Sirius XM RAdio TTR1 Quick Start Manual

STEP 1: Connect to a Network
This Quick Start Guide covers the two most common types of network connections. If your network
requires manual configuration, refer to the User Guide page 66 and page 71 for instructions. Also refer to the
"Troubleshooting" section on page 76 of the User Guide if you encounter any problems.
Turning the TUNE knob scrolls through menus and highlights menu items, and pressing the TUNE knob
selects a highlighted item.
To Connect to a Wireless Network
a.
Plug the Radio into an AC outlet and press the Power button.
b.
Wait while the Radio searches for wireless networks. Then select
your wireless network from the list.
c.
The Radio will attempt to connect to the wireless network. If you
chose a network that is secured, you will be prompted to enter the
key (password).
d.
When the Radio has successfully connected to the wireless network,
the Connected screen will be displayed. Continue with step 2.
To Connect to a Wired Network
a.
Remove the compartment cover at the rear of the Radio and
connect an Ethernet cable. Replace the compartment cover.
Connect the other end of the Ethernet cable to your wired
network.
b.
Plug the Radio into an AC outlet and press the Power button.
c.
Wait while the Radio searches for wireless networks. Then
select [Wired] from the list.
d.
When the Radio has successfully connected to the network,
the Connected screen will be displayed. Continue with step 2.
STEP 2: Enter Your SiriusXM Account Information
Enter Your SIRIUS or XM Internet Radio Account User Name and Password
a.
Select SiriusXM Setup.
b.
Select User name. Enter your SIRIUS or XM Internet Radio user name
and select OK. Your user name is case sensitive.
c.
Enter your password and select OK. Your password is case sensitive.
d.
Network settings When the Radio connects to the SiriusXM Internet Radio service,
select All channels. Turn the TUNE knob to scroll through the channel
choices and highlight the channel to which you want to listen. Press
Network wizard
the TUNE knob to select the channel.
Scanning.../
The installation is complete.
Connected
Connected
IMPORTANT! You must be subscribed to the Premium SiriusXM Internet Radio service to use the SiriusXM TTR1 Radio. You can add
this service to your existing SIRIUS or XM subscription, or subscribe only to the Premium SiriusXM Internet Radio service.
For SIRIUS service go to sirius.com/siriusinternetradio or call 888-539-7474 to subscribe. For XM service go to
xmradio.com/getxmro or call 800-967-2346 to subscribe. When subscribed, you will be provided with your account user name and
password.
IMPORTANT! If you had previously subscribed to Premium XM Radio Online, you will need to change your password before using
the SiriusXM TTR1 Radio. To change your password, go to https://home.xmradio.com and login. Then click on the EDIT button to
change your password. Also, if your user name is less than 6 or greater than 20 characters, you will need to change it to be between
6 and 20 characters.
TIP! To verify that you are subscribed to the service, listen online:
Wired Ethernet
• For SIRIUS service go to sirius.com. Click on the LISTEN ONLINE link, and then click the LAUNCH ONLINE PLAYER link.
Connector
Enter your username and password. Select a channel to listen to and then click on the PREMIUM link. If you can listen in the
Premium mode, then you are subscribed to the Premium SiriusXM Internet Radio service.
• For XM service go to xmradio.com. Click on the LISTEN ONLINE NOW link and then enter your user name and password. If
you can listen, then you are subscribed to the Premium SiriusXM Internet Radio service.
SSID
[Wired]
Some Network Name
Other Network Name
[Rescan]
[Manual config]
TTR1 Radio Functions & Main Display Screen
Power Button TUNE Knob (Multifunction)
Turns Radio On and Off. Turning the knob at the default display screen displays the
SiriusXM category tune screen; pressing the knob at the default display
screen displays the direct tune screen; turning the knob in a menu
Category Tune >
or user input screen scrolls through menus and choices; pressing
SiriusXM Setup >
the knob in a menu or user input screen selects a highlighted item;
EQ pressing and holding displays the Parental control menu.
Parental control
System Setup >
All Channels
001-SIRIUS XM Hits 1
002-The Blend
003-SIRIUS XM Love
004-40s on 4
005-50s on 5
1 2 3 4 5 6 7 8 9
0-9 Number Buttons
Set and select channel
presets or directly enter
channel numbers.
Wired Ethernet Connector
Line Out Connector
Category or Channel
List Screen
Menu Options Screen
Main Display Screen
Channel Name
Song Title or
Talk Show Schedule
Alarm 1/2 On Indicator
VOL (Volume) Knob
Increases or decreases volume;
also mutes the audio.
MENU Button
Press to access or exit category
Headphone
and channel tuning, advanced
Connector Connector
features, and configuration
options.
TUNE VOL
ALARM 1 / ALARM 2 Buttons
Turns the alarm clocks On or Off;
0 BACK MENU ALARM 1 ALARM 2
pressing and holding displays the
Wireless
alarm settings.
Antenna
Snooze/Sleep Timer Button
Mutes the alarm, or sets the sleep timer,
BACK Button
for 5, 10, 15, 30, 45, or 60 minutes.
Press to return to the
previous display
screen.
Rear
Compartment
The Main Display Screen
SiriusXM 017 5:23PM
Current Time
Jam_ON
Channel Number
Artist Name or
Phish
Talk Show Host
First Tube
Network Connection
Type (wireless)
P 1
1 2 Signal Strength
(wireless)
Sleep Audio is Preset Network Connection
Timer Muted Number Type (wired)
Countdown (Favorites)
Aux In
