- Page 1 ORIGINAL USER’S MANUAL User’s Manual DEVICE (PRODUCT) NAME: 3D PRINTER TYPE: DWARF SUPPLIER NAME: FUTUR3D s.r.o. ADDRESS: 14800 Praha 4 - Kunratice, Golcova 486, 14800 Praha 4 - Kunratice BUSINESS ID NO.: 28952383 TAX ID NO.: 28952383...
- Page 2 SELLING – CONTACT INFORMATION Complete following information about your device. This information is necessary for spare parts order or in case of loss or theft. Type number: Production number: Delivery (purchase) date: Supplier (dealer): Address: Phone/mobile/fax number: Email: Stránka 2 z 39...
-
Page 3: Table Of Contents
Table of Contents 1 Introduction ......................5 2 Intended device usage description ................5 3 General device description ..................6 3.1 Technical specification: ..................6 4 Device control ......................7 5 ... - Page 4 27 Instructions for safe transportation, manipulation and storing ......... 36 28 Obligatory accident and damage procedure ............36 29 Specification of spare parts, which must be used ........... 36 30 Adjustment and maintenance operations description ..........36 31 ...
-
Page 5: Introduction
1 Introduction Submitted manual contains technical data of device, instructions for location and transportation, information regarding operation and device start-up. The Manual does not serve its purpose, though, if it is not introduced to department leaders and especially those, who will operate and maintain the device. Proper knowledge of this manual prior usage is obligatory for user and operator. -
Page 6: General Device Description
3 General device description (basic device description) DLP 3D DWARF printer uses Stereolithography printing technology, thus gradual hardening of photo-reactive resin, so called photopolymer. As a light source serves UV lamp with DLP chip. In this case a DLP projector manufactured by ACER, this device has enclosed Confirmation of Conformity in writing. -
Page 7: Device Control
4 Device control (Device control possibilities) • Device is controlled via PC 5 Description of posts, which has to be attended by operators (Defined posts for device operators) • Device works in automatic mode, operators carry out only regular monitoring of device. -
Page 8: Personal Protection Measures
• It is prohibited to perform constructional alterations and interventions, which were not recommended or approved by manufacturer of device, same applies for replacement of spare parts for other kind • It is prohibited to remove residue from dangerous places while device is operational •... - Page 9 ELECTRIC PART OF DEVICE MUST OT BE CLEANED BY SPRAYING WATER! • Protection measures must be kept flawless • Keep safety marking on the device clean • Unconditionally follow safety instructions mentioned in this manual • Before you start any usage of the device read this manual carefully as well as any other manuals from partial devices •...
-
Page 10: Risk Locations
• Install the printer in location which is: o Dry and dust-free o stabile (temperature, humidity) o well-ventilated o in vicinity of easily accessible electric outlet o sufficiently distant from objects, which may cover vents of printer o in sufficient distance from flammable objects (e.g. curtains and drapery) o in sufficient distance from spraying liquids, in sufficient distance from organic gasses (e.g. -
Page 11: Device Tests
14 Device tests (necessary test of device) • Electric device must be, after full connection, a subject of tests according to valid standards of country where operated • A written proof of revision has to be issued 15 Safety of work on electric device (safety requirements) Electric device requires scheduled and regular maintenance, which is a presumption of safe, reliable work and major lifetime extension of electric device... -
Page 12: Operation Of Electric Device
17 Operation of electric device (device operation staff requirements from the point of view of qualification for electric devices ) • Electric device operation is allowed only to persons with qualification required for given device • Persons without professional electrotechnical qualification (ordinary persons) can operate unsupervised devices of extra low and low voltage, constructed in a fashion that they cannot, while operating, be exposed to uncovered parts of electric device, which are under voltage... -
Page 13: Electric Devices
• Replace and extend movable inputs with connecting cables equipped with appropriate connecting parts, when the device is turned off • Turn on and off simple electric devices In case of observance of device defect e.g.: • Damage on isolation •... -
Page 14: Assembly, Installation And Connection Instructions
22 Assembly, installation and connection instructions (manufacturer’s requirements for safe assembly, installation and connection) • Device is to be connected via electric plug into a socket with 230 V 23 Instruction starting and operating the device (in case of need the instructions for professional operator training) •... -
Page 15: Lan And Wifi Printer Connection And Control
23.1 LAN AND WIFI PRINTER CONNECTION AND CONTROL 23.1.1 Connection via LAN cable – intranet Connect RS–45 cable (network LAN cable) on one side to socket on the back side of the printer and the other side to the router. ... - Page 16 Start t he p rinter a nd w hen t he b oot i s c ompleted, t he I P a ddress a ssigned b y t he r outer appears. ...
- Page 17 Enter t his I P a ddress i n t he w eb b rowser a nd p ush E nter. The i ntranet c ontrol s ystem o f t he p rinter w ill o pen. The ...
- Page 18 Home-‐command In t his p art o f m enu, y ou c an c hange t he e xposition t imes o f i ndividual l ayers d uring t he print.
- Page 19 Printer r eport You c an c heck t he p rint p rogress h ere. What l ayer i s b eing p rinted a nd w hether t he c ommand, y ou s ent t o t he p rinter, w as executed. ...
- Page 20 System r eport Informationabout c urrent s ystem o f t he p rinter, S oftware, F irmware Information a bout u pdates Information a bout t he c ommands s ent d uring t he p rint. ...
