- Page 1 V2.0...
- Page 2 This Manual will help you to get started with setting up your notebook. For more detailed information, please visit our website at http://www.aorus.com. All specifications are subject to the manufacturer's configuration at the time of shipping and may change without prior notice,written or otherwise.
-
Page 3: Switching On The Power
Switching on the Power After you turn on the notebook for the very first time, do not turn it off until the operating system has been ® configured. Please note that the volume for the audio will not function until Windows Setup has completed. - Page 4 Your AORUS Notebook Tour Webcam Status LED Indicator Webcam Light sensor Microphone TouchPad Battery Indicator Button LED Indicators Bluetooth Status LED Press the right button of touchpad to check the remaining battery power. Right click to show the remaining power percentage. As shown below, the...
- Page 5 HDMI Port USB Port Microphone Jack Headphone Jack Speaker Speaker SD Card Reader USB Port Power Button DC-in Jack Ethernet Port Warning: DO NOT remove the built-in lithium battery. For any service needs, please contact your local Aorus Authorized Service Center.
- Page 6 Hotkeys The computer employs hotkeys or key combinations to access most of the computer’s controls like screen brightness and volume output. To activate hotkeys, press and hold the <Fn> key before pressing the other key in the hotkey combination. Hotkey Function Description Fn + F1...
- Page 7 X3 Operation manual X3 equipped with many unique features, providing user an exceptional gaming experiences. Macro key X3 features five macro keys and macro group switch, providing users to set their own preference of combinations, capable for switching in between maximum up to 25 sets of macros simultaneously. By using Marco Engine, users can easily access to their own defined recorded macro, and also adjust the macro sets, so the players are always steps ahead in games.
-
Page 8: Hardware Upgrade
Moreover, user may also configure the network for the download priority for online videos and games packets to achieve the best network optimization. Hardware Upgrade User may upgrade memory or carry X3 to nearest repair center to upgrade; Please visit AORUS official website for compatible memory brands. Caution Please ensure X3 is not powered on and unplugged to power source before the upgrade. - Page 9 X3 Command & Control Command & Control is a software that integrates a list of basic settings to a single interface, providing user a faster and better experience when customization is needed. Hotkey Function Description Backlit Keyboard Switch Turn On or Off keyboard backlit. System will try to lower the fan speed to increase the battery Quiet Mode life and reduce the noise without affecting light-weight tasks...
- Page 10 Brightness Setting Adjust Screen brightness. Wi-Fi Switch Turn ON or OFF Wi-Fi connection. Bluetooth Switch Turn On or Off Bluetooth connection. Adjust the power plan by user usage in order to obtain maximum Power Mode battery life or performance. Switch between the computer screen and the external display External Monitor Setting video output, or simultaneous display.
- Page 11 Macro Engine Instruction Welcome to use Macro Engine ! Macro Engine makes it much easier for you to control your Macro Key on X3. You can deal with complex key stroke combination by just one press on macro key, which brings you benefits both in work and game.
- Page 12 Using Macro Engine Set Macro Key to basic function a. Click the G button on the left-top of the keyboard b. Click the Macro Key function brick to switch to the Macro Key group you would like to use c. Double-click the function you would like to use(ex. Media Player) in the Basic or Macros function area.
- Page 13 d. Complete the setting Edit macro command funtions anf settings. a. Click "Macros" (you can set up to 100 sets of macro)
- Page 14 b. Overview of macro record panel (you can record your own macro here) 1. Start recording: Click when you’re about to record the macro 2. Pause key Switch: Enable/Disable Pause key to stop recording. 3. Macro Name: Set the name of this macro 4.
- Page 15 c. Start to record macro: When you click start button, the macro engine will start to record macro. All movement you made(mouse/keyboard) will be shown in the movement list. You can decide to use “pause” key or mouse click on stop button to stop recording based on your record range. Finishing recording: When you have done all movement, click exit button.
- Page 16 Edit "Settings" of Macro Engine 1. Software update: Update latest version of Macro Engine 2. Clean memory: Erase current Macro Engine settings...
- Page 17 Setup Your System for RAID 0/1 WARNING ● Please backup your data before you build and run RAID 0/1 on your system. ● RAID 1 needs two storage drives of the same specification and capacity in your laptop. ● RAID 0 needs two storage drives of the same specification in your laptop. Different capacity is acceptable. •...
- Page 18 • Inser t the dr iver disk to your optic al dr ive and r un the install of “System Backup” (for none-ODD model, please use USB ODD device or download from http:// www.AORUS.com • Run the “System Backup” after finishing the install. • Select your USB disk from the drop-down list and start to create the recovery USB disk.
- Page 19 Recovery Guide System Recovery (Restore your laptop operating system) When something is going wrong with the laptop operating system, the storage of the laptop has a hidden partition containing a full back up image of the operating system that can be used to restore the system to factory default settings.
- Page 20 A progress indicator bar will show on the window when the recovery process is running. Please make sure the AC- adapter is plugged in and do not turn off the laptop. Reboot the laptop after the system recovery is complete. Windows 8.1 Recovery Guide Turn off and restart the laptop.
-
Page 21: Advanced Options
Choose “Troubleshoot” to enter the recovery settings. (Also you can choose “Continue” to exit recovery system and continue to Windows 8.1 for files or data backup.) There are two options for system recovery ˙ Refresh your PC You can refresh your laptop to improve the system stability without losing your files. ˙... -
Page 22: Startup Settings
Change Windows Startup behavior. Appendix Warranty & Service: „ Warranty and service and related information please refer to the warranty card or service website as the below link: http://www.aorus.com/ FAQ: „ FAQ (Frequent Asked Questions) please refer to the below link: http://www.aorus.com/...
