exit the manual when OSD is shown.
Press this button for the display to optimize the position,
phase and clock pulse automatically when OSD is not shown.
3
Power Cable
Audio Cable (Optional)
DVI Signal Cable (Optional)
D-Sub Signal Cable