-
Page 21: Setting Up The Wifi Via Remote Access
23.1.2 Setting up the WIFI via remote access Install t he r emote a ccess p rogram i n y ou c omputer – e .g. V NC v iewer – f ree t o d ownload here ... - Page 22 Click o n C ontinue... The s creen w ith S DWARF l ogo a ppears o n y our m onitor. I n l eft h and u pper c orner, t here i s a WIFI ...
- Page 23 Input S SID – t he n ame o f t he n etwork a nd P SK – t he p asword o f t he n etwork a nd c lick o n Add. ...
-
Page 24: Print Preparation
USB. • The keystone is model in STL format. Follow basic modelling rules for 3D printing. (http://www.futur3d.net/pravidla-3d-modelovani-a-tvorba-stl-souboru) 1. Model design preparation in Creation Workshop program. Program is open source and is downloadable at here. Stránka 24 z 39... -
Page 25: Model Loading And Insertion
23.3 MODEL LOADING AND INSERTION Basic control elements in Creation Workshop software environment: PRINT AREA Insert model via icon ‰ in left upper corner. When dialogue opens, find desired STL file for printing and open it. 1 Scene This window contains list of inserted files. It is possible to further duplicate or remove the models or clear entire area in this window. - Page 26 Holding the shift key allows moving the model freely. 4 Mirror Allows to inverse a model thru selected plane of mirroring. 5 Scale Tool for dimensions size change. 6 Rotate Allows model rotation around selected axis. 7 Support generation Serves as a support for surfaces, which forms an acute angle (smaller than 30°) with the platform.
- Page 27 8 Configure Configure Machine Preset correct printing device in the section , and if necessary check whether the set parameters are consistent with device parameters. Set „1280“ for usage of printer with standard definition • Set „HD“ for usage of printer with HD resolution •...
- Page 28 Section C onfigure Slicing Profile allows conditions setting for individual layers creation. Check whether the setting contains desired parameter (especially layer thickness). Complete „Export Options“ and check the fields as in the picture. Do not forget to confirm „Apply Changes“ after every change of setting 11 Slice When the models are in desired position, it is necessary to save the Š...
- Page 29 Number of layers and individual slices can be reviewed in Slice View section. Stránka 29 z 39...
- Page 30 Slices are exported into the folder called NAME.slice in the form of PGN files. It is necessary to compress the files into single .zip file. Create a folder with the name of printed object in the USB flash drive directory. Insert the created .zip file into this folder.
- Page 31 Fill-in the folder name with content for printing and layer height consistent with preset slicer in the text file „config“ at USB. Set required exposition times according to the chart. This setting does not have to be consistent with slicing profile. PRINTING // FOLDER NAME / EXPOSITION TIME / EXPOSITION TIME OF THE FIRST LAYERS / LAYER...
- Page 32 3. Insert USB flash drive into printer. 4. Turn on the device. (do not forget the main switch on the back side). 5. When the printer starts (ca. 1min depending on the size of model) information and blue button PRESS (START) appears- Button turns red, wait for command execution.
-
Page 33: Printing Finalization
PRINTING FINALIZATION 1. Wipe off liquid material from the top of platform. 2. Extract the platform from the device and wipe off remaining material from the platform. 3. Carefully cut off printed models. Stránka 33 z 39... - Page 34 4. Pour unused material back to bottle thru a sieve. 5. Clean everything thoroughly for next printing. If the model parameters are set correctly, printing difficulties do not occur. Not always is exact data matrix for printing of desired model available, though. The tank has limited durability, which is significantly influenced by cleaning and manipulation method.
-
Page 35: Important Warnings
23.4 IMPORTANT WARNINGS 1. Printer must be placed on flat surface 2. Back side of the printer with vents has to be in the distance of at least of 30cm (for proper cooling function) from the wall or other obstacle 3. -
Page 36: Instructions For Safe Transportation, Manipulation And Storing
27 Instructions for safe transportation, manipulation and storing (with specified weight of device ant its various parts, if these are regularly transported separately) • Transportation must comply with carrier’s rules • All internal movable parts must be securely fixed during transport •... -
Page 37: Maintenance Warning
31 Maintenance warning (Maintenance and adjustment safety) Regular and proper maintenance as well as rigorous tidiness of workplace is due to safety reasons unavoidable! SAFETY • Always turn off control switch prior any maintenance, you will prevent accidental device start or turning on by someone else; if maintenance or measurement requires to turn on the control switch, only with utmost diligence •... -
Page 38: Adjustment And Maintenance Safety Instructions
33 Adjustment and maintenance safety instructions (including protection measures necessary to undergo during this operations) BEFORE INTERVENTION INTO DEVICE: • Make sure that the device is not connected to the grid • Make sure that device or its parts are not hot SECURE THE WORKPLACE TO AVOID RECONNECTION OF DEVICE TO: •... -
Page 39: Disposal Of Device And Its Parts
35 Disposal of device and its parts (ecological disposal of device) FOLLOW VALID ECOLOGICAL REGULATIONS ! After final shutdown of the device (when its lifetime ends), please mind environmental protection and recycling possibilities (generally): • Drain contained liquids into dedicated containers – such liquids like motor oil , transmission oil, cooling and cleaning liquids, and send them to specialized facilities •...
