VBG30
Read
Do not store or use
Retain this manual for future reference.
VERTICAL
BROILER
ELECTRIC: VBE30
Installation and
Instructions
2M-Z13927 Rev. B 2/27/14
WARNING:
This appliance shall be installed
in accordance with current regulations and
used only in well-ventilated space. Refer to
instructions before installing and using this
appliance.
In addition, there should be posted, in a
prominent location, detailed instructions to
be followed in the event the operator smells
gas. Obtain the instructions from the local
gas supplier.
GAS: VBG30
Operation
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Star VBE30
Summary of Contents for Star VBE30
- Page 1 VERTICAL BROILER ELECTRIC: VBE30 GAS: VBG30 Installation and Operation Instructions 2M-Z13927 Rev. B 2/27/14 VBG30 WARNING: WARNING: Improper installation, adjustment, This appliance shall be installed alteration, service or maintenance can cause in accordance with current regulations and property damage, injury or death.
-
Page 2: Safety Symbol
RETAIN THIS MANUAL FOR FUTURE REFERENCE NOTICE Using any part other than genuine Star factory supplied parts relieves the manufacturer of all liability. Star reserves the right to change specifications and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment. -
Page 3: Specifications
Aproximate Weight Model Width Depth Height Voltage Input Amps Plug Type (cm) (cm) (cm) Type Total Shipping Installed BTU’s 208V 21.6 NEMA 6-30P VBE30 16.08” 24.97” 32” 230V 18.2 240V 18.8 NEMA 6-30P VBG30 (40.79) (63.42) (81.28) 120V 30,000 NEMA 5-15P... -
Page 4: General Installation Data
CAUTION The Star series gas vertical broiler is equipped for the type of gas indicated on the nameplate mounted on the unit. All gas units are shipped from the factory for use with natural gas. -
Page 5: Assembly And Installation
INSTALLATION INSTRUCTIONS UNCRATING AND INSPECTING Unpack the unit and components from the shipping container. Remove all visible packing material and those from inside the cooking chamber. If damage is discovered, file a claim immediately with the carrier that handled the shipment. Do not operate the unit if it was damaged during shipping. -
Page 6: Gas Model
INSTALLATION INSTRUCTIONS continued GAS MODEL Check unit nameplate for correct gas supply to the appliance. Be sure to remove all paper protection and packing material from the unit prior to lighting. Provide adequate air supply and ventilation to the appliance. A manual shut-off valve (not supplied) should be installed upstream from the unit &... -
Page 7: Burner Operation
INSTALLATION INSTRUCTIONS continued BURNER OPERATION Each burner is controlled by an individual high-low, on-off valve. A variety of broiling temperatures may be obtained by turning the burner valve knob to any position between ON and LO. It is possible through this arrangement to have a high heat or searing section, while having a low heat finishing or holding section. -
Page 8: Limited Equipment Warranty
LIMITED EQUIPMENT WARRANTY All workmanship and material in Star products have a one (1) year limited warranty on parts & labor in the United States and Canada. Such warranty is limited to the original purchaser only and shall be effective from the date the equipment is placed in service. Star's obligation under this warranty is limited to the repair of defects without charge, by the factory authorized service agency or one of its sub-agencies. - Page 9 ELEMENT ELECTRIC BROILER WIRING DIAGRAM FOR SUPPLY USE COPPER CONDUCTORS SWITCH RATED FOR 75°C. MINIMUM. TERMINAL SEE NAMEPLATE FOR VOLTAGE BLOCK SUPPLY WIRES SWITCH SWITCH FUSE- 3A. FUSE- 3A. ELEMENT PILOT LAMP MOTOR Z13920 TERMINAL BLOCK SWITCH POWER CORD 120V. PILOT LAMP VERTICAL BROILER-GAS...
- Page 10 Nameplate SOME ITEMS ARE INCLUDED FOR ILLUSTRATIVE PURPOSES ONLY AND IN CERTAIN INSTANCES MAY NOT BE AVAILABLE This drawing contains information confidential to Star Manufacturing International, Inc. No reproduction or disclosure of it's contents is permitted. SK2523 Rev.- 6-28-2011 Model: VBE Vertical Broiler...
-
Page 11: Parts List
PARTS LIST February 27, 2014, Rev B VERTICAL ELECTRIC BROILER - VBE30 Fig No Part Number Description Application K8-Z13909 BACK PANEL 2R-Z9686 KNOB,DAVIES 2860AP 1/4-20 K8-VB0002 V.B. TOP ROD HOLDER BRKT K8-VB0012 V.B. MEAT SUPPRT PLATE 2V-VB0006 V.B. MEAT ROD ASSY. - Page 12 18 2 MODEL: VBG Gas Vertical Broiler SK2567, Rev. A 12/17/2014...
- Page 13 V.B. MEAT SUPPRT PLATE 2K-Z13933 PILOT TUBE, 1/4” 2K-70101-122 BRASS COUPLING 1/4” COMP 2A-Z0790 FITTING STRAIGHT 2K-Z13936 BURNER TUBE 3/8” 2A-Z13931 LP ORFICE LP ONLY 2M-Z13926 FRONT LABEL-GAS 2M-Z13922 WIRING DIAGRAM-GAS K8-VB0013 V.B. POWER CORD ASSY Star International Holding, Inc.
- Page 16 STAR INTERNATIONAL HOLDINGS INC. COMPANY Star - Holman - Lang - Wells - Bloomfield - Toastmaster 10 Sunnen Drive, St. Louis, MO 63143 U.S.A. (314) 678-6303 www.star-mfg.com...
